Parts No. |
Description |
A108160102 |
Cover |
A3CKH00102 |
PWB Assembly(PWB-ADF Assy) |
A3CK101400 |
Reinforce Plate |
A108130100 |
Wiring Guide |
A3CK100300 |
Hinge-L |
9J07210901 |
SHOULDER SCREW |
A01H100400 |
GUIDE |
A108940300 |
Label |
A3CK100401 |
Hinge |
A108N10900 |
ADF Wiring |
9J07200801 |
PRESSURE SPRING |
9J07200702 |
Lever |
9J07160200 |
MAGNET |
A3CK160400 |
Seal |
A108160002 |
Cover |
A3CK160300 |
Seal |
A108100800 |
Holding Mat /1 |
A3CK105000 |
Base frame |
A01H100300 |
GUIDE |
A3CK130700 |
Guide |
A3CK130000 |
Fixing Plate /P |
A3CKN10300 |
ADF Wiring |
A3CKN10000 |
ADF Wiring |
A3CK700600 |
Seal |
A108940401 |
Sheet |
A2X0R71800 |
Dual Scan ADF |
A108940000 |
Label |
V137030803 |
screw |
V153030803 |
Screw |
V116030803 |
Screw |
V116040803 |
Screw |
V144030603 |
Screw |
V144030803 |
SCREW |
V153040803 |
screw |
V116030603 |
Screw |
V147031403 |
screw |
V137040803 |
SCREW |
A3CK940100 |
Label |
A3CK560500 |
Regulating Plate /Rear |
4641350301 |
SEAL |
A108561701 |
Lifting Plate |
A3CK560400 |
Regulating Plate /Front |
A0HT560200 |
Bracket |
9J07310701 |
ACTUATOR |
A108M50100 |
Photointerrupter |
A108M50000 |
Photoreflector |
A108N10600 |
ADF Wiring |
A01H561100 |
Plate spring |
A108561800 |
Lever |
9J07341102 |
GUIDE |
A3CKN10400 |
ADF Wiring |
4641341702 |
CAM |
A108563400 |
Guide |
A108563000 |
Mounting Plate |
A108R70400 |
Lifting Motor Assy |
A108563200 |
Holder |
A108563300 |
Gear 14/37T |
4641341501 |
GEAR 13/28T |
4641343601 |
GEAR 30T |
A108563100 |
Plate spring |
A108562600 |
Mounting Plate |
9J07310401 |
STOPPER |
A01H561200 |
GUIDE |
9J07560000 |
PLATE SPRING |
9J07310313 |
Rack |
A108N10800 |
ADF Wiring |
9J07310502 |
GEAR 40T |
A108561103 |
Tray |
A1UDM50100 |
VR |
A108562700 |
Spacer |
A108564301 |
Spacer /A |
A2X0R71611 |
Push Up Plate Assy |
A108564400 |
Spacer |
A108564500 |
Rack |
A3CK892201 |
Lever |
A3CK892100 |
Holder |
A3CK560700 |
Guide |
A108R70800 |
Lifting Motor Assy |
V153030803 |
Screw |
V218040086 |
E ring |
V115030803 |
Screw |
V145030803 |
screw |
V166170504 |
screw |
A0HT560813 |
Cover Upper |
A3CK940200 |
Label |
A108940100 |
Label |
A0HT562200 |
Light blocking Part |
A3CK569000 |
Arm /Rear |
9J07330102 |
Roller |
9J07330801 |
PULLEY 21T |
1067250101 |
PIN |
9J07330201 |
SHAFT |
A3CK568900 |
Arm /Front |
1033440203 |
STOPPER RING |
4469346501 |
BUSHING |
A108M50100 |
Photointerrupter |
A07H570001 |
Guide |
9J07332102 |
GUIDE |
A108N10700 |
ADF Wiring |
A03TM50000 |
Photoreflector |
A07H570200 |
Bracket |
A07H570800 |
Bracket |
A01H565100 |
NEUTRALIZING BRUSH |
A07H570600 |
Bracket |
A07H570400 |
Tension spring |
A07H570500 |
Clutch |
A00J563600 |
Roller |
A3CK569200 |
Paper feed Shaft |
4641351401 |
TIMING BELT 122L |
A3CK569300 |
Gear 16T |
9J07331901 |
PULLEY 19T |
4643300701 |
SHOULDER SCREW |
V153031003 |
screw |
V144030603 |
Screw |
V218040086 |
E ring |
V153030803 |
Screw |
9J07300801 |
ROLL |
A108890500 |
Plate spring |
9J07301702 |
ARM |
9J07302001 |
BRACKET |
9J07301902 |
SHAFT |
A0HT561600 |
Holder /Front |
9J07301601 |
TENSION SPRING |
9J07R71000 |
BRACKET ASSY |
9J07331801 |
BRACKET |
A108561500 |
Guide |
A108891300 |
Neutralizing Brush |
A3CK568300 |
Guide |
A3CK568800 |
Neutralizing Brush |
A3CK568701 |
Torque limiter |
A0HT561202 |
Shaft |
A108563900 |
Roller |
A3CK568200 |
Holder |
A3CK565100 |
Holder |
A3CK568601 |
Spring |
A3CK100700 |
Reinforce Plate |
A108101200 |
Guide |
A108561400 |
Cover |
A0HT891400 |
Ground Plate |
A0HT562800 |
Holder |
A108M50100 |
Photointerrupter |
A108701600 |
Mounting Plate |
A3CK101100 |
Wiring Cover |
V144030603 |
Screw |
V153030803 |
Screw |
V217030001 |
E Ring |
V206040001 |
washer |
V237200850 |
Pin |
9313150021 |
FAN MOTOR |
A3CK130100 |
Vibrationproof Sheet |
A3CK130200 |
Holder |
A2X0R71900 |
Paper Feed Motor Assy |
A0G6243900 |
Ball Bearing |
A3CK213300 |
Mounting Plate |
A108260700 |
Bushing |
A3CK210700 |
Roll |
A108R90000 |
PHOTO INTERRUPTER |
A3CK212100 |
Timing Belt 268L |
A3CK212700 |
Torsion Coil spring |
A3CKM20000 |
Clutch |
A3CK211900 |
Holding Plate |
A3CK213900 |
Compressing Coil spring |
A3CK213600 |
Pulley 24T |
A108711100 |
Handle /Rear |
A3CK702400 |
Guide |
A3CK702500 |
Guide |
A3CK701300 |
Roller |
A108704500 |
Guide Sheet |
A00J617800 |
BALL BEARING |
A108702201 |
Detecting Plate |
A108702500 |
Torsion Coil spring |
A108M50100 |
Photointerrupter |
9J08210401 |
COLLAR |
A3CK711200 |
Sensor Holder |
A0HT890800 |
Shaft |
A2X0R70F00 |
Tension Plate (B) Assy |
A00V240600 |
BALL BEARING |
A3CKN10700 |
ADF Wiring |
9J07501901 |
ROLL |
9J07400902 |
TORSION SPRING |
9J07400801 |
LEVER |
9J07160600 |
WASHER |
A07H750200 |
Neutralizing brush |
A108701800 |
Guide |
A0HT700600 |
Roller |
A3CK701900 |
Guide |
9J07401201 |
SHAFT |
A108703100 |
Stopper |
A3CK705200 |
Mounting Plate |
9335140071 |
SOLID STATE SWITCH |
A3CK711000 |
Mounting Plate |
A3CK213400 |
Gear 16T |
4131253701 |
BUSHING |
A3CK213000 |
Shaft |
A3CK710100 |
Guide |
A108213200 |
Gear 18T |
A108212200 |
Pulley 34/40T |
A3CK213500 |
Pulley 24/40T |
A108214300 |
Pulley 40T |
A108214100 |
Timing belt 122L |
A108703600 |
Guide |
A2X0R71A00 |
Registration Lower Motor Assy |
V144030603 |
Screw |
V217040050 |
E ring |
V217040001 |
E Ring |
V116030603 |
Screw |
V217060001 |
E Ring |
V231201050 |
pin |
V217030001 |
E Ring |
V143030603 |
SCREW |
9J07160302 |
SEAL |
A108702104 |
Mounting Plate |
A3CK706500 |
Compressing Coil spring |
A3CK706401 |
Holder |
9J07431502 |
Stopper |
A108703000 |
Idler Roll |
A108703700 |
Guide |
A108703800 |
Guide |
A108701001 |
Lever |
A108703400 |
Pulling Coil spring |
9J07R70900 |
BRACKET ASSY |
A0HT700800 |
Guide |
A3CK705600 |
Guide |
A3CK705400 |
Guide /2 |
A3CK705301 |
Guide /1 |
A3CK700900 |
Guide |
A0HT701000 |
Guide |
A3CK705800 |
Guide |
A0HT701300 |
Guide |
A3CK705700 |
Guide |
A2X0R70G00 |
Lock Shaft Assy |
A3CK706600 |
Spring |
A3CK703300 |
Registration Shaft |
A3CK700300 |
Guide |
A0HT704100 |
Plate spring |
A0HT704200 |
Torsion Coil spring |
9J07400601 |
BRACKET |
A108701200 |
Ground Plate |
A3CK703200 |
Conveyance Shaft |
A2X0R70700 |
Left Cover Assy |
V137030804 |
screw |
V116030603 |
Screw |
V144030603 |
Screw |
V217040001 |
E Ring |
V153030803 |
Screw |
1200312109 |
BUSHING |
A3CK272600 |
Shoulder screw |
A3CK272001 |
Lever |
A3CK272301 |
Torsion Coil spring |
A3CK272200 |
Shaft |
A3CK272100 |
Roll |
A3CK272401 |
Torsion Coil spring |
9J07420502 |
TORSION SPRING |
9J07420901 |
GUIDE |
A108713300 |
Seal |
A108713200 |
Reinforce Plate |
9J07420801 |
COVER |
9J07420301 |
GUIDE |
9J07420402 |
TORSION SPRING |
A108M50100 |
Photointerrupter |
A0DA701200 |
Bushing |
A3CK714900 |
Shoulder screw |
A2X0R70H00 |
Pressure/Release Motor Assy |
A3CK713800 |
Timing Belt 66L |
A3CK714100 |
Pulley 15T |
A3CK713900 |
Worm |
9J07431101 |
GEAR 26T |
A3CK713400 |
Cam |
A3CK713301 |
Lever |
A3CK714800 |
Mounting Plate |
A3CK272501 |
Support Shaft |
9J07420602 |
Guide |
9J07420204 |
Guide |
V217040001 |
E Ring |
V237201450 |
pin |
V218040086 |
E ring |
V116030603 |
Screw |
V147030803 |
screw |
V144030603 |
Screw |
A3CKM10200 |
Stepping motor |
A3CK210000 |
Mounting Plate |
A108210800 |
Pulley |
A0HT210700 |
Flange |
A00V240600 |
BALL BEARING |
A108210100 |
Timing belt |
A3CK210700 |
Roll |
A2X0R70K00 |
Tension Plate (A) Assy |
A108210400 |
Pulling Coil spring |
A108700200 |
Roller |
A108269900 |
Guide Sheet |
A108267600 |
Protection Cover /Front |
A108268100 |
Protection Cover /Rear |
A0HT700400 |
Roller |
A108269200 |
Guide |
A0HU250600 |
Timing belt |
A108251000 |
Pulley 27/27T |
A0DA701800 |
Flange |
4658351701 |
BUSHING |
A108262501 |
Guide Sheet /C |
A3CK700200 |
Collar |
V116030603 |
Screw |
V144030603 |
Screw |
V116030803 |
Screw |
V217060001 |
E Ring |
V217040001 |
E Ring |
A3CKM10300 |
Stepping motor |
A108216000 |
Mounting Plate |
A0HU250800 |
Timing belt |
A108216200 |
Pulley 34T |
4131253701 |
BUSHING |
A108890800 |
Guide |
A108890000 |
Paper exit Guide /1 |
A108890200 |
Paper exit Roller |
A108R90000 |
PHOTO INTERRUPTER |
9J07491101 |
LEVER |
A0HT891900 |
Bracket |
9J08210401 |
COLLAR |
9J07890000 |
SHAFT |
9J07491201 |
TORSION SPRING |
A108890100 |
Reinforce Stay /4 |
1200312109 |
BUSHING |
A108265900 |
Mounting Plate |
A3CKM10400 |
Stepping motor |
A0DA701200 |
Bushing |
A3CK714900 |
Shoulder screw |
A3CK262900 |
Mounting Plate |
A0HU251200 |
Flange |
A3CKN10A01 |
ADF Cable |
A0HU251100 |
Pulley |
A108262800 |
Belt 260L |
A0HU250300 |
Pulley |
A108M50100 |
Photointerrupter |
A3CK100900 |
Guide |
A108890601 |
Guide |
A2X0R70M00 |
CIS Unit |
A3CKN10500 |
ADF Wiring |
A3CKN10100 |
ADF Wiring |
V144030603 |
Screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V143030603 |
SCREW |
V217030050 |
E ring |
A3CKN10200 |
ADF Wiring |
A3CKH00200 |
PWB Assembly(PWB-DC Assy) |
A3CKN10600 |
ADF Wiring |
A0HU261700 |
Ground Plate |
A0HU261000 |
Mounting Plate |
9335191092 |
SOLID STATE SWITCH |
A3CK271800 |
Compressing Coil spring |
A3CK300200 |
Brush |
A3CK300001 |
Shaft |
A3CK281900 |
Shoulder screw |
A0HU260300 |
Slide Part |
A0HU300300 |
Arm |
A3CK300400 |
Bushing |
A0HU250100 |
Pulley |
A0HU250500 |
Flange |
A0HU261900 |
Spacer |
A3CK281400 |
Sheet |
A3CK281300 |
Sheet |
A0HU261103 |
Guide |
A0HU300400 |
Arm |
A0HU300500 |
Bushing |
A0HU300601 |
Fixing Ring |
A0HU261200 |
Mounting Plate |
A3CK300102 |
Sheet |
A3CK300500 |
Contact |
V116030603 |
Screw |
V115030803 |
Screw |
V144030603 |
Screw |
V143030603 |
SCREW |
V218040086 |
E ring |
V217030050 |
E ring |
V111030603 |
screw |
A108270601 |
Sheet |
A3CK282100 |
Spacer |
A108270200 |
Slide Part |
A3CK270100 |
Guide |
A3CK270001 |
Guide |
A108264700 |
Spacer |
A3CK300200 |
Brush |
A3CK260100 |
Conveyance Guide |
A108260700 |
Bushing |
A108270400 |
Ground Plate |
A108264601 |
Compressing Coil spring |
A108265301 |
Shaft |
A108940200 |
Label |
A108260403 |
Cover |
4163529301 |
SCREW |
A108273200 |
Guide Plate |
A108272900 |
Slide Part |
A108266701 |
Cover |
A00J617800 |
BALL BEARING |
A108264100 |
Pulley |
A108264200 |
Flange |
A108264800 |
Timing belt 146L |
A108265800 |
Pulley |
A108270801 |
Compressing Coil spring |
A0FD892900 |
Timing belt 190L |
A108265700 |
Pulley 25L |
A108M50100 |
Photointerrupter |
A108265600 |
Mounting Plate |
A0HUM10000 |
Stepping motor |
A3CK265000 |
Mounting Plate |
A108270700 |
Plate spring |
A3CK281800 |
Shoulder screw |
A3CK262100 |
Shaft |
A3CK300102 |
Sheet |
A108264400 |
Bushing |
V144030603 |
Screw |
V111030603 |
screw |
V218040086 |
E ring |
V149030803 |
screw |
V217040001 |
E Ring |
V143030603 |
SCREW |
V111260403 |
screw |
V153030803 |
Screw |
A108272700 |
Neutralizing Brush |
9J07810300 |
ROLL |
A108266600 |
Shaft |
A108261701 |
Shaft |
A3CK264500 |
Compressing Coil spring |
A108266800 |
Guide |
A108269600 |
Torsion Spring /Front |
A108260501 |
Lock Part /Front |
A108266300 |
Lock Lever |
A108271101 |
Mounting Plate |
A108M50100 |
Photointerrupter |
A108272000 |
Pulling Coil spring |
A3CK262400 |
Pulling Coil spring |
9J07430201 |
ROLL |
A108272101 |
Guide Plate |
9J07441502 |
GUIDE |
A108272200 |
Guide Plate |
A108272501 |
Shaft |
A108269700 |
Torsion Spring /Rear |
A108260201 |
Lock Part /Rear |
A108260301 |
Mounting Plate |
A108272300 |
Guide Plate |
A3CK700300 |
Guide |
A3CK940000 |
Label |
V153030803 |
Screw |
V217040001 |
E Ring |
V144030603 |
Screw |
V143030603 |
SCREW |
V217030001 |
E Ring |
V111260403 |
screw |
V115260503 |
Screw |
A00J163401 |
Paper exit Cover /Rear |
A00J166400 |
Paper exit Cover /Right |
A00J166300 |
Paper exit Cover /Rear |
A00J163503 |
Paper exit Cover /Right |
A2X0160100 |
Paper exit Cover /Front |
A2X0160500 |
Cover /Left front |
A2X0156600 |
Filter |
A00J160605 |
Cover /Left |
A00J161400 |
Cover /Left rear |
A00J896901 |
Neutralizing Brush |
A2X0895400 |
Ground Seal /1 |
V114040804 |
screw |
V121030804 |
screw |
A00J404700 |
Spacer |
A00J404601 |
Plate spring |
4038228104 |
HOLDER |
4136675101 |
CONNECTOR PIN |
A00J165103 |
Cover /Inside |
A00J407500 |
Holder |
A00J164701 |
Open/close Shaft |
A2X0160400 |
Cover /Front |
4120101402 |
BAND |
A161940400 |
Label |
4475260302 |
MAGNET CATCH |
A161942000 |
Label |
A0P0162600 |
Mounting Plate /B |
A2X0170701 |
Open/close Cover /Front |
A2X0160202 |
Open/close Cover /Front |
A00J945500 |
Logo Mark |
A2X0948600 |
Label |
56AA40490 |
SHAFT STOPPER 4 |
A2X0404800 |
Regulating Block /Black |
A2X0405800 |
Regulating Block /Black |
A2X0405900 |
Regulating Block /Black |
A00J407400 |
SEAL |
A2X0940700 |
Label |
A0P0169600 |
Claw /Black |
A2X0940600 |
Label |
4036532502 |
PAWL |
A2X0940500 |
Label |
A2X0949100 |
Label |
4038101401 |
SUCTION PLATE |
A2X0940400 |
Label |
A0P0N10G00 |
Toner Wiring |
9326282011 |
MAGNET |
4030104002 |
CATCH |
V153030803 |
Screw |
V118030803 |
screw |
V121030804 |
screw |
V153031003 |
screw |
V126030603 |
screw |
V147031403 |
screw |
V153031004 |
screw |
A2X0160800 |
Cover Cassette /Right |
A2X0168500 |
Protection Sheet |
A00JH00D00 |
PWB Assembly LED1 |
4475260302 |
MAGNET CATCH |
A0P0162600 |
Mounting Plate /B |
A2X0170801 |
Open/close Cover /Front |
A2X0172100 |
Cover |
A2X0N10C00 |
Indicating Relay harness / 2 |
A00J164501 |
Mounting Plate |
A161626000 |
Lens |
A161626100 |
Light blocking Sheet |
A161626200 |
Sheet |
A2X0171001 |
Cover |
A2X0172600 |
Cover |
A2X0172300 |
Handle |
A2X0161000 |
Cover |
A2X0172000 |
Cover |
A2X0171701 |
Handle |
A2X0160900 |
Cover |
A2X0171600 |
Cover |
A2X0171801 |
Holder |
A2X0171901 |
Release Lever |
A2X0160301 |
Open/close Cover /Front |
A2X0944001 |
Label |
56AA40490 |
SHAFT STOPPER 4 |
A2X0162100 |
Hinge |
4120101402 |
BAND |
A2X0172200 |
Cover |
A2X0172501 |
Release Lever |
A2X0172400 |
Holder |
A2X1943301 |
Label |
A2X0943301 |
Label |
A2X0N10D00 |
Indicating Relay harness / 1 |
V153030803 |
Screw |
V126030603 |
screw |
V114040804 |
screw |
V153031004 |
screw |
V137040803 |
SCREW |
V153031003 |
screw |
A2X0132800 |
Cover |
A2X0161600 |
Cover/Rear |
A2X0162301 |
Cover/Rear |
A2X0161700 |
Cover/Rear |
A00J161804 |
Cover/Rear |
A2X0161901 |
Cover/Rear |
A0P0165301 |
Cover |
A0P0162004 |
Cover/Rear |
A2X0165702 |
Cover |
A00J162802 |
COVER /RIGHT REAR |
A00J164201 |
Cover |
A0P0161300 |
Cover /Right |
A00J162901 |
Cover /Right front |
A0P0163800 |
Cover |
A0P0162702 |
Cover /Right rear |
A2X0165400 |
Cover /Inside |
A2X0948900 |
Seal |
A2X0165602 |
Cover |
A161164401 |
Cover |
A00J945400 |
Label Dehumidifier SW. |
A00J945800 |
Label Controller |
A2X0945700 |
Label |
A2X0945000 |
Label |
V153030803 |
Screw |
V121030804 |
screw |
V114040804 |
screw |
V121030803 |
SCREW |
A2X0167900 |
Cover |
A2X0263200 |
Frame |
A2X0167400 |
Cover |
A2X0171101 |
Light blocking Cover |
A161190900 |
Cover |
A2X0R70500 |
Operation Panel Mounting Part Assy |
A2X0168101 |
Cover |
A161167000 |
Lens |
A161167100 |
Lens |
A2X0170400 |
Cover /Front |
A161167400 |
Light blocking Sheet /2 |
A2X0168200 |
Light blocking Sheet /1 |
A161H00U01 |
PWB Assembly(PWB-LED ASSY) |
A2X0170600 |
Mounting Plate |
A2X0170500 |
Cover /Front |
A2X0167500 |
Cover |
A161M70501 |
Panel assembly |
A161M70601 |
Panel assembly |
A161M70701 |
Panel assembly |
A011946200 |
Label Emperon |
V121030804 |
screw |
V137030603 |
screw |
V144040603 |
SCREW |
V116041003 |
Screw |
V116040803 |
Screw |
V153030803 |
Screw |
V116030803 |
Screw |
A0P0163101 |
Read Cover/Rear |
A00J167812 |
Read Cover /Upper |
A00J169200 |
Shoulder screw |
A0P0167202 |
Read Cover /Upper |
A02E167700 |
Cover |
A2X0165801 |
Read Cover /Front |
A0P0165200 |
Cover |
A2X0167601 |
Read Cover |
A2X0163001 |
Read Cover /Front |
A2X0168300 |
Holder |
A2X0168600 |
Cushion |
A161941500 |
Label |
A00J940100 |
Label Legal Restiriction |
A00J167104 |
Read Cover /Upper |
A2X0167300 |
Seal |
A0P0163201 |
Read Cover /Left |
A2X0267900 |
Mounting Plate |
A0P0166600 |
Seal |
A0P0267300 |
Guide |
A2X0163302 |
Read Cover /Right |
A1UD947400 |
Label |
A161940602 |
Label |
V121030804 |
screw |
V121030803 |
SCREW |
V153030803 |
Screw |
V137030603 |
screw |
V137040803 |
SCREW |
A0P0267800 |
Mounting Plate |
A0P0262103 |
Frame |
9J07210802 |
SHOULDER SCREW |
A2X0261900 |
Frame |
4581162501 |
SEAL |
A0P0262002 |
Frame |
A2X0N14400 |
Scanner Wiring /4 |
4037090301 |
PHOTO INTERRUPTER |
A00J280101 |
Mounting Plate |
A00J280200 |
Lever |
4036172001 |
PRESSURE SPRING |
A0P0267600 |
Seal |
A2X0N14300 |
Scanner Wiring /3 |
A1UDM50200 |
Lead Switch |
A0P0267501 |
Mounting Plate |
A0P0263800 |
Mounting Plate |
A0P0M73100 |
Speaker |
A0P0262200 |
Mounting Plate |
A2X0263100 |
Reinforce Plate |
A0P0267300 |
Guide |
A0P0263301 |
Mounting Plate /Right rear |
A0P0263400 |
Reinforce Plate |
9335140061 |
SOLID STATE SWITCH |
A0P0267000 |
Reinforce Plate |
A0P0281801 |
Mounting Plate |
V137030603 |
screw |
V195040003 |
Nut |
V115030803 |
Screw |
V115030603 |
Screw |
V137040803 |
SCREW |
A0P0R71000 |
Manuscript glass assy |
A00J265200 |
Holding Plate |
A2X0265100 |
Holding Plate |
A00J265300 |
Regulating Plate |
A1DM268801 |
Holding Plate |
A00J169200 |
Shoulder screw |
A1DM266000 |
Hold Plate |
A2X0R70A00 |
Slit Glass Assy |
A0ED268700 |
Regulating Plate |
A1DM267501 |
Cover |
V127030604 |
screw |
V121030804 |
screw |
A0P0278500 |
Cover |
A2X0R70000 |
CCD Lens Assy (After) |
A0P0H02500 |
PWB assembly(PWB-UCN ASSY) |
A0P0148000 |
Mounting Plate |
A0P0148101 |
Mounting Plate /1 |
A0P0148201 |
Mounting Plate /2 |
A161M31001 |
Lamp |
A2X0N14001 |
CCD Cable |
V116030603 |
Screw |
V137030803 |
screw |
V111020603 |
screw |
V137030603 |
screw |
A161M10A00 |
Stepping motor |
A0P0276600 |
Mounting Plate |
A0P0275500 |
Pulley 84T |
A0ED276500 |
Bearing |
A0ED275600 |
Belt 210L |
A2X0N14200 |
Scanner Wiring /2 |
A161M50A00 |
APS Photoreflector |
A161M50A00 |
APS Photoreflector |
A2X0281200 |
Guide |
A2X0281100 |
Mounting Plate |
A2X0H01A00 |
PWB Assembly(PWB-ID ASSY) |
4002145801 |
TENSION SPRING |
4581131601 |
SEAL |
A2X0264600 |
Seal |
V137030603 |
screw |
V116030803 |
Screw |
V115030603 |
Screw |
V116030603 |
Screw |
A0P0101212 |
Support Plate |
A108M50100 |
Photointerrupter |
4038229401 |
SPRING |
A0P0107700 |
Mounting Plate /ASSY |
4038229501 |
HOLDER |
A2X0156700 |
Seal |
A2X0110000 |
Seal |
4038229301 |
SPRING |
A0P0107601 |
Holder /Black |
V651020004 |
Drawer CN |
A0P0382400 |
Positioning Pin /Front |
A00J105601 |
Guide Post |
A2X0105700 |
Guide Post |
4581162501 |
SEAL |
A2X0155000 |
Cover |
A2WU156000 |
Seal |
A2X0156800 |
Cover |
A2X0156300 |
Seal |
A00J102301 |
Shaft |
A2X0R70B00 |
Print Head Assy |
A2X0N12G00 |
Control Relay harness /3 |
A2X0H00300 |
PWB Assembly(PWB-J ASSY) |
A00J137500 |
Mounting Plate |
V502010026 |
SUPPORT |
A0P0137401 |
Mounting Plate |
A2X0135900 |
Holder |
V217080001 |
E ring |
V137030803 |
screw |
V116030603 |
Screw |
V137030603 |
screw |
V207030003 |
washer |
V217020050 |
E ring |
V137040803 |
SCREW |
V153030803 |
Screw |
A0P0108400 |
Mounting Plate /Left |
A0P0125000 |
Slide Rail |
A0P0108100 |
Spacer |
A0P0115700 |
Holder |
A00J941201 |
Label |
A0P0110501 |
Rail /E |
A0P0108900 |
Sealing Part |
A0P0108623 |
Scatteringprevention Duct |
A0P0125311 |
Seal |
A0P0382700 |
Screw |
A00J121200 |
Cushion /Lower |
A0P0114100 |
Ozone Seal /Black |
A0P0108300 |
Sealing Part |
A0P0108201 |
Mounting Plate /Lower |
A0P0109701 |
Protection Cushion |
A0P0108500 |
Mounting Plate /Right |
V116030803 |
Screw |
V116030603 |
Screw |
V137030803 |
screw |
V118030403 |
screw |
A2X0N13200 |
Chaging Wiring /C |
A2X0N13700 |
Chaging Wiring /2 |
A0P0111900 |
Compressing Coil spring |
4004231701 |
PRESSURE SPRING |
4036231101 |
PIN |
A0P0R71500 |
Contact2 assy |
A00JR73400 |
TERMINAL 3 ASSY |
A00J110800 |
Developing Contact /Front |
A00J112200 |
Holder /Color |
A00J110900 |
Developing Contact / Middle |
A00J115900 |
Compressing Spring |
A00J112800 |
COVER /YELLOW |
A2X0N13600 |
Chaging Wiring /1 |
A2X0N13300 |
Chaging Relay harness /K |
A2X0N13000 |
Chaging Wiring /Y |
A2X0N13100 |
Chaging Wiring /M |
A00J118200 |
Contact /Yellow |
A00J118000 |
Developing Contact / Yellow |
A00J118400 |
Cover /Yellow |
A00JR73800 |
TERMINAL Y ASSY |
A00J118300 |
Contact /Magenta |
A00J118100 |
Developing Contact / Magenta |
A00J118500 |
Cover /Magenta |
A00JR73900 |
TERMINAL M ASSY |
A0P0R71800 |
C/K contact assy |
V116030603 |
Screw |
V153030803 |
Screw |
4004182902 |
CUSHION |
A00J121000 |
Swing Shaft |
A00J121400 |
Torsion Spring |
A00J120900 |
Knob |
A00J120201 |
Claw |
A00J120300 |
Support Shaft |
A00J121500 |
Compressing Spring |
A00J120100 |
Lever /Color |
A0P0120800 |
Mounting Plate /Black |
A108M50100 |
Photointerrupter |
A0P0121300 |
Mounting Plate /Cyan |
A00J120500 |
Mounting Plate /Left |
A00J121200 |
Cushion /Lower |
A00J120600 |
Mounting Plate /Right |
A0P0A14001 |
IU Lock(YM) |
A0P0A14101 |
IU Lock (C) |
V217030001 |
E Ring |
V137030603 |
screw |
A00J114901 |
Seal /B |
A0P0113600 |
Ozone Duct /B |
A00J114401 |
Seal /A |
A2X0114300 |
Seal /Cyan |
4036606202 |
ERASE ASSY |
A00J119600 |
Positioning Holder /Cyan |
A00J119500 |
Positioning Holder /Yellow |
A00J113401 |
Ozone Duct |
A00J114701 |
Seal |
A00J113800 |
Ozone Duct /Inside |
A00J116201 |
Seal /Upper |
A00J116100 |
Seal /Lower |
A0P0115000 |
Seal /Inside |
A00J116400 |
Ozone Duct /Front |
A00J116301 |
Ozone Duct /Rear |
A0P0119700 |
Ozone Duct /A |
9313100072 |
FAN MOTOR |
4036248501 |
SEAL |
A0P0119800 |
Ozone Duct /B |
A00J116511 |
Seal |
A2X0R71E00 |
Ozone Filter |
A00J117000 |
Duct /Cyan |
A00J114801 |
Seal /Cyan |
A2X0113500 |
Ozone Duct /Cyan |
A00J114502 |
Seal /B |
A00J114603 |
Seal |
V153044503 |
SCREW |
V153030803 |
Screw |
V116030603 |
Screw |
V137030603 |
screw |
A0P0402500 |
Mounting Plate /T |
9326290006 |
MAGNET |
A0P0407701 |
Detecting Plate |
A2X0N12300 |
Toner Drive harness |
65AA32501 |
BUSHING /B |
A0P0400100 |
Supply Casing |
4036534903 |
SEAL |
4036534801 |
TENSION SPRING |
4036534702 |
SHUTTER |
A0P0405400 |
Cover /Lower |
A0P0400600 |
Agitating Shaft |
A00J401700 |
Gear 45T |
A0P0400800 |
Toner supply Sheet |
A0P0407800 |
Pin |
A2X0R71400 |
Sub Hopper Assy |
A00J400500 |
Supply Roller |
A00J401600 |
Gear 22T |
A00J401900 |
Gear 17/44T |
A2X0401800 |
Gear 35/45T |
A2X0401000 |
Guide Plate |
A00JM12100 |
Stepping motor |
A2X0F41001 |
DrivePanel/H |
A0P0407900 |
Protection Plate |
A0P0402200 |
Seal /A |
A00J407300 |
SEAL |
4011533901 |
PLATE NUT |
9334271011 |
SWITCH |
A00J401401 |
Spring /A |
A0P0400301 |
Cover /Upper |
A00J401200 |
Regulating Claw |
A0P0406800 |
Receiving Block |
A00J400401 |
Shutter /H |
A0P0405600 |
Guide Cover /Left |
A0P0405500 |
Guide Cover /Right |
A00J400900 |
Seal /S |
V118030803 |
screw |
V153030803 |
Screw |
V112030803 |
screw |
V116031003 |
Screw |
V217040001 |
E Ring |
V115030803 |
Screw |
V153031004 |
screw |
V137030603 |
screw |
A0P0406700 |
Cover |
A00J400611 |
Agitating Shaft |
A00JR74400 |
AGITAING PANEL |
65AA32501 |
BUSHING /B |
A00J402300 |
Seal |
A00J400112 |
Supply Casing |
4036534903 |
SEAL |
4036534801 |
TENSION SPRING |
4036534702 |
SHUTTER |
A00J405400 |
Cover /Lower |
A00JN12100 |
TONER RELAY HARNESS/3 |
A00J401700 |
Gear 45T |
A2X0401800 |
Gear 35/45T |
A0P0401000 |
Seal |
A00JM12100 |
Stepping motor |
A2X0F41001 |
DrivePanel/H |
A00J401900 |
Gear 17/44T |
A00J402200 |
Seal /A |
A00J401600 |
Gear 22T |
A00J400500 |
Supply Roller |
A00J407300 |
SEAL |
A00J401401 |
Spring /A |
A00J400300 |
Cover /Upper |
A00J401200 |
Regulating Claw |
A00J400401 |
Shutter /H |
A00J406801 |
Receiving Block /Left |
A00J406901 |
Receiving Block /Right |
A00J405600 |
Guide Cover /Left |
A00J400900 |
Seal /S |
A00J405500 |
Guide Cover /Right |
40AA88031 |
Level Detection Sensor |
A00J406600 |
Panel /P |
A2X0401000 |
Guide Plate |
V118030803 |
screw |
V145030803 |
screw |
V153030803 |
Screw |
V115030803 |
Screw |
V217040001 |
E Ring |
V153031004 |
screw |
A0P0502300 |
Holder |
4163407201 |
TORSION SPRING |
4036482701 |
SEPARATOR |
A2X0R70100 |
Transfer Unit (After) |
V116030803 |
Screw |
A00JR90000 |
PHOTO INTERRUPTER |
A00J524201 |
Cover /2 |
A00J524101 |
Cover /1 |
A00JR7A200 |
PLATE / REAR |
A2X0N12M00 |
Sensor Relay harness /4 |
A00JR7A300 |
LOCK PLATE/REAR |
A00J523201 |
Connecting Plate |
A2X0N13C00 |
Transfer Wiring |
A2X0N13D00 |
Separating Wiring /E |
A00J524402 |
Cover /4 |
4036231101 |
PIN |
A00J520102 |
Transfer Rail /Front |
A00J521601 |
Plate spring /1 |
A00JR7A500 |
LOCK PLATE/FRONT |
A00J523901 |
Connecting Plate |
A00JR7A600 |
PLATE/FRONT |
A00J521701 |
Plate spring /2 |
A00J522600 |
Contact /Black |
A00J520300 |
Contact /Black |
A00J522700 |
Contact /Cyan |
A00J520400 |
Contact /Cyan |
A00J520600 |
Contact /Yellow |
A0P0109501 |
Guide Seal /2 |
A00J520203 |
Transfer Rail /Rear |
A00J520800 |
Contact |
A00J520900 |
Contact |
A2X0N13E00 |
Separating Wiring /1 |
A2X0N13F00 |
Separating Wiring /2 |
A00J524300 |
Cover /3 |
A00J520500 |
Contact /Magenta |
V217040001 |
E Ring |
V153031003 |
screw |
V153030803 |
Screw |
V116040803 |
Screw |
V137030603 |
screw |
V153030603 |
screw |
V153040803 |
screw |
A2XKN10J00 |
Grounding Wiring |
A2X0125400 |
Protection Sheet |
A00J104700 |
Mounting Plate |
A00JR73700 |
ERASER LAMP ASSY |
A00J107001 |
Mounting Plate |
A2X0102500 |
Guide Plate /Front |
A2X0948500 |
Label |
A2X0404901 |
Regulating Block /Cyan |
A2X0406001 |
Regulating Block /Cyan |
A2X0406301 |
Regulating Block /Cyan |
A2X0948400 |
Label |
A2X0405001 |
Regulating Block /Magenta |
A2X0406101 |
Regulating Block /Magenta |
A2X0406401 |
Regulating Block /Magenta |
A2X0405101 |
Regulating Block /Yellow |
A2X0406201 |
Regulating Block /Yellow |
A2X0406501 |
Regulating Block /Yellow |
A2X0948300 |
Label |
A00J137105 |
Cover |
A00J107100 |
Reinforce Plate |
A1DM403900 |
Protection Plate |
A2X0102600 |
Guide Plate /Rear |
A2X0106600 |
Spacer |
A2X0106700 |
Spacer |
A2X0106800 |
Spacer |
A2X0100701 |
Mounting Plate |
A00JM30301 |
LED array |
A00J145101 |
Mounting Plate |
A00J145000 |
Mounting Plate |
A00J145200 |
Light blocking Part |
A1DM403600 |
Seal |
A00J107401 |
Sheet |
V116030603 |
Screw |
V137030603 |
screw |
V137030803 |
screw |
V137040803 |
SCREW |
V153030803 |
Screw |
V144030803 |
SCREW |
V116030803 |
Screw |
A0P0364800 |
Fixing Plate /Right |
A00J365001 |
Knob |
A0P0366000 |
Guide Part /Right |
A0XPWY1 |
Bottle(Toner Collection) |
A0P0366200 |
Guide Part /Middle |
A00J361101 |
Collection Shutter |
A00J361200 |
Compressing Spring |
A00J361700 |
Collection Pipe |
A00J360800 |
Conveyance Screw |
4037090101 |
PHOTO INTERRUPTER |
A0P0366100 |
Guide Part /Left |
A0P0362900 |
Gear 27T |
A0P0364100 |
Drive Gear /10 17T |
A108M50100 |
Photointerrupter |
A0P0364200 |
Shaft |
A2WUR70400 |
Fixing Plate |
A0P0364900 |
Fixing Plate /Left |
A0P0366301 |
Mounting Plate |
A0P0360700 |
Collection Casing |
65AA32501 |
BUSHING /B |
A00J361900 |
Drive Shaft /2 |
A00J362700 |
Gear 20T |
A00J363000 |
Gear 38/35T |
A0P0364000 |
Bushing |
A00J362500 |
Gear 30T |
A00J362400 |
Gear 30/20T |
A0P0368500 |
Gear 28T |
A2WU364100 |
Gear 34T |
A00JM12100 |
Stepping motor |
A0P0361000 |
Mounting Plate /ASSY |
A00J362600 |
Gear 18T |
A00J362800 |
Gear 40T |
A0P0368400 |
Gear26T |
A00J361800 |
Drive Shaft /1 |
A0P0368200 |
Bushing |
A0P0368600 |
Seal |
A0P0368100 |
Agitating Paddle |
A00J361000 |
Gear 38T |
A00J365402 |
Sealing Shutter |
A0P0R71322 |
Toner collection assy |
A0P0366400 |
Seal |
A2X0R71F00 |
Toner Supply Duct Assy |
A0P0361100 |
Mounting Plate /2 |
A2WU362900 |
Gear 22T |
A0P0361500 |
Seal |
V137030603 |
screw |
V115030603 |
Screw |
V153030803 |
Screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V218040086 |
E ring |
A2X0R70E00 |
Paper Feed 1 Assy |
56AA40490 |
SHAFT STOPPER 4 |
A00J563600 |
Roller |
A00J562502 |
Mounting Plate /1 |
A2X0624200 |
Mounting Plate |
A00J566300 |
Washer |
A00J562400 |
Gear 28T |
A00J562800 |
Timing belt 160L |
A00J562300 |
Gear 22/32T |
A2X0R70P00 |
Mounting Plate/Paper Feed Drive Assy |
A00J562200 |
Gear 24/42T |
A2X0M10100 |
Stepping motor |
A0P0570400 |
Gear 24T |
A0HT811400 |
Timing belt 76L |
A0P0R7A111 |
Frame/Drive Moter |
A2X0M10300 |
Stepping motor |
A2X0R90100 |
Separation Roller Kit |
A00J563500 |
Clutch |
V118040803 |
screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V116030803 |
Screw |
V217060001 |
E Ring |
A00J574611 |
Attaching Cover |
A00J573712 |
Lock Claw /Front |
A00J571712 |
Paper feed Door /Lower |
A00J574500 |
PULLING SPRING / LOWER |
A00J574100 |
IDLER SHAFT |
4030312201 |
ROLL |
A0P0571911 |
Guide Plate /Lower |
56AA40490 |
SHAFT STOPPER 4 |
A00J563600 |
Roller |
A2X0R70J00 |
Paper Feed 2 Assy |
A0P0570400 |
Gear 24T |
A0HT811400 |
Timing belt 76L |
A0P0R7A111 |
Frame/Drive Moter |
A2X0M10300 |
Stepping motor |
A0P0573100 |
Mounting Plate |
A0P0575500 |
Torsion Spring |
A00J573801 |
Lock Claw /Rear |
A00J573900 |
MOUNTING PLATE |
A00J566600 |
Torsion Spring |
A0P0571811 |
Guide Plate /Upper |
A2X0568400 |
Ground Contact |
A00J573601 |
Stopper Door |
A2X0R90100 |
Separation Roller Kit |
A2X0N10F00 |
Paperfeed Drive harness |
A00J563500 |
Clutch |
V116040803 |
Screw |
V217040001 |
E Ring |
V217080001 |
E ring |
V153030803 |
Screw |
V153040803 |
screw |
V118040803 |
screw |
V116030603 |
Screw |
A02E622700 |
Cushion |
A2X0624400 |
Cover |
A161620600 |
Shoulder screw |
A161620701 |
Gear |
A161943000 |
Label |
A161620802 |
Regulating Plate /Front |
4037320401 |
KNOB |
A161621300 |
Lever |
A0ED621400 |
Pulling Coil spring |
4163529301 |
SCREW |
A0ED620200 |
Guide |
A2X0631300 |
Mounting Plate |
1151330001 |
SCREW |
A161943801 |
Label |
A161626200 |
Sheet |
A161626000 |
Lens |
A161626100 |
Light blocking Sheet |
A2X0170901 |
Cover |
A161625900 |
Cover |
A161625201 |
Handle |
A2X0160702 |
Cover |
A161626601 |
Lever |
A161626800 |
Pulling Coil spring |
A161626300 |
Holder |
A2X0624001 |
Lever |
A2X0624500 |
Stopper |
A161621900 |
Mounting Plate |
A2X0621400 |
Lever |
A161620500 |
Lifting Plate |
A00J623400 |
FRICTION PLATE |
A00J630500 |
Guide Sheet |
A2X0631000 |
Mounting Plate |
A00J631900 |
GUIDE SHEET/2 |
A00J631100 |
Stopper |
4030322601 |
FRICTION SHEET |
A161621800 |
Plate spring |
A2X0624600 |
Stopper /2 |
A161622100 |
Ground Plate |
A2X0621600 |
Lifting Shaft |
A0P0623700 |
Lever |
A2X0624300 |
Compressing Coil spring |
A2X0631400 |
Mounting Plate |
4030320601 |
LEVER |
A161943601 |
Label |
A161943500 |
Label |
A161621701 |
Regulating Plate |
A00J942202 |
Label FD |
A00J631700 |
Screw |
A161621100 |
Rack |
A2X0620901 |
Regulating Plate /Rear |
4002730601 |
LABEL CARRYING CAPACITY |
4537331701 |
GUIDE |
A2X0F62007 |
cassette |
A02E940300 |
Label Iu |
V153030803 |
Screw |
V153040803 |
screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V125041001 |
Screw |
V144040603 |
SCREW |
A2X0630800 |
Mounting Plate |
A00J618400 |
Screw |
A00J631204 |
Slide Rail /A |
4036141001 |
SHOULDER SCREW |
A2X0631600 |
Mounting Plate /Front |
A2X0624101 |
Lock Holder |
A00J631800 |
HOLDING PLATE |
A00J630102 |
Mounting Plate |
V137040803 |
SCREW |
V137030803 |
screw |
V209040003 |
washer |
A0P0138600 |
Cover |
A00J133200 |
Rail /Left |
A00J575302 |
Mounting Plate |
A2X0N11600 |
Paperfeed Relay harness / 1 |
A2X0N11700 |
Paperfeed Relay harness / 2 |
A2X0M12001 |
Brush motor |
4002313101 |
SHOULDER SCREW |
4002311002 |
Pressure Spring |
A108M50100 |
Photointerrupter |
4030308104 |
Pressure Spring |
4037090601 |
PHOTO INTERRUPTER |
4030322402 |
SHOULDER SCREW |
4030308301 |
HOLDER |
A2X0575100 |
Mounting Plate |
A161628000 |
Holder |
A161M50600 |
Photointerrupter |
A161M50501 |
Photointerrupter |
A161627500 |
Holder |
V116030603 |
Screw |
V137030603 |
screw |
V116033003 |
Screw |
V145030803 |
screw |
V118040803 |
screw |
V116030803 |
Screw |
A00J618101 |
Cover |
A00J601201 |
Paper feed Cover /1 |
A108M50100 |
Photointerrupter |
A00J605511 |
Conveyance Roller |
A00J617800 |
BALL BEARING |
A00J600313 |
Guide Assy draw /1 |
A00J603300 |
Detection Actuator /2 |
A00J603200 |
Mounting Plate |
A00J605001 |
Torsion Spring |
56AA40490 |
SHAFT STOPPER 4 |
A00J663200 |
Bushing |
A00J600600 |
Regulating Plate /Front |
A0TJ602900 |
Pulley /3 |
A0TJ602800 |
Pulley /2 |
A00J604301 |
Actuator |
A00J563600 |
Roller |
A0TJ603000 |
Pulley /1 |
A00J602700 |
Timing belt 102L |
A00J600204 |
Paper feed Base frame /2 |
A2X0603000 |
Shaft |
A03U812800 |
Slide Shaft Holder |
56AA82012 |
PAPER FEED DRIVING CLUTCH |
55VA42120 |
SHAFT STOPPER |
A00J605300 |
Paper feed Coupling /2 |
A00J605400 |
Pressing Spring |
A00J660700 |
Washer |
A00J617900 |
Ball Bearing |
A00J603102 |
Auxiliary Part |
A00J618300 |
Handle |
A00J619400 |
Auxiliary Part /2 |
56AA40380 |
PAPER FEED REGULATING BLOCK |
A00JN11E01 |
PFU Relay harness /5 |
A00J600400 |
Regulating Plate /Rear |
A2X0604200 |
Paper feed Shaft |
A2X0667500 |
Holder |
A00J600500 |
Coupling |
A00J600800 |
Paper feed Shaft /1 |
15AG50280 |
PUNCH SPACER |
A00J600701 |
Detection Actuator /1 |
A00J615901 |
Detection Actuator /1 |
A00J604401 |
Mounting Plate |
A00J660800 |
Washer |
A0P0663300 |
Holder |
A00J660900 |
Sealing Magnet |
A2X0R70Q00 |
1000-Sheet Paper Feed Assy |
A0P0664000 |
Washer |
A00J563500 |
Clutch |
V118030603 |
screw |
V233201050 |
pin |
V127030603 |
screw |
V217040001 |
E Ring |
V217060001 |
E Ring |
V116030803 |
Screw |
V153030803 |
Screw |
V231200850 |
Pin |
V218030086 |
E ring |
V118030403 |
screw |
V127030803 |
screw |
V153031003 |
screw |
V217030001 |
E Ring |
A00J618700 |
Conveyance Cover |
A00J604701 |
Pulling Spring |
A00J605100 |
Idler Roll |
A00J605200 |
Idler Shaft |
56AA40430 |
SPRING MOUNTING PLATE 1 |
A00J604800 |
Pulling Spring |
A00J601300 |
Mounting Plate |
A00J663200 |
Bushing |
A00J601501 |
Mounting Plate /ASSY |
A00J618601 |
Guide Plate /2 |
A00J601700 |
Shaft |
A0P0664000 |
Washer |
A00J619611 |
Pulley 14T |
A00J618500 |
Torque limiter |
56AA40490 |
SHAFT STOPPER 4 |
A00J563600 |
Roller |
A00J619500 |
Pulley 15T |
A00J619800 |
Timing Belt 96L |
A00J619700 |
ROLL /1 |
56AA40540 |
ENTRANCE GUIDE SHEET |
A00J601600 |
Multi-feed Adjusting Plate |
A00J601402 |
Input Shaft |
A0P0663500 |
Input Shaft |
A00J603600 |
Mounting Plate |
56AA40510 |
PRESSING SPRING |
56AA40450 |
PAPER FEED COUPLING PART |
56AA75050 |
CLEANER SHAFT HOLDER |
A00J603400 |
Gear 22/14T |
A00J600900 |
Gear43T |
A00J605600 |
Ground Plate /1 |
V153030803 |
Screw |
V217040001 |
E Ring |
V217060001 |
E Ring |
V231200850 |
Pin |
V116030803 |
Screw |
V116030603 |
Screw |
V231301450 |
pin |
V127030803 |
screw |
V233161050 |
pin |
A2X0M10200 |
Stepping motor |
A00J611300 |
Drive Shaft /5 |
A00J616900 |
Drive Shaft /1 |
A00JM20000 |
Clutch |
A00J612100 |
Gear 32T |
56AA40490 |
SHAFT STOPPER 4 |
A00J617700 |
Mounting Plate |
A00V240600 |
BALL BEARING |
A2X0R70S00 |
Mounting Plate/LCC Length Conveyance Dri |
A00J616200 |
Gear 31T |
A00J616300 |
Gear 44T |
A00J700900 |
Collar |
55VA42120 |
SHAFT STOPPER |
A00J612500 |
Gear 25T |
A00J610200 |
Fixing Plate /1 |
A00J611600 |
Gear 40/33T |
A00J610600 |
Timing belt 633L |
A00J611500 |
Gear 67T |
A00J612600 |
Holding Part /1 |
A00J610812 |
Drive Shaft /1 |
A00J610300 |
Fixing Plate |
A00J612200 |
Pulley 33T |
4004254701 |
PIN |
A00J611711 |
Gear 29T |
A00J612800 |
Regulating Part |
A0P0666400 |
Tension Roll |
A0P0R7A200 |
Mounting plate /Belt tension |
56QA15190 |
BELT TENSION SPRING |
A00J611900 |
Gear 30T |
A00J611200 |
Drive Shaft /4 |
A161M10200 |
brushless Motor /20 |
A00J611800 |
Gear 33T |
A00J611000 |
Drive Shaft /2 |
A00J611100 |
Drive Shaft /3 |
A00J137600 |
Cover |
A00JR7AJ00 |
MOUNTING PLATE / LCC DRIVE 2 |
A00J616400 |
Gear 29T |
A00J616500 |
Gear 33T |
A00J616601 |
Mounting Plate |
A00J616800 |
Gear 35T |
A00J613000 |
Gear 35T |
A00J612000 |
Gear 29T |
1500266013 |
WAVE WASHER |
A0P0R7A311 |
Mounting plate / LCC drive 1 |
A2X0667200 |
Fixing Plate |
V116030603 |
Screw |
V217060001 |
E Ring |
V116040803 |
Screw |
V232302209 |
pin |
V231301450 |
pin |
V217040001 |
E Ring |
V116030803 |
Screw |
A00J631204 |
Slide Rail /A |
A00J618400 |
Screw |
A00J607100 |
Mounting Plate |
A00J607800 |
Ground Plate |
A00J607401 |
Mounting Plate |
A00J607500 |
Mounting Plate |
A0P0607000 |
Conveyance Roller /A |
A0P0606000 |
Conveyance Base frame |
A0P0663600 |
Bushing |
A03U812800 |
Slide Shaft Holder |
A00J941800 |
Label LC1 |
A00J660100 |
COUPLING SPRING |
55VA15541 |
CLEANER COUPLING PART |
V153030803 |
Screw |
V217060001 |
E Ring |
V118030803 |
screw |
V231301450 |
pin |
V217040001 |
E Ring |
V149030803 |
screw |
A00J614002 |
Mounting Plate /A |
A00J614501 |
Support Shaft /B |
A00J614700 |
Swing Shaft /B |
A00J614300 |
Sensor Block |
56AA40490 |
SHAFT STOPPER 4 |
4037090601 |
PHOTO INTERRUPTER |
56QA57240 |
PAPER DETECTION ACTUATOR |
56QA57170 |
PRESSURE SPRING |
A00J614800 |
Mounting Plate |
A00J614200 |
Swing Panel /B |
4036596601 |
SCREW |
A0P0606400 |
Mounting Plate |
A00J606500 |
Idler Shaft |
4030312201 |
ROLL |
A00J606600 |
Compressing Spring |
A0P0606200 |
Conveyance Cover |
A00J606100 |
Guide Plate |
56QA57110 |
SUPPORT BLOCK |
A00J606802 |
Mounting Plate |
A00J606900 |
Compressing Spring |
A00J606700 |
Guide Plate |
A00J660200 |
LOCK SPRING |
A00J607301 |
Mounting Plate /1 |
A0P0663400 |
Light blocking Sheet |
A00J622600 |
Shaft /L |
A00J623300 |
Shaft |
A00J663000 |
Roll |
56AA41711 |
TRAY PRESSING PLATE |
A00J941900 |
Label LC2 |
A00J607600 |
Ground Plate |
A00J607700 |
Ground Plate |
A00J614101 |
Swing Panel /ASSY |
56QA57210 |
SWING SPRING REAR |
A00J614600 |
Swing Shaft /A |
A00J614400 |
Support Shaft /A |
A00JN11F01 |
PFU Relay harness /6 |
V118030603 |
screw |
V217030001 |
E Ring |
V153030803 |
Screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V118040603 |
screw |
A00J603800 |
Paper feed Cover |
1134304101 |
COLLAR |
A00J619101 |
Mounting Plate |
A00J601111 |
Conveyance Roller |
1134304202 |
SHAFT |
A00J604002 |
Actuator |
A00J615800 |
Torsion Spring |
A108M50100 |
Photointerrupter |
A00J603900 |
Mounting Plate |
56AA40490 |
SHAFT STOPPER 4 |
A00J663200 |
Bushing |
A00J617800 |
BALL BEARING |
A00J603713 |
Guide Assy draw /2 |
A00J600600 |
Regulating Plate /Front |
A0TJ602900 |
Pulley /3 |
A0TJ602800 |
Pulley /2 |
A2X0604200 |
Paper feed Shaft |
A2X0603000 |
Shaft |
A00J602401 |
Level Actuator /1 |
A00J563600 |
Roller |
A0TJ603000 |
Pulley /1 |
A00J602700 |
Timing belt 102L |
A00J600115 |
Paper feed Base frame /1 |
A03U812800 |
Slide Shaft Holder |
A00J603500 |
Paper feed Shaft /2 |
55VA42120 |
SHAFT STOPPER |
56AA82012 |
PAPER FEED DRIVING CLUTCH |
A00J617900 |
Ball Bearing |
A00J618300 |
Handle |
A00J603102 |
Auxiliary Part |
A00J619400 |
Auxiliary Part /2 |
56AA40380 |
PAPER FEED REGULATING BLOCK |
A00J600400 |
Regulating Plate /Rear |
A2X0667400 |
Holder |
A00J600500 |
Coupling |
A00J618002 |
Wiring Cover |
A00JN11D01 |
PFU Relay harness /4 |
A00J660700 |
Washer |
A00J660800 |
Washer |
A2X0R70R00 |
1500-Sheet Paper Feed Assy |
A0P0664000 |
Washer |
A00J563500 |
Clutch |
V118030603 |
screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V116030803 |
Screw |
V233201050 |
pin |
V153030803 |
Screw |
V231200850 |
Pin |
V217060001 |
E Ring |
V127030803 |
screw |
V153031003 |
screw |
V118030403 |
screw |
A00J601402 |
Input Shaft |
A00J605700 |
Ground Plate /2 |
A00J601000 |
Gear 18T |
A00JR7AK11 |
MOUNTING PLATE / LCC FEED DRIVE |
56AA40430 |
SPRING MOUNTING PLATE 1 |
A00J663200 |
Bushing |
56AA40440 |
SPRING MOUNTING PLATE 2 |
A00J618800 |
Ground Plate /Middle |
A00J604701 |
Pulling Spring |
A00J605100 |
Idler Roll |
A00J604800 |
Pulling Spring |
A00J605200 |
Idler Shaft |
A00J601700 |
Shaft |
A2X0667100 |
Mounting Plate |
A00J619611 |
Pulley 14T |
A00J618500 |
Torque limiter |
56AA40490 |
SHAFT STOPPER 4 |
A00J563600 |
Roller |
A00J619500 |
Pulley 15T |
A00J619800 |
Timing Belt 96L |
A00J619700 |
ROLL /1 |
A0P0602100 |
Guide Washer |
A00J601600 |
Multi-feed Adjusting Plate |
A00J601501 |
Mounting Plate /ASSY |
A00J603400 |
Gear 22/14T |
56AA75050 |
CLEANER SHAFT HOLDER |
A00J604101 |
Paper feed Plate |
A0P0663500 |
Input Shaft |
56AA40510 |
PRESSING SPRING |
56AA40450 |
PAPER FEED COUPLING PART |
A00J600900 |
Gear43T |
A0P0664000 |
Washer |
V116030803 |
Screw |
V217040001 |
E Ring |
V153030803 |
Screw |
V233161050 |
pin |
V231200850 |
Pin |
V217060001 |
E Ring |
V116030603 |
Screw |
V231301450 |
pin |
A00J619901 |
Mounting Plate |
56AA83061D |
INTERNAL HEATER |
A00J618400 |
Screw |
A00J613401 |
Slide Rail /A |
A00J608400 |
Mounting Plate |
A00J608600 |
Mounting Plate |
A00J608100 |
Mounting Plate |
A2X0608000 |
Mounting Plate /1 |
A00J608500 |
Mounting Plate |
A00J608200 |
Mounting Plate |
A00J608300 |
Mounting Plate |
A2X0666600 |
Lock Holder |
A2X0665100 |
Lock Holder |
V116030603 |
Screw |
V137040803 |
SCREW |
V205040003 |
washer |
V137030603 |
screw |
A00J609400 |
Guide Part |
4037090201 |
PHOTO INTERRUPTER |
4036596601 |
SCREW |
A00J609501 |
Mounting Plate /F |
A00J572200 |
Roller |
A00J609100 |
Mounting Plate |
A00J617900 |
Ball Bearing |
A00J608700 |
Mounting Plate |
A00J608800 |
Mounting Plate |
A2X0R70200 |
Mounting Plate/Updown Motor Assy |
A0P2N10X00 |
Heater Relay harness |
A2X0M12101 |
Brush motor |
56AA17330 |
SLIDE SHAFT |
56AA17080 |
TERMINAL ROCKING SPRING |
A00J608900 |
Mounting Plate /Rear |
A0P0N11G00 |
PFU Relay harness |
4037090601 |
PHOTO INTERRUPTER |
A00J609000 |
Mounting Plate |
A00J609300 |
Mounting Plate |
A00V240600 |
BALL BEARING |
A00J609800 |
Clutch Assy |
A00JN11C01 |
PFU Relay harness /3 |
A00J609201 |
Mounting Plate |
A00J617000 |
Protection Cover /S |
A00J660700 |
Washer |
V116040803 |
Screw |
V116030603 |
Screw |
V153030803 |
Screw |
V217060001 |
E Ring |
V118040803 |
screw |
V116032003 |
Screw |
V126030603 |
screw |
V217040001 |
E Ring |
A00J613500 |
Up/down Plate |
55VA40930 |
DOUBLE FEED PREVENTIVE PLATE |
A00J623400 |
FRICTION PLATE |
56QA58110 |
LCT UP DOWN WIRE RIGHT FRONT |
A0P0663900 |
Pad |
A00J615101 |
Stopper Plate /1 |
A2X0665300 |
Lock Guide |
A00J663200 |
Bushing |
A00J613700 |
Up/down Pulley |
A0P0618900 |
Regulating Plate /1 |
A0P0663800 |
Gear /1 |
A0P0662700 |
Dumper |
A00J619011 |
Protection Cover |
56QA58041D |
LCT SLIDE BOARD |
56QA58470D |
EXTERNAL PROTECTION PLATE |
A00J613300 |
Sensor Cover |
4037090601 |
PHOTO INTERRUPTER |
A00J660600 |
Protection Sheet |
A00J663100 |
Stopper Rubber |
26NA45440 |
REGISTRATION UNIT FIXED SCREW |
A00J615000 |
Connecting Plate |
A00J613200 |
Guide Plate |
A00JN11B01 |
PFU Relay harness /2 |
A00J619300 |
Receiving Block |
A0P0615600 |
Regulating Plate |
A00J615500 |
Up/down Shaft |
56QA58120 |
LCT UP DOWN WIRE RIGHT REAR |
A00J660300 |
LIGHT BLOCKING PART |
A2X0666900 |
Pressure Spring |
A2X0F63004 |
1000-sheet tray |
A2X0F63104 |
1000-sheet tray |
A2X0666001 |
Lever |
A161626800 |
Pulling Coil spring |
V116030603 |
Screw |
V118020803 |
SCREW |
V217040001 |
E Ring |
V116030803 |
Screw |
V127030603 |
screw |
V232302509 |
pin |
V125040803 |
Screw |
V149030803 |
screw |
55VA40930 |
DOUBLE FEED PREVENTIVE PLATE |
A00J613500 |
Up/down Plate |
A00J623400 |
FRICTION PLATE |
56QA59110 |
LCT UP DOWN WIRE LEFT FRONT |
A0P0663900 |
Pad |
A0P0615200 |
Stopper Plate /2 |
A2X0665800 |
Shaft |
A00J663200 |
Bushing |
A00J613700 |
Up/down Pulley |
A0P0618900 |
Regulating Plate /1 |
A0P0663800 |
Gear /1 |
A0P0662700 |
Dumper |
A00J619011 |
Protection Cover |
56QA58041D |
LCT SLIDE BOARD |
A00J613300 |
Sensor Cover |
A00J660600 |
Protection Sheet |
A00J663100 |
Stopper Rubber |
4037090601 |
PHOTO INTERRUPTER |
26NA45440 |
REGISTRATION UNIT FIXED SCREW |
A00J615000 |
Connecting Plate |
A00J660500 |
Protection Sheet |
A00J613200 |
Guide Plate |
A00JN11A00 |
PFU RELAY HARNESS/1 |
A0P0615700 |
Regulating Plate |
A00J615500 |
Up/down Shaft |
56QA59120 |
LCT UP DOWN WIRE LEFT REAR |
A00J660300 |
LIGHT BLOCKING PART |
A2X0666900 |
Pressure Spring |
A2X0F64004 |
1500-sheet tray |
A2X0F64104 |
1500-sheet tray |
A2X0665401 |
Lever |
A2X0665300 |
Lock Guide |
A2X0665900 |
Lever |
A161626800 |
Pulling Coil spring |
A2X0665600 |
Connecting Shaft /1 |
A2X0665500 |
Connecting Plate |
V116030603 |
Screw |
V118020803 |
SCREW |
V217040001 |
E Ring |
V116030803 |
Screw |
V127030603 |
screw |
V232302509 |
pin |
V127030803 |
screw |
V149030803 |
screw |
V125040803 |
Screw |
56QA58420 |
PULLEY GUIDE PART |
A2X0941701 |
Label |
A00JN11N01 |
PFU Relay harness /8 |
57AA17010 |
WIRE PULLEY |
56QA58060D |
LCT GUIDE PLATE RIGHT |
55VA40610 |
WIRE HOLDER A |
540047200 |
PAPER REGULATING CLAW |
56QA58450 |
PROTECTION COVER |
56QA58050D |
LCT ADJUSTMENT SIDE PLATE |
A00JR7AN00 |
SUPPORT BOARD/ WIRE PULLEY |
A00J613101 |
Mounting Plate |
57AA97870 |
PAPER GUIDE LABEL |
56QA58070D |
SHAFT HOLDING PART |
56QA58490D |
REAR REINFORCE PLATE |
56QA58150 |
PAPER GUIDE SHAFT RIGHT |
A2X0941600 |
Label |
56QA59060D |
LCT GUIDE PLATE LEFT |
56QA59150D |
PAPER GUIDE SHAFT LEFT |
A00J613900 |
Reinforce Plate /Rear |
V116030603 |
Screw |
V217060001 |
E Ring |
V116030803 |
Screw |
V127030603 |
screw |
V217040001 |
E Ring |
V118030603 |
screw |
A0P0594200 |
Bypass Tray /3 |
A00J942500 |
Label |
1134304202 |
SHAFT |
A00J599100 |
Torsion Spring |
A00J585300 |
Actuator |
A00J597911 |
Mounting Plate |
4037090601 |
PHOTO INTERRUPTER |
A2X0597700 |
Mounting Plate |
A00J597800 |
Actuator |
A00J599000 |
Torsion Spring |
A2X0942700 |
Label |
A0P0594300 |
Bypass Tray /4 |
A161M50400 |
VR |
A2X0597200 |
Gear 43T |
A00J597100 |
Rack /L |
A00J596900 |
Gear 18T |
A2X0R70T00 |
Manual Feed Tray Unit |
A00JN11501 |
Paperfeed Relay Harness / 6 |
A00J593600 |
Sensor Plate |
A00J593700 |
Actuator /E |
A00J593800 |
Torsion Spring /E |
A00J594013 |
Bypass Tray /1 |
A2X0586900 |
Mounting Plate |
A2X0942600 |
Label |
A2X0597600 |
Holder |
4036578501 |
SCREW |
A00J597300 |
Mounting Plate |
A00J592500 |
Lifting Lever |
A0P0599600 |
Friction Plate |
A00J594602 |
Lifting Plate |
A00J599300 |
Holding Plate |
A00J595100 |
Holder |
A00J597000 |
Rack /R |
4036365901 |
COLLAR |
A00J594112 |
Bypass Tray /2 |
4131462304 |
CLEANING PAD |
A2X0594500 |
Regulating Plate /R |
A00J587200 |
Brake Part |
A2X0594400 |
Regulating Plate /L |
A2X0942800 |
Scale |
A2X0942900 |
Scale |
V137030803 |
screw |
V111170403 |
screw |
V153030803 |
Screw |
A00J598101 |
Cover /Middle |
A00J586400 |
Holder |
A00J593500 |
Pressure Holder |
A00J593900 |
Compressing Spring |
A00JR7AP00 |
FRAME/BYPASS (FRONT) |
A00J598200 |
Bypass Cover /Front |
A00J588800 |
PLATE SPRING |
A00J594800 |
Torsion Spring |
A00J599200 |
Mounting Plate /F |
A00J598401 |
Lock Lever |
A00J594900 |
Holder |
A00J585500 |
Shaft |
A00J585401 |
Torsion Spring |
A00J585601 |
Mounting Plate |
A00J596602 |
Mounting Plate |
A00J588300 |
Roll |
A00J588200 |
Fixing Plate |
A00J594701 |
Positioning Shaft |
A00J586700 |
Hold Holder |
A00J599800 |
Mounting Plate |
A00J585700 |
Detecting Shaft |
A00J599500 |
Torsion Spring |
A00J598800 |
Set Actuator |
A00J585100 |
Mounting Plate |
4037090601 |
PHOTO INTERRUPTER |
A00J586600 |
Mounting Plate |
A2X0590200 |
Frame |
A00J599700 |
Mounting Plate |
A00J588601 |
Seal |
A108M50100 |
Photointerrupter |
V137030603 |
screw |
V121030803 |
SCREW |
V232302509 |
pin |
V217040001 |
E Ring |
V153030803 |
Screw |
V231301850 |
PIN |
V116030603 |
Screw |
V144030803 |
SCREW |
A2X0595000 |
Support Holder |
4131300301 |
BUSHING |
A00J590500 |
Guide Plate |
A0P0587500 |
Guide Plate /Front |
A00J586201 |
Guide Sheet |
56AA40490 |
SHAFT STOPPER 4 |
4030300301 |
SHAFT |
1067250101 |
PIN |
4425301601 |
GEAR 32T |
A00J563600 |
Roller |
A00J596000 |
Wiring Cover |
A0P0590100 |
Paper feed Holder |
4425301301 |
GEAR 30T |
A00J590300 |
Gear 20T |
4040309701 |
SHAFT |
A00J590400 |
Torsion Spring |
1065308601 |
BUSHING |
A00J590700 |
Paper feed Shaft |
A00J587000 |
Paper feed Coupling |
A00J586100 |
Mounting Plate |
A00J586000 |
Paper feed Shaft |
A00JR7AQ00 |
FRAME /BYPASS (REAR) |
A00J596700 |
Pressing Collar |
A00J595800 |
Gear 15/28T |
A00J592600 |
Gear 14T |
A00J592201 |
Gear 18/29T |
A00J591700 |
Gear 18/35T |
A00J592800 |
Gear 26T |
A00J593000 |
Compressing Coil |
A00J595600 |
Clutch |
V137030603 |
screw |
V217040001 |
E Ring |
V218040086 |
E ring |
V217030001 |
E Ring |
V153030603 |
screw |
V144030803 |
SCREW |
V137030803 |
screw |
A00J598002 |
Bypass Cover/Rear |
A0P0R75200 |
MOTOR ASSY |
A00J593400 |
Mounting Plate |
A00JR7AR00 |
MOUNTING PLATE / BYPASS 1 |
A00J591800 |
Gear 22T |
A0P0598300 |
Shutter |
A00J587600 |
Guide Sheet |
4036141001 |
SHOULDER SCREW |
A0P0596500 |
Bypass Holder /Front |
A0P0597400 |
Guide Sheet |
A00J589100 |
Guide Sheet |
A00J587701 |
Reinforce Plate |
A2X0591200 |
Mounting Plate |
A00J587300 |
Pulling Spring |
4131300301 |
BUSHING |
56AA40490 |
SHAFT STOPPER 4 |
4030303901 |
SHAFT |
A2X0592000 |
Guide Plate |
A00J591014 |
Mounting Plate /S |
A00J591100 |
Compressing Spring |
A00J590901 |
Holder /S |
A00J597511 |
Guide Part |
A0P0R74100 |
Fieldroller/1 assy |
4030312501 |
TENSION SPRING |
A00J591300 |
Reinforce Plate |
A00J585800 |
Seal |
A00J593101 |
Gear 14/24T |
A00J593300 |
Gear 14/50T |
A00J587901 |
Mounting Plate /Rear |
A2X0N11401 |
Paperfeed Relay harness / 5 |
A0P0588112 |
Mounting Plate /ASSY |
A00J598600 |
Support Shaft |
A0P0588700 |
Cover |
A00J595702 |
Mounting Plate /ASSY |
A2X0M10000 |
Stepping motor |
A00J596300 |
Mounting Plate /ASSY |
A00J586300 |
Wiring Holder |
A00JR7AS00 |
MUUNTINGPLATE/
BYPASS2 |
A0P0R72911 |
Bypass field roller assy |
A2X0599900 |
Holder |
A2X0584100 |
Torsion Coil spring |
A2X0584000 |
Torsion Coil spring |
V137030803 |
screw |
V127030803 |
screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V217030001 |
E Ring |
V118030803 |
screw |
V118030603 |
screw |
V137030603 |
screw |
V217060001 |
E Ring |
V116041203 |
Screw |
V121030804 |
screw |
V115260503 |
Screw |
A00J706800 |
Compressing Spring |
4025353401 |
PRESSURE SPRING |
A00J701500 |
Conveyance Duct |
A00J709100 |
Seal |
A00J701800 |
Suction Seal |
A00J701701 |
Cover |
A00J702400 |
Mounting Plate |
A00J711301 |
Lever /1 |
A00J711700 |
Compressing Spring |
A00J711500 |
Hold Plate |
4036367502 |
LEVER |
1164352702 |
TORSION SPRING |
A00J701000 |
Pulling Spring |
A00V240600 |
BALL BEARING |
A00J700600 |
Gear 20T |
A00J702700 |
Gear 14T |
4025357201 |
BUSHING |
A00J701900 |
Ground Contact |
A00J704700 |
Guide Film |
4025356801 |
NETURALIZING MEMBER |
A00J707801 |
Compressing Spring |
A00JR90100 |
PHOTO INTERRUPTER |
A00J704600 |
Guide Film |
A00J701600 |
Neutralizing Holder |
A00J704200 |
Guide Film |
A00J700201 |
Roller |
A00J700100 |
Roller |
A00J701200 |
Guide Plate |
A00JR7AT00 |
MOUNTING PLATE / PAPER EXIT CONVEYANCE |
1164350901 |
BUSHING |
A00J700501 |
Gear 34/17T |
A2X0948800 |
Seal |
A00J703001 |
Positioning Holder |
A00J706900 |
Rotation Knob |
A00J700301 |
Gear 26T |
A00J700900 |
Collar |
A00J702000 |
Wiring Cover |
A2X0M10500 |
Stepping motor |
A108M50100 |
Photointerrupter |
1164350403 |
ACTUATOR |
A2X0R71C00 |
Conveyance Holder Assy |
V153030803 |
Screw |
V218030086 |
E ring |
V217060001 |
E Ring |
V217040001 |
E Ring |
V149030803 |
screw |
V116030603 |
Screw |
A2X0710200 |
Mounting Plate |
A2X0713200 |
Timing Belt 152L |
A2X0713100 |
Pulley 16T |
A0P0R75400 |
Motor Assy |
4025490701 |
GEAR 16/40T |
4025491001 |
GEAR 12/40T |
A2X0708200 |
Contact |
9454407602 |
RESISTOR |
A2X0713400 |
Ground Plate |
A00JR7AU11 |
2ND TRANSFER RETRACTION DRIVE |
4025490801 |
GEAR 15T |
4025490901 |
GEAR 15T |
4036491101 |
PIN |
A00J710800 |
Compressing Spring |
4004472202 |
WASHER |
1144520001 |
PIN |
4004471002 |
CAM |
4036471201 |
ARM |
4004472301 |
WASHER |
4025472501 |
TORSION SPRING |
A00J711400 |
Cam /1 |
A00J708100 |
Ground Plate |
4036473001 |
BUSHING |
A0P0R71911 |
2nd transfer roller assy |
A0P0R73111 |
Removal guide assy |
4025471902 |
TORSION SPRING |
A0P0710501 |
Arm /Rear |
A00J708700 |
Contact |
A00J710400 |
Support Shaft |
A2X0N11000 |
Conveyance Wiring |
4025472001 |
DETECTING PLATE |
4025470902 |
SHAFT |
A2X0713000 |
Mounting Plate |
A0P0710600 |
Arm /Front |
A2X0708800 |
Contact |
A00J710700 |
Mounting Plate |
A108M50100 |
Photointerrupter |
A0P0709100 |
Contact |
A00J708400 |
Contact |
A00J708900 |
Contact |
A00J708300 |
Contact |
V153030803 |
Screw |
V115260503 |
Screw |
V217040001 |
E Ring |
V217060001 |
E Ring |
V217050001 |
E ring |
V217030001 |
E Ring |
V116030603 |
Screw |
V137030603 |
screw |
V149030803 |
screw |
A2X0709700 |
Spring |
A00J893100 |
Compressing Spring |
A2X0705101 |
Conveyance Cover /Right |
A00JN11101 |
Conveyance Relay harness /1 |
A00J815711 |
Cushion |
A2X0713300 |
Holder |
A2X0901000 |
Mounting Plate /Front |
4036365901 |
COLLAR |
A00J892202 |
Mounting Plate |
A00J705800 |
Shoulder screw |
A00J705700 |
Reinforce Plate /Front |
A00J705200 |
Guide Film |
A00J705900 |
Wiring Cover |
A0P0712200 |
Contact |
A2X0R71D00 |
Paper Exit Conveyance Door Assy |
A00J706200 |
Open/close Lever /Right |
A00J706500 |
Lock Lever /F |
4036359002 |
TORSION SPRING |
A00J706400 |
Mounting Plate |
9313100072 |
FAN MOTOR |
A00J705600 |
Conveyance Duct |
A00J708000 |
Reinforce Plate |
A00J706600 |
Lock Lever/R |
A00J706700 |
Support Plate |
4138586601 |
LABEL HI-TEMP CAUTION |
A2X0709400 |
Protection Part |
A2X0709300 |
Protection Part |
A2X0899600 |
Protection Part |
A00J707300 |
Support Shaft |
A2X0900900 |
Mounting Plate /Rear |
A0P0709000 |
Mounting Plate |
A2X0713500 |
Protection Part |
V153030803 |
Screw |
V116030803 |
Screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V137030603 |
screw |
A00J704100 |
Sensor Cover |
A00J711101 |
Sensor Shutter |
A00J702901 |
Guide Stopper |
A00J703600 |
Shoulder screw |
A0P0702200 |
Guide Plate |
4025367601 |
PIN |
A00J704500 |
Wiring Cover |
A00J702101 |
Guide Holder /Left |
4036367301 |
LEVER |
A00J711601 |
Lever |
4025367402 |
HOLD PLATE |
A00J702600 |
Guide Shutter |
A0P0M50400 |
Humidity sensor |
V869900045 |
PHOTO SENSING ELEMENT |
A00JN12201 |
Sensor Relay harness /4 |
A00J707200 |
Hold Wire /Front |
A00J706100 |
Torsion Spring |
4643460501 |
SHOULDER SCREW |
A00J704400 |
Sensor Cover /2 |
A00J703700 |
Plate spring /2 |
4025355601 |
TENSION SPRING |
A00J702811 |
Reinforce Plate |
A00J702500 |
Plate spring /1 |
A00J703800 |
Plate spring /3 |
9454407602 |
RESISTOR |
4036355701 |
STOPPER |
4002504202 |
PLATE NUT |
A0P0R75000 |
GUIDE ASSY |
V153030803 |
Screw |
V137030603 |
screw |
A00J707501 |
Guide Wire |
A0P0707701 |
Holder |
A00J709000 |
Guide Plate |
A0P0103300 |
Shaft |
A108M50100 |
Photointerrupter |
A0P0103902 |
Holder |
A0P0107500 |
Actuator |
A0P0103401 |
Torsion Spring |
A0P0104001 |
Actuator |
A0P0102901 |
Guide Plate |
A0P0M50000 |
Temp. transfer |
A2X0107300 |
Guide Holder |
A2X0107500 |
Guide |
A2X0104800 |
Guide |
A00J707102 |
Hold Wire /Rear |
4004351202 |
FLANGE |
A0P0707600 |
Open/close Spring |
A0P0N12H00 |
Sensor Relay harness /2 |
A2X0N10U00 |
Temperature Detection harness |
V137030803 |
screw |
V116030803 |
Screw |
V116030603 |
Screw |
A2X0R71011 |
Fusing Unit |
A2X0M40200 |
Fixing Coil /100V |
A2X0M40300 |
Fixing Coil /230V |
A2X0145700 |
Mounting Plate |
A2X0N10201 |
Main body Relay harness / Upper |
A2X0138500 |
Shoulder screw |
A2X0890600 |
Sealing Part |
V116030603 |
Screw |
A00J810302 |
Handle |
4497310603 |
PRESSURE SPRING |
A00J814600 |
Guide Part /Front |
A2X0810400 |
Cover /Front |
A0P0812800 |
Gear 48T |
4131300301 |
BUSHING |
A00JR7AV00 |
MOUNTING PLATE /B |
A0P0812900 |
Gear 22/48T |
A00J813000 |
Belt 248L |
1200164603 |
WASHER |
A00J813600 |
Roll |
A00J812400 |
Torsion Spring /Lower |
910362001 |
STOP RING |
A00J812300 |
Lever |
A00J812200 |
Pulley 26T |
4657371301 |
PULLEY 22T |
A00JR7AW00 |
MOUNTING PLATE /D |
A00JR7AX11 |
MOUNTING PLATE /C |
A00J811000 |
Roller /4 |
A00J814101 |
Roll |
A00J814411 |
Shaft |
A00J814500 |
Spring |
A2X0810101 |
Duplex Base frame |
A00J811800 |
Actuator /Upper |
4657373501 |
TORSION SPRING |
A00J810800 |
Roller /1 |
1067250101 |
PIN |
A00J815101 |
Knob |
A00JR7AY00 |
MOUNTING PLATE /A |
A00J812100 |
Torsion Spring /Upper |
A00J811200 |
Pulley 22T |
A00J815200 |
Lever |
A00J811600 |
Belt 306L |
A00J816400 |
STOPPER |
A00J814700 |
Guide Part /Rear |
A2X0810500 |
Open/close Cover |
A00J815801 |
Compressing Spring |
V153030803 |
Screw |
V217040001 |
E Ring |
V217030001 |
E Ring |
A00J810201 |
Cover /Upper |
A00J816300 |
Guide Film |
A00J813200 |
Actuator |
4657373401 |
TORSION SPRING |
A2X0949000 |
Label |
A00J812000 |
Sensor Plate /Lower |
A00J811900 |
Actuator /Lower |
4657373501 |
TORSION SPRING |
A00J810713 |
Cover /Lower |
A00J814101 |
Roll |
A00J814411 |
Shaft |
4036596601 |
SCREW |
A00J814500 |
Spring |
A00J816200 |
Reinforce Plate |
A108M50100 |
Photointerrupter |
A00J815400 |
Wiring Cover |
4131300301 |
BUSHING |
A00J813800 |
Gear 25T |
A00J813900 |
Pulley 33/25T |
A2X0813300 |
Sensor Plate /Middle |
A00J811100 |
Belt 160L |
A00JR7B000 |
DRIVE FRAME / LOWER |
A2X0M10600 |
Stepping motor |
A0P0816600 |
Protection Film |
A00J810601 |
Cover/Rear |
A00J816100 |
Lever |
A00J815300 |
Hook |
A2X0N11300 |
ADU Wiring |
A00JR7B100 |
DRIVE FRAME / UPPER |
4657374301 |
TIMING BELT 134L |
A00J812600 |
Sensor Plate /Upper |
A2X0M10700 |
Stepping motor |
A2X0816900 |
Contact /3 |
A0P0817000 |
Contact /4 |
A0P0816700 |
Contact /1 |
A2X0816800 |
Contact /2 |
V153030803 |
Screw |
V217040001 |
E Ring |
V116030603 |
Screw |
V121030804 |
screw |
V218030086 |
E ring |
V217030001 |
E Ring |
V125041001 |
Screw |
A00J891801 |
Paper exit Cover |
A00J898900 |
Cover |
4036596601 |
SCREW |
9J06M10000 |
FAN MOTOR |
A1DMN11200 |
Conveyance Relay harness /1 |
A2X0R71B00 |
Cooling Fan Assy |
A00J892101 |
Guide Plate |
A2X0901100 |
Roll |
A00J892300 |
Paper exit Actuator |
A00J892712 |
Sensor Plate |
A00J898400 |
Cover |
A108M50100 |
Photointerrupter |
A00J899711 |
Protection Part |
A00J894000 |
Contact |
4030309301 |
BUSHING |
A00J897800 |
Shaft |
A00J894200 |
Contact |
A00J892600 |
Plate spring /1 |
A0P0897600 |
Protection Part |
A00J892001 |
Reinforce Plate |
A2X0892400 |
Guide Plate |
A00J897100 |
Pin |
A00J897000 |
Roll |
A0P0900201 |
Bushing |
A00J896300 |
Gear 15T |
A00J896100 |
Gear 16T |
A00JR7B200 |
MOUNTING PLATE / 1ST EXIT |
A2X0892900 |
Guide Plate |
A2X0R71700 |
Mounting Plate/Exit Assy |
A2X0898300 |
Roller |
A0P0900100 |
Mounting Plate |
4036591301 |
TORSION SPRING |
A0P0900700 |
Compressing Coil spring |
4004598701 |
BUSHING |
A2X0900500 |
Cushion |
V153030804 |
screw |
V153030803 |
Screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V116031003 |
Screw |
V137030803 |
screw |
A2X0M10800 |
Stepping motor |
A0P0R7A400 |
Mounting plate / Paper exit motor |
A00J891100 |
Gear 16/26T |
A0P0891000 |
Idler Gear 22T |
A0P0896600 |
Mounting Plate |
A00J895100 |
Gear 16T |
4030309301 |
BUSHING |
A2X0890701 |
Paper exit Roller |
A00J896801 |
Mounting Plate |
A00J898001 |
Plate spring |
A00J898101 |
Plate spring |
A00J899101 |
Contact |
A00J890512 |
Guide Lever |
4030382301 |
BUSHING |
A0P0900411 |
Pulling Coi spring |
A00J891200 |
Mounting Plate |
A00J898200 |
Cover |
A00J896500 |
Shoulder screw |
A00JR7B500 |
REVERSAL UPPER STAKE |
A00J893800 |
Pulling Spring |
4004590301 |
ROLL |
4025598401 |
SHAFT |
4036596601 |
SCREW |
A0P0890200 |
Mounting Plate |
A2X0R71100 |
Riverse Unit |
A2X0890600 |
Sealing Part |
A0P0900600 |
Timing belt 86L |
A00J893512 |
Riverse/exit Cover |
A00J897401 |
Neutralizing Brush |
A02E890700 |
Neutralizing brush |
A00J899500 |
Shoulder screw |
A0P0893911 |
Riverse/exit Roller |
4004590301 |
ROLL |
A00J890411 |
Bushing |
4011585202 |
SHOULDER SCREW |
4030309301 |
BUSHING |
A00J899200 |
Contact |
A00J896412 |
Contact |
A00J893413 |
Guide Plate |
A00J899301 |
Plate spring |
4025598401 |
SHAFT |
A00J893201 |
Plate spring |
A00J893601 |
Mounting Plate |
A00J893311 |
Guide Plate |
A00J898500 |
Guide Part |
4025593901 |
PULLEY 24T |
1200164603 |
WASHER |
A0P0900800 |
Cushion |
V153030803 |
Screw |
V217040001 |
E Ring |
A2WU220800 |
Gear 88T |
A2WU220300 |
Transfer Shaft |
A00V240600 |
BALL BEARING |
A00J220600 |
Transfer Frame /C |
4036351701 |
GUIDE |
A00JR7B700 |
TRANSFER FRAME/B |
1164306501 |
STOPPER RING |
A2WU220100 |
Gear 59T |
A0P0228900 |
Reinforce Plate /T |
A0P0228100 |
Transfer Gear /M 55/34T |
A2X0228500 |
Pulling Coil spring |
A0P0228700 |
Transfer Shaft /B |
A0P0228200 |
Transfer Gear /Y 20T |
A0P0228400 |
Transfer Frame /E |
A0P0R7A600 |
Transfer freme / F |
A161M10200 |
brushless Motor /20 |
9314230021 |
MOTOR |
A2XKM10300 |
Brushless motor |
A0P0M90000 |
Ferritecore |
A00J225100 |
Gear 22/33T |
A02EM10C01 |
Stepping motor |
A00JR7B600 |
TRANSFER FRAME/D |
A00J225000 |
Gear 16/64T |
A2X0R70600 |
Main Drive Assy |
A2WU221001 |
Flange |
A00JM11000 |
Brushless motor /15 |
A2WU220000 |
Gear 44/60T |
4004254701 |
PIN |
A2WU220400 |
Transfer Frame /A |
A00JM11300 |
Brushless motor /12 |
A2WU220901 |
Flange |
A2WU221200 |
Spacer |
V116030603 |
Screw |
V223120050 |
C ring |
V137030603 |
screw |
V137030803 |
screw |
V217040001 |
E Ring |
V217030001 |
E Ring |
V237301850 |
Pin |
V118030503 |
screw |
A0P0M11500 |
Brushless motor /30 |
4036225801 |
SHOULDER SCREW |
4004224802 |
PRESSURE SPRING |
4036224102 |
Bracket |
9J06M60100 |
MICRO SWITCH |
4004258201 |
TENSION SPRING |
A00J138000 |
Mounting Plate |
A00J232011 |
Fusing Frame /3 |
A00J230000 |
Gear 52/30T |
A00J232400 |
PLATE SPRING |
A00J230100 |
Gear 38/38T |
A00J231200 |
Fusing Shaft /1 |
A00J230711 |
Gear 33T |
A00J231812 |
Paper exit Shaft /1 |
A00J232111 |
Paper exit Bearing /1 |
A00J230800 |
Gear 18T |
A00J230500 |
Gear 23T |
A161254600 |
Gear |
A00V240600 |
BALL BEARING |
A2X0231000 |
Fusing Frame /2 |
A2X0235400 |
Pressure Shaft |
A2X0R70800 |
Fusing Drive Assy |
4036252401 |
BUSHING |
A2X0236100 |
Support Part |
A161M10300 |
Stepping motor |
A2X0R70900 |
Fusing Drive Frame Assy |
A2X0235600 |
Gear 21/42T |
A2X0235100 |
Gear 21/115T |
A2X0235500 |
Gear 28/53T |
A2X0R70N00 |
Fusing Retractio Drive Assy |
A2X0235900 |
Gear 38T |
A00J230300 |
Gear 30T |
A2X0230600 |
Gear 61/62T |
A00J230200 |
Gear 35/23T |
A0P0232500 |
Bushing |
A2X0231500 |
Fusing Shaft /2 |
A00J230400 |
Gear 30T |
A00J232200 |
Fusing Knob /1 |
V116030603 |
Screw |
V237301850 |
Pin |
V116031603 |
Screw |
V217040001 |
E Ring |
V217030001 |
E Ring |
V137030603 |
screw |
V231201050 |
pin |
V217060001 |
E Ring |
V118030603 |
screw |
V115030603 |
Screw |
A00J403100 |
Drive Gear /3 40T |
A00J403000 |
Drive Gear /2 75/40T |
A00J402601 |
Drive Holder /Right |
A00J402900 |
Drive Gear /1 70/35T |
A00J404000 |
Gear 40T |
4038541101 |
SPRING |
A2X0404100 |
Joint |
4038541301 |
GUIDE |
4038540701 |
COLLAR |
4038541202 |
PRESSURE SPRING |
A00J402801 |
Fixing Plate /Right |
9314130021 |
MOTOR |
A00J403800 |
Fixing Plate /Left |
A00J403700 |
Gear 40T |
A00J402711 |
Drive Holder /Left |
A2X0N10900 |
Drive Wiring /1 |
A2X0R70D00 |
Bottle Drive (C/BK) Assy |
A2X0R70C00 |
Bottle Drive (Y/M) Assy |
A00J142900 |
Protection Plate |
A2X0N10P00 |
Drive Wiring /2 |
V116030603 |
Screw |
V145030803 |
screw |
A2X0M10900 |
Stepping motor |
A00J895000 |
Mounting Plate |
A00J896000 |
Mounting Plate |
A2X0R71200 |
Paper Exit Belt Drive Assy |
A00J895200 |
Pulley 24/29T |
A00J894300 |
Timing belt 210L |
1200164603 |
WASHER |
4004533901 |
BUSHING |
A00J895700 |
Gear 21/34T |
A2X0894900 |
Mounting Plate /ASSY |
A2X0897701 |
Cover |
A00J899400 |
Pulling Spring |
A0P0897300 |
Cam |
A00J894600 |
Gear 16T |
A00J897200 |
Shaft |
A00J895300 |
Gear 16T |
A0P0900001 |
Bushing |
A2X0894800 |
Shaft |
A00J894400 |
Gear 21T |
A00J894500 |
Gear 21T |
V137030603 |
screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V116030803 |
Screw |
A0P0105100 |
Hold Plate /1 |
A0P0165500 |
Cover Handle |
A0P0105200 |
Hold Plate /2 |
A00J595200 |
Mounting Plate /ASSY |
A00J102402 |
Mounting Plate |
A0P0105300 |
Mounting Plate |
A0P0138200 |
Cover |
A0P0138300 |
Cover |
A00J106500 |
Plate |
A0P0109001 |
Castor |
4556M10000 |
FAN MOTOR |
A00J137701 |
Mounting Plate |
A0P0135400 |
Mounting Plate |
4038M60000 |
SEESAW-SWITCH |
A00J134500 |
Mounting Plate |
A2X0104301 |
Mounting Plate |
A00J101400 |
Stay /Lower |
A0P0101311 |
Stay /Upper |
A0P0104600 |
Rubber foot |
A00J106400 |
Plate |
A00J104400 |
Mounting Plate |
9J03M10000 |
FAN MOTOR |
A00J105400 |
Mounting Plate |
A00J164600 |
Cover Handle |
A0P0M50300 |
Thermistor |
A00J101603 |
Side plate /Middle |
A0P0N12P00 |
Temperature Relay harness |
A0P0148701 |
Cover |
957149101 |
LABEL |
A2X0101500 |
Side plate /Upper |
A0P0109300 |
Sealing Part /2 |
A2X0154001 |
Mounting Plate |
A00J102700 |
Mounting Plate |
A00J586800 |
Guide Holder |
A0P0102000 |
Seal |
A2WU156400 |
Seal |
V137040803 |
SCREW |
V137030603 |
screw |
V116030603 |
Screw |
V153030803 |
Screw |
V121040603 |
screw |
V137030803 |
screw |
V116033003 |
Screw |
A0P0125211 |
Mounting Plate |
A00J121700 |
Protection Sheet /Black |
1079221901 |
SHOULDER SCREW |
A00J941201 |
Label |
A00J121600 |
Protection Seal |
A2X0N12701 |
Developing Relay harness |
A00J155300 |
Mounting Plate |
A0P0144000 |
Mounting Plate |
A0P0155100 |
Duct |
A0P0159100 |
Seal |
9313110033 |
FAN MOTOR |
A0P0R75200 |
MOTOR ASSY |
A0P0109100 |
Mounting Plate |
A00J123400 |
Collar |
A00J123300 |
Gear 22T |
A00J123200 |
Coupling |
A108M50100 |
Photointerrupter |
A0P0125100 |
Mounting Plate |
V116030603 |
Screw |
V115260503 |
Screw |
V116030803 |
Screw |
V153030803 |
Screw |
V217020001 |
E ring |
V153044503 |
SCREW |
V137030803 |
screw |
A0P0150100 |
Duct |
A0P0150400 |
Seal |
9313100072 |
FAN MOTOR |
A0P0151100 |
Sealing Part |
A0P0150200 |
Mounting Plate |
A00J150600 |
Mounting Plate |
A00J157200 |
Duct /2 |
A2X0157500 |
Sealing Part |
A00J157100 |
Duct /1 |
A00J157301 |
Duct /3 |
A00J157401 |
Duct /4 |
A00J157501 |
Duct /5 |
A0P0157700 |
Duct |
A00J157901 |
Mounting Plate |
A00J157600 |
Duct /6 |
A0P0150300 |
Duct |
A0P0150500 |
Mounting Plate |
A0P0M14200 |
Fan motor |
A00J151002 |
Mounting Plate |
A2X0157600 |
Sealing Part |
V137030603 |
screw |
V116043503 |
Screw |
V153030803 |
Screw |
V137030803 |
screw |
V116030603 |
Screw |
A0P0R70100 |
Smoke suction filter assy |
A00J154801 |
Seal |
A0P0153300 |
Duct |
4556M10000 |
FAN MOTOR |
A2X0154501 |
Duct |
A2X0152600 |
Duct |
A2X0154800 |
Seal |
A2X0153700 |
Seal |
A2X0110200 |
Seal |
A00J152700 |
Seal |
A2X0152100 |
Duct |
A2X0132200 |
Mounting Plate /ASSY |
A2X0153100 |
Mounting Plate |
A2X0154900 |
Seal |
A00J154600 |
Mounting Plate |
4036248501 |
SEAL |
9313100072 |
FAN MOTOR |
V116043503 |
Screw |
V153030803 |
Screw |
V137030803 |
screw |
V116030603 |
Screw |
V116030803 |
Screw |
A2WU156900 |
Seal |
A1DM403300 |
Guide Plate /B |
A1DM403200 |
Guide Plate /A |
A2WU156700 |
Seal |
A00J403402 |
Guide Plate /C |
9334261012 |
REED SWITCH |
A00J135800 |
Mounting Plate /B |
9J06M60100 |
MICRO SWITCH |
A00J134600 |
Shoulder screw |
A00J136500 |
Torsion Coil |
A00J135201 |
Mounting Plate |
A2X0N10B00 |
Toner Relay harness |
V116030603 |
Screw |
V118030603 |
screw |
V116031603 |
Screw |
V116030803 |
Screw |
A00J135100 |
Mounting Plate |
A2X0M40800 |
High voltage unit /2 |
A00J132600 |
Guide Rail |
A00J140900 |
Cover |
A00J137800 |
Guide Holder |
A00J132102 |
Guide Rail |
A00J135500 |
Guide Rail |
A0P0132300 |
Guide Rail /Right |
A2X0M40700 |
High voltage unit /1 |
A00J132700 |
Rail /Right |
A00J134000 |
Mounting Plate |
V116030603 |
Screw |
V116030803 |
Screw |
V153030803 |
Screw |
V137030803 |
screw |
V137030603 |
screw |
A0P0148801 |
Plate spring |
A2X0158800 |
Protection Sheet |
A2X0132400 |
Cover |
A2X0R70300 |
Main Power (100V) Assy |
A2X0R70400 |
Main Power (200V) Assy |
A2X0143500 |
Protection Sheet |
V116030603 |
Screw |
A0P0148300 |
Cover |
A0P0149700 |
Cover |
A00J140600 |
Shaft |
A00J133101 |
Mounting Plate |
A2X0N15601 |
Interface Cable |
A2X0N15400 |
Interface Cable /1 |
A00J133500 |
Mounting Plate |
A00J139400 |
Mounting Plate |
A2X0M14000 |
Fan motor |
A2X0144200 |
Mounting Plate |
V116030603 |
Screw |
V153030803 |
Screw |
V116040803 |
Screw |
V116033003 |
Screw |
A2X0N10T00 |
DC Power source harness /3 |
A161138601 |
Shoulder screw |
A161H00C01 |
PWB Assembly(PWB-DC ASSY) |
A00J138700 |
Cover |
A2X0H00102 |
PWB Assembly(PWB-MC ASSY) |
A161N15500 |
Interface Flatcable |
A4MG130900 |
Shoulder screw |
A2X0N12F00 |
Control Relay harness /2 |
A161H02A00 |
PWB assembly(PWB-DS ASSY) |
A0P0144300 |
Shoulder screw |
A0P0144400 |
Bushing |
A161139901 |
Shoulder screw |
A0P0N15100 |
Cable |
A0P0N15200 |
Cable |
A2X0M72C00 |
HDD |
A161132400 |
Mounting Plate |
A161137600 |
Shoulder screw |
V865300050 |
MEMORY MODULES |
A2XKH02004 |
PWB assembly(PWB-MFP ASSY) |
A161139400 |
Mounting Plate |
A108M50100 |
Photointerrupter |
A2X0133000 |
Mounting Plate /ASSY |
A161139500 |
Cover |
A161139800 |
Cover |
A0P0149100 |
Shoulder screw |
4025228301 |
SCREW |
A2X0130401 |
Mounting Plate /ASSY |
A2X0N12X00 |
Controller Relay harness / 2 |
A2X0N12R00 |
Controller Relay harness / 1 |
V144030603 |
Screw |
V116030603 |
Screw |
A2WU133900 |
Cover |
A2X0N12E00 |
Control Relay harness /1 |
V502010026 |
SUPPORT |
A00J136302 |
Mounting Plate |
A2X0H00200 |
PWB Assembly(PWB-KH ASSY) |
A0P0133800 |
Mounting Plate /ASSY |
A0P0133701 |
Stay |
A2X0145500 |
Mounting Plate |
A2X0M40900 |
High voltage unit /3 |
V116030603 |
Screw |
V137040803 |
SCREW |
V153030803 |
Screw |
V116040803 |
Screw |
4037077501 |
POWER CORD |
V502010056 |
Circuit Board Spacer |
A2X0101800 |
Mounting Plate |
A2XKM40G00 |
Board /100V |
A2XKM40H00 |
Board /230V |
V502010033 |
spacer |
A2X0H00X00 |
PWB Assembly(PWB-DHR ASSY) |
A00HN10K11 |
AC Relay harness /5 |
A2X0N10701 |
AC Relay harness /1 |
A00J139100 |
Cover |
4037223902 |
BRACKET |
A00J139000 |
Cover |
A00JM60300 |
Rocker switch |
A00J134702 |
Mounting Plate |
A00J140401 |
Protection Part |
9J06730101 |
LABEL |
A1MT140100 |
Protection Part |
56AA84520 |
Power Source Transfomer |
A00J136400 |
Mounting Plate |
A2X0101700 |
Mounting Plate |
A0P0N30000 |
Power source Cord /120V |
A00J138900 |
Cover |
V116030603 |
Screw |
V116030803 |
Screw |
V116040803 |
Screw |
A0P0134300 |
Cover Holder |
A2X0135700 |
Guide Cover |
A2X0145800 |
Mounting Plate |
A0P0149800 |
Protection Seal |
A0P0141300 |
Protection Cover |
A2X0145900 |
Cover |
A2XKM40A00 |
Power source /100V |
A2XKM40B00 |
Power source /230V |
A0P0131301 |
Cover |
A0P0149000 |
Mounting Plate |
A2X0158901 |
Sheet |
V502010061 |
Spacer |
A2X0H00W01 |
PWB Assembly(PWB-CR ASSY) |
A2X0131500 |
Mounting Plate /ASSY |
A2X0N12D00 |
Fixing Wiring /2 |
A2X0N10V01 |
AC Wiring /2 |
V116030803 |
Screw |
V126030603 |
screw |
V116030603 |
Screw |
V116040803 |
Screw |
V153040803 |
screw |
A2X0N10001 |
Main body Wiring /1 |
A2X0N10101 |
DC Power source harness /1 |
A2X0N10300 |
Paperfeed Control harness |
A2X0N10400 |
PFU Wiring |
A2X0N10501 |
AC Wiring /1 |
A2X0N10601 |
AC Wiring /1 |
A2X1N10A00 |
Main body Wiring /2 |
A2X0N10A00 |
Main body Wiring /2 |
A2X0N10E00 |
DC Power source harness /2 |
1038400601 |
INSULATING MEMBER |
1050480501 |
INSULATING MEMBER |
1052430102 |
Insulating Member |
1053481201 |
CORD CLAMP |
1065587202 |
CORD CLAMP |
9384160011 |
P-CLIP 10D |
V500010003 |
Saddle |
V500010005 |
saddle |
V500010007 |
saddle |
V500010008 |
saddle |
V500010013 |
saddle |
V500010015 |
saddle |
V500010020 |
Saddle |
V500010022 |
saddle |
V500010023 |
clip |
V500010046 |
saddle |
V500010052 |
SADDLE |
V500010053 |
SADDLE |
V500010054 |
SADDLE |
V500010055 |
SADDLE |
V500010061 |
saddle |
V500020011 |
clip |
V500020037 |
clamp |
V500020038 |
clamp |
V500020039 |
clamp |
V500020069 |
Clamp |
V500020077 |
wabe Clamp |
V500020082 |
Clamping for FFC |
V500020091 |
Clamp |
V500020094 |
FG Clamp |
V501010001 |
band |
V501010018 |
BAND |
V570010021 |
Saddle |
V570010023 |
saddle |
V570010025 |
saddle |
V570010026 |
saddle |
V570010027 |
saddle |
V570010028 |
saddle |
V570010031 |
holder |
V570010046 |
SADDLE |
V570010047 |
SQUARE CLAMP |
V500020052 |
bushing |
9J06PJG100 |
JIG |
A0P0989900 |
Packing Parts |
A0P0165900 |
Read Cover /Left |
A00J166101 |
Installing Spacer |
V503010002 |
Connector Cover |
A00J169100 |
Cover |
A02E167700 |
Cover |
A00J169901 |
Holder |
A161947000 |
Label |
A2X0943000 |
Label |
A2X0943100 |
Label |
V121030803 |
SCREW |
A00J940100 |
Label Legal Restiriction |
A00J106202 |
Cleaning Pad |
A161R70400 |
CLEANING MATERIAL |
4040078001 |
POWER CORD |
A161192000 |
Panel |
A4MF131300 |
Cover |
127A90020 |
MODULAR WIRING 1 |
A161N15D00 |
Wiring /2 |
A4MF131500 |
Sheet |
A4MF131200 |
Mounting Plate |
A4MF131400 |
Sheet |
A22MH01A1B |
CONTROL BOARD ASSY |
A22MH01W1B |
CONTROL BOARD ASSY |
A161N15800 |
Interface Cable |
A2X0N15A00 |
Interface Cable /2 |
A161N15900 |
Power source Cable |
A2X0N15B00 |
Power source Cable /2 |
V570010057 |
Wing Edge Saddle |
V500010047 |
saddle |
15MY73110 |
TERMINAL PROTECT COVER |
A4MF131600 |
Sheet |
V116030603 |
Screw |
V207030001 |
washer |
A0P0148500 |
Mounting Plate /1 |
A0P0947600 |
Label |
A0P0N15400 |
Cable |
A0P0148401 |
Mounting Plate /2 |
A0P0M72600 |
Speaker |
A0P0148600 |
Holding Plate |
A0P0H02700 |
PWB assembly(PWB-HUB ASSY) |
V111020603 |
screw |
V116030603 |
Screw |
V500010003 |
Saddle |
V500010023 |
clip |
A0P0148500 |
Mounting Plate /1 |
A0P0947600 |
Label |
A0P0N15400 |
Cable |
A0P0148403 |
Mounting Plate /2 |
A0P0M72600 |
Speaker |
A0P0148600 |
Holding Plate |
A0P0H02700 |
PWB assembly(PWB-HUB ASSY) |
A0P0149500 |
Spacer |
A0P0M72500 |
Unit |
A0YC130200 |
Protection Film |
A0YC130100 |
Cover |
V111020603 |
screw |
V116030603 |
Screw |
V195020003 |
nut |
V500010003 |
Saddle |
V500010023 |
clip |
A161H02801 |
PWB assembly(PWB-EIF ASSY) |
A4MG130900 |
Shoulder screw |
A00J139800 |
SHOULDER SCREW |
A0YEN30001 |
Power code |
A4MG131000 |
Mounting Plate |
A4MG131100 |
Mounting Plate |
A02E147900 |
Bracket |
V116040803 |
Screw |
V116031604 |
Screw |
V116034003 |
Screw |
A0G5620100 |
Tray /ASSY |
4069620701 |
GUIDE |
A0G5940100 |
Label Set Tray |
A00J566700 |
Guide Sheet /2 |
4069620500 |
SPACER |
4069620600 |
PLATE SPRING |
V153030803 |
Screw |
V153030603 |
screw |
A03N160501 |
Paper Feed Door |
13SU12170D |
DOOR STOPPER CUSHION 2 |
A03N161200 |
Screw |
A03N160200 |
Cover /Right |
A00JH00D00 |
PWB Assembly LED1 |
A00J168102 |
Lens /A |
A00J168400 |
Light blocking Cover |
A00J168801 |
Light blocking Plate |
A03N160603 |
Cover /Right Front |
A03N160000 |
Cover /Front |
A03N940100 |
Label |
A03N161100 |
Holding Plate |
A03N940000 |
Label |
13SU12031D |
WIRE MOUNTING PLATE |
A03N160700 |
Idler Cover |
A03N160900 |
Support Plate |
A03N161000 |
Holding Spring |
A03N160400 |
Cover /Upper |
A03N160800 |
Wiring Cover |
A03N160100 |
Cover/Rear |
A03NN10300 |
Harness |
V153030803 |
Screw |
A03N103700 |
Sound shield Cushion / Rear |
13SU10591D |
TRAY SUPPORT PLATE RIGHT |
A03N104100 |
Adjusting Roll |
A03N560900 |
Guide Plate |
A03N100201 |
Panel /Left |
A03N103601 |
Sound shield Cushion / Front |
A03N103900 |
Support Plate /Left |
A03N100400 |
POSITIONING PLATE / LOWER |
A03N104400 |
Guide Film |
A03N104000 |
Ground Plate |
A03N103501 |
Positioning Block |
A03N100501 |
POSITIONING STAY |
A03N160300 |
Cover /Left |
V127040803 |
Screw |
V195080003 |
Nut |
4106206301 |
SCREW |
V137040803 |
SCREW |
A03NA11200 |
Supprot Plate/Rear Stake |
540047200 |
PAPER REGULATING CLAW |
A03N620001 |
REGULATING PLATE |
12UM11030 |
PAPER REGULATING BLOCK |
A03N620100 |
Regulating Shaft |
A03NR70000 |
Moisture Proof Heater |
A03N100300 |
PANEL /RIGHT |
A03N100700 |
SUPPORT PLATE /ASSY |
13SU47460D |
PAPER GUIDE SHEET |
A03N622000 |
Sound shield Cushion |
12VL42941 |
SLIDE SHEET 3 |
A03N621900 |
Lifting Plate /ASSY |
540047030 |
MULTI FEED PREVENT PLATE |
13SU10460D |
COVER 1 |
4106206301 |
SCREW |
V116031203 |
Screw |
V217040001 |
E Ring |
A03N101200 |
LOCK CLAW /R |
A03N101000 |
LOCK SHAFT /1 |
13SU47061D |
LIFTING SHAFT |
466076020 |
PAPER FEED SHAFT HOLDER |
13SU47420 |
DRIVE PULLEY |
A03N620200 |
Up/down Wire /S |
13SU47480 |
WIRE PULLEY |
A03N620400 |
Auxiliary Wire |
A03N620300 |
Up/down Wire /L |
13SU47141D |
DRIVE AUXILIARY SHAFT 1 |
25AA42570 |
WIRE PULLEY |
55VA40610 |
WIRE HOLDER A |
A03N103801 |
Release Handle |
40AA32320 |
TONER SUPPLY SPACER |
A03N102500 |
Connecting Shaft /2 |
A03N100900 |
RELEASE PLATE /2 |
A03N620900 |
Slide Plate |
A03N620700 |
Slide Spring /1 |
A03N621800 |
Slide Shoulder screw |
A03N620600 |
Slide Spring /1 |
A03N620800 |
Mounting Plate |
A03N101100 |
LOCK CLAW /F |
13SU10081 |
TRAY LOCKING SPRING |
A03N104200 |
Regulating Spring |
A03NR7A000 |
TRAY RELEASE PLATE STAKE |
A03N104500 |
Washer |
V116030803 |
Screw |
V217060001 |
E Ring |
V217040001 |
E Ring |
V116030804 |
Screw |
V217030001 |
E Ring |
V153030803 |
Screw |
4106206301 |
SCREW |
08AA76010 |
DRUM DRIVING SHAFT HOLDER |
A03N560700 |
Paper feed Shaft /2 |
A03N560600 |
Paper feed Shaft /1 |
A03N560400 |
Pressing Weight |
A03N561200 |
Handle |
A00J595600 |
Clutch |
A00J563600 |
Roller |
56AA40490 |
SHAFT STOPPER 4 |
A03N560800 |
Actuator |
A00J602900 |
Washer |
A00J602700 |
Timing belt 102L |
A03N561600 |
Stopper Part |
A03N560001 |
Guide Plate /ASSY |
A00J587000 |
Paper feed Coupling |
A03N210800 |
Connecting Shaft |
A03N210401 |
Gear 41T |
A03N560500 |
Mounting Plate |
A00J602800 |
Pulley 14T |
V217040001 |
E Ring |
4106206301 |
SCREW |
V232201009 |
Pin |
V116030803 |
Screw |
V153030803 |
Screw |
V231200850 |
Pin |
A03N210401 |
Gear 41T |
A00J617800 |
Bearing |
A03N561100 |
Guide Part |
9335130061 |
PHOTO INTERRUPTER |
A03N560101 |
Paper Feed Plate /Assy |
A03N561001 |
Paper Feed Spring |
08AA76010 |
DRUM DRIVING SHAFT HOLDER |
A00J601600 |
Multi-feed Adjusting Plate |
A03N561501 |
Mounting Plate /Assy |
A03N561700 |
Washer |
A00J619700 |
ROLL /1 |
A00J619600 |
Pulley 14T |
A03N560301 |
Reverse Shaft /2 |
A00J619500 |
Pulley 15T |
A00J618500 |
Torque limiter |
A00J563600 |
Roller |
56AA40490 |
SHAFT STOPPER 4 |
A03N560201 |
Reverse Shaft /1 |
A00J619800 |
Timing Belt 96L |
A00J602900 |
Washer |
V217040001 |
E Ring |
4106206301 |
SCREW |
V217060001 |
E Ring |
V231200850 |
Pin |
A03N102300 |
Detection Actuator |
A03N102400 |
Torsion Spring |
A03N102100 |
Mounting Plate /2 |
A03N102200 |
Shaft |
A03N102000 |
Mounting Plate |
9335130061 |
PHOTO INTERRUPTER |
A03N210300 |
Gear 41T |
55VA75540 |
PAPER FEED SHAFT HOLDER B |
A03N700201 |
Conveyance Roller |
A03N700000 |
Conveyance Plate /ASSY |
A03N700300 |
Sensor Plate |
4037090201 |
PHOTO INTERRUPTER |
08AA76010 |
DRUM DRIVING SHAFT HOLDER |
A03N700100 |
Conveyance Plate /Lower |
A03N700501 |
PULLING SPRING |
4030312201 |
ROLL |
A03N700400 |
Conveyance Shaft /ASSY |
A03NN10101 |
LCT Relay Harness /1 |
V217040001 |
E Ring |
4106206301 |
SCREW |
V217060001 |
E Ring |
A03N620300 |
Up/down Wire /L |
A03N621000 |
Level Plate |
A03N621300 |
Detection Spring |
A03N620200 |
Up/down Wire /S |
13SU47420 |
DRIVE PULLEY |
13SU10340 |
COUPLING BEARING |
13SU47480 |
WIRE PULLEY |
13SU47380 |
RELEASE SPRING |
13SU47330D |
DRIVE INPUT SHAFT |
13SU47260 |
RELEASE WIRE |
13SU47300D |
RELEASE PART |
13SU47271 |
SLIDE ROLLER |
A03N211100 |
Gear 26T |
13SU47351 |
COUPLING SPRING |
A03NR7A200 |
SUPPORT PLATE STAKE |
A03N211200 |
Gear 26T |
13SU47410 |
WIRE HOLDER 1 |
12VL42390 |
PULLEY A |
466076020 |
PAPER FEED SHAFT HOLDER |
V217060001 |
E Ring |
V217040001 |
E Ring |
V217030001 |
E Ring |
V231201850 |
PIN |
V237301850 |
Pin |
V153030803 |
Screw |
V233302550 |
Pin |
V116030803 |
Screw |
A03NH00101 |
PWB Assy |
A03N621101 |
Mounting Plate |
13SU47470 |
PRESSING SPRING |
12QR86011 |
Interlock Switch |
9335130061 |
PHOTO INTERRUPTER |
08AA76010 |
DRUM DRIVING SHAFT HOLDER |
A03N210500 |
Gear 27/15T |
A03N210600 |
Gear 27T |
A03N210100 |
Drive Shaft |
A03N210700 |
Gear 43T |
A03NR7A300 |
DRIVE PALETE STAKE |
56AA80031 |
CASSETTE DRIVE MOTOR |
A00JM12000 |
Stepping motor |
4036301401 |
PIN |
4106206301 |
SCREW |
V118020803 |
SCREW |
V116032003 |
Screw |
V217040001 |
E Ring |
V217060001 |
E Ring |
V116030603 |
Screw |
A03NN10001 |
LCT Wiring |
A03NN10202 |
LCT Relay Harness /2 |
V500010003 |
Saddle |
V500010020 |
Saddle |
V570010021 |
Saddle |
V570010035 |
Bushing |
A03N101400 |
POSITIONING SHAFT /A |
V217040001 |
E Ring |
A03N101300 |
FIXING PLATE |
A03NA957000 |
Mounting Plate Stake |
V137040803 |
SCREW |
A03N101900 |
Slide Rail |
V116040803 |
Screw |
A03N101502 |
Guide Plate /Assy |
A03N101600 |
Guide Roll |
A00J700900 |
Collar |
V217060001 |
E Ring |
4106206301 |
SCREW |
A03N104300 |
Ground Plate |
A0TJ160500 |
Paper feed Door |
13SU12170D |
DOOR STOPPER CUSHION 2 |
A03N161200 |
Screw |
A0TJ160200 |
Right Cover |
A00JH00D00 |
PWB Assembly LED1 |
A00J168102 |
Lens /A |
A00J168400 |
Light blocking Cover |
A00J168801 |
Light blocking Plate |
A0TJ160600 |
Right Front Cover |
A0TJ160001 |
Front Cover |
A03N940100 |
Label |
A03N161100 |
Holding Plate |
A0TJ940000 |
Label |
A0TJ161600 |
Mounting Plate /ASSY |
A0TJ160701 |
Idler Cover |
A0TJ160900 |
Support Plate |
A03N161000 |
Holding Spring |
A0TJ160400 |
Upper Cover |
A03N160800 |
Wiring Cover |
A0TJ160100 |
Rear Cover |
A03NN10300 |
Harness |
A0TJ162100 |
Detecting Plate |
A0TJ161700 |
Mounting Plate |
A0TJ161900 |
Support Shaft |
A0TJ161800 |
Torsion Spring |
A03N161300 |
Fixing Sheet |
V153030803 |
Screw |
A0TJ103700 |
Sound shield Cushion / Rear |
A0TJ105800 |
Seal /Rear |
A0DA116100 |
Castor |
A0TJ560900 |
Guide Plate |
A0TJ100200 |
Panel /Left |
A0TJ103600 |
Sound shield Cushion / Front |
A0TJ103900 |
Support Plate /Left |
A0TJ100400 |
Positioning Plate /Lower |
A03N104400 |
Guide Film |
A03N104000 |
Ground Plate |
A0TJ103500 |
Positioning Block |
A0TJ100500 |
Positioning Stay |
A0TJ160300 |
Left Cover |
A0TJ100300 |
Panel /Right |
A0TJ105701 |
Seal /Front |
A03N104500 |
Washer |
13SU47141D |
DRIVE AUXILIARY SHAFT 1 |
A0TJ622200 |
Shaft |
A0TJ622700 |
Support Shaft /1 |
A0TJ104600 |
Support Plate/Right front |
A03N102900 |
Slide Stake |
A0TJ211000 |
Positioning Shaft |
A0TJ621200 |
Detection Shaft |
A0TJ104700 |
Support Plate/Right rear |
V127040803 |
Screw |
V195080003 |
Nut |
V116030803 |
Screw |
V144030603 |
Screw |
V137040803 |
SCREW |
A03NR7A100 |
SUPPORT PLATE/REAR STAKE |
540047200 |
PAPER REGULATING CLAW |
A0TJ620000 |
Regulating Plate |
A03N102200 |
Shaft |
A03N102100 |
Mounting Plate /2 |
A03NR70000 |
Moisture Proof Heater |
A03N102000 |
Mounting Plate |
A0TJ100700 |
Support Plate /ASSY |
13SU47460D |
PAPER GUIDE SHEET |
A03N622000 |
Sound shield Cushion |
12VL42941 |
SLIDE SHEET 3 |
A0TJ621900 |
Lifting Plate /ASSY |
4014197701 |
SHEET |
A0TJ105000 |
Bottom plate |
A0TJ622400 |
Adjusting Plate |
A0TJ622300 |
Mounting Plate |
A0TJ623000 |
Mounting Plate |
A0TJ620100 |
Regulating Plate |
57AA97870 |
PAPER GUIDE LABEL |
A03N102300 |
Detection Actuator |
A03N102400 |
Torsion Spring |
9ЗЗ51З0061 |
PHOTO INTERRUPTER |
A0TJ102001 |
Mounting Plate |
V144030603 |
Screw |
V126030603 |
screw |
V217040001 |
E Ring |
A03N101200 |
LOCK CLAW /R |
A0TJ101000 |
Lock Shaft /1 |
A0TJ2m00 |
Up/down Shaft |
4014175401 |
BUSHING |
A0TJ2^600 |
Drive Pulley |
A0TJ620200 |
Up/down Wire /S |
^SU47480 |
WIRE PULLEY |
A0TJ620400 |
Auxiliary Wire |
A0TJ620300 |
Up/down Wire /L |
A03N104500 |
Washer |
4014159201 |
WIRE PULLEY |
4014197001 |
HOLDER |
A03N103801 |
Release Handle |
4969115501 |
SPACER |
A0TJ102500 |
Connecting Shaft /2 |
A03N100900 |
RELEASE PLATE /2 |
A03N620900 |
Slide Plate |
A0TJ620700 |
Slide Spring /1 |
A03N621800 |
Slide Shoulder screw |
A0TJ620600 |
Slide Spring /1 |
A0TJ620800 |
Mounting Plate |
A03N101100 |
LOCK CLAW /F |
13SU10081 |
TRAY LOCKING SPRING |
A03N104200 |
Regulating Spring |
A03NR7A000 |
TRAY RELEASE PLATE STAKE |
V217060001 |
E Ring |
V153030803 |
Screw |
V217040001 |
E Ring |
V217030001 |
E Ring |
V144030603 |
Screw |
V116030803 |
Screw |
V217050001 |
E ring |
4024219001 |
BUSHING |
A03N560700 |
Paper feed Shaft /2 |
A03N560600 |
Paper feed Shaft /1 |
A03N560401 |
Pressing Weight |
A03N561200 |
Handle |
A00J595600 |
Clutch |
A00J563600 |
Roller |
4024255001 |
STOPPER |
A03N560800 |
Actuator |
A00J602900 |
Washer |
A00J602700 |
Timing belt 102L |
A03N561600 |
Stopper Part |
A0TJ560000 |
Guide Plate /ASSY |
A00J587000 |
Paper feed Coupling |
A0TJ210800 |
Connecting Shaft |
A03N210401 |
Gear 41T |
A03N560500 |
Mounting Plate |
A00J602800 |
Pulley 14T |
V116030803 |
Screw |
V153030803 |
Screw |
V217040001 |
E Ring |
V232201009 |
Pin |
V144030603 |
Screw |
V231200850 |
Pin |
A03N210401 |
Gear 41T |
A00J617800 |
BALL BEARING |
A03N561100 |
Guide Part |
9335130061 |
PHOTO INTERRUPTER |
A0TJ560100 |
Paper feed Plate /ASSY |
A03N561001 |
Paper Feed Spring |
4024219001 |
BUSHING |
A00J601600 |
Multi-feed Adjusting Plate |
A03N561501 |
Mounting Plate /Assy |
A03N561700 |
Washer |
A00J619700 |
ROLL /1 |
A00J619600 |
Pulley 14T |
A00J619611 |
Pulley 14T |
A03N560301 |
Reverse Shaft /2 |
A00J619500 |
Pulley 15T |
A00J618500 |
Torque limiter |
A00J563600 |
Roller |
4024255001 |
STOPPER |
A0TJ560200 |
Reverse Shaft /1 |
A00J619800 |
Timing Belt 96L |
A00J602900 |
Washer |
A00J660800 |
Washer |
V144030603 |
Screw |
V217040001 |
E Ring |
V137030603 |
screw |
V231200850 |
Pin |
A0TJ211500 |
Conveyance Timing belt |
A0TJ210300 |
Pulley 41T |
4014217301 |
BUSHING |
A0TJ700200 |
Conveyance Roller |
4024219001 |
BUSHING |
A0TJ700000 |
Conveyance Plate /ASSY |
A0TJ700100 |
Conveyance Plate /Lower |
A03N700501 |
PULLING SPRING |
4030312201 |
ROLL |
A03N700400 |
Conveyance Shaft /ASSY |
4037090201 |
PHOTO INTERRUPTER |
A03N700300 |
Sensor Plate |
A0TJN10100 |
LCT Detection harness |
V217060001 |
E Ring |
V144030603 |
Screw |
V217040001 |
E Ring |
A0TJ622600 |
Detecting Wire |
A03N621000 |
Level Plate |
A0TJ621300 |
Detection Spring |
A0TJ620200 |
Up/down Wire /S |
A0TJ213600 |
Drive Pulley |
A0TJ103200 |
Bushing |
13SU47480 |
WIRE PULLEY |
13SU47380 |
RELEASE SPRING |
A0TJ213000 |
Drive Shaft |
13SU47260 |
RELEASE WIRE |
13SU47300D |
RELEASE PART |
A0TJ105900 |
Slide Roll |
A0TJ211100 |
Gear 26T |
A0TJ213700 |
Compressing Spring |
A0TJR7A200 |
Support Plate Stake |
A0TJ211200 |
Gear 26T |
13SU47410 |
WIRE HOLDER 1 |
12VL42390 |
PULLEY A |
4014175401 |
BUSHING |
4014197001 |
HOLDER |
A0TJ620300 |
Up/down Wire /L |
A0TJ213400 |
Pin |
A0TJ213300 |
Pin |
V217060001 |
E Ring |
V217050001 |
E ring |
V116030803 |
Screw |
V217030001 |
E Ring |
V153030803 |
Screw |
A0TJH00100 |
PWB Assembly (PWB-LCT ASSY) |
A0TJ621100 |
Mounting Plate |
13SU47470 |
PRESSING SPRING |
12QR86011 |
Interlock Switch |
9335130061 |
PHOTO INTERRUPTER |
4024219001 |
BUSHING |
A03N210500 |
Gear 27/15T |
A03N210600 |
Gear 27T |
A03N210100 |
Drive Shaft |
A03N210700 |
Gear 43T |
A0TJR7A100 |
Drive Plate Stake |
A00JR74900 |
MOTOR ASSY |
A00JM12000 |
Stepping motor |
4036301401 |
PIN |
A0TJ622500 |
Mounting Plate |
4131353202 |
BUSHING |
A0TJ211701 |
Up/down Shaft |
A0TJ212400 |
Washer |
A0TJ212800 |
Compressing Spring |
A0TJ212700 |
Cam |
A0TJ212000 |
Gear 75T |
A0TJ212100 |
Gear 16T |
A0TJ211900 |
Gear 16/48T |
A0TJ213100 |
Conveyance Pulley |
A0TJ213500 |
Pin |
A0TJ211600 |
Gear 46T |
A0TJM12400 |
Stepping motor |
A0TJR7A000 |
Bracket Stake |
A0TJ212500 |
Mounting Plate |
A0TJ212900 |
Pin |
V144030603 |
Screw |
V118021003 |
screw |
V116030603 |
Screw |
V217040001 |
E Ring |
V217060001 |
E Ring |
V217030001 |
E Ring |
V217080001 |
E ring |
V115260503 |
Screw |
A0TJN10001 |
LCT Wiring |
A0TJN10200 |
LCT Relay harness |
V500010003 |
Saddle |
V500010020 |
Saddle |
V570010021 |
Saddle |
V570010035 |
Bushing |
A03N101400 |
POSITIONING SHAFT /A |
V217040001 |
E Ring |
A03N101300 |
FIXING PLATE |
A03NR7A400 |
MOUNTING PLATE STAKE |
A0TJ940300 |
Label |
A0TJ101900 |
Slide Rail |
V116040803 |
Screw |
A03N101502 |
Guide Plate /Assy |
A03N101600 |
Guide Roll |
A00J700900 |
Collar |
V217060001 |
E Ring |
V144030603 |
Screw |
A03N104300 |
Ground Plate |
A4FRPP0300 |
MEMORY MODULES |
A4FRPP0100 |
PWB Assy Mother |
A4FRPP0200 |
CPU/COOLING KIT |
A127PP0600 |
Power Supply |
A127PP0B00 |
PWB Assy Video |
A074PP0100 |
Motor |
A4FRPP0400 |
HDD 160GB |
A4FRPP0500 |
SATA CABLE |
A074PP0700 |
Power Cord 120V |
A074PP0800 |
Power Cord 220-240V |
A074PP0900 |
Power Cord 220-240V |
A4FRPP0600 |
Power Cord 220-230V |
A074PP0A00 |
Power Cord 100V |
A4FRPP0700 |
Wire Harness Assy |
A4FRPP0800 |
Wire Harness Assy |
A4FRPP0900 |
Media Pack Europe |
A4FRPP1000 |
Media Pack Japanese |
A4FRPP1100 |
Service Kit English |
A4FRPP1200 |
Service Kit Japanese |
A3ERPP1E01 |
Cover/Front |
A3ERPP1G01 |
Lever |
A3ERPP1P00 |
Torsion Spring |
A3ERPP1M00 |
Shaft |
A3ERPP6Q00 |
Label |
A3ERPP6P01 |
Label |
A3EPPPB801 |
Screw |
V217040001 |
E Ring |
A3ERPP1F01 |
Mounting Plate |
A3ERPP4P00 |
Shaft |
A3ERPP1401 |
Stay |
A3ERPP1301 |
Stay |
A3ERPP1J01 |
Stay |
A3ERPP1C01 |
Cover |
A3ERPP1201 |
Stay |
A3ERPP1801 |
Mounting Plate |
A3ERPP1T00 |
Sheet |
A3EPPPB601 |
Screw |
A3EPPPBQ01 |
Screw |
A3ERPP1R01 |
Sheet |
A3ERPP6J01 |
PWB |
A3ERPP1B02 |
Mounting Plate |
A3ERPP1K00 |
Shaft |
A3ERPP1S01 |
Cover |
A3ERPP1D01 |
Guide |
A3ERPP1701 |
Guide |
A3ERPP1A01 |
Lock Lever |
A3ERPP1600 |
Roll |
A3ERPP1L00 |
Shaft |
A3ERPP1N01 |
Tension Spring |
A3ERPP1903 |
Mounting Plate |
A3EPPPB101 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB701 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3ERPP4S00 |
Motor |
A3ERPP7Q00 |
Neutralizing Brush |
A3ERPP4701 |
Mounting Plate |
A3ERPP4B01 |
Gear 24/46T |
A3ERPP4E00 |
Gear 15/40T |
A3ERPP4F01 |
Gear 34/80T |
A3ERPP4U02 |
Gear 28/96T |
A3ERPP4T01 |
Gear 24/60T |
A3ERPP4301 |
Mounting Plate |
A3ERPP3X01 |
Mounting Plate |
A108M50100 |
Photointerrupter |
A3ERPP4900 |
Holder |
A3EPPP1101 |
Bushing |
A3ERPP4V01 |
Plate |
A3ERPP4201 |
Slide Plate |
A3ERPP4K00 |
Shaft |
A3ERPP4A01 |
Gear 46T |
A3EPPPAS01 |
Pin |
A3EPPP1201 |
Bushing |
A3ERPP3Y01 |
Mounting Plate |
A3ERPP4J00 |
Shaft |
A3ERPP4101 |
Stay |
A3ERPP4001 |
Mounting Plate |
A3ERPP1H01 |
Cover |
A3EPPPB601 |
Screw |
V217060001 |
E Ring |
A3EPPPBQ01 |
Screw |
A3ERPP4Q01 |
Gear |
A3ERPP4N01 |
Roller |
A3ERPP4802 |
Guide Plate |
A3ERPP4R01 |
Plate |
A3ERPP4G01 |
Gear |
A3EPPPAS01 |
Pin |
A3ERPP5E00 |
Gear 20T |
A3ERPP4L00 |
Shaft |
A3ERPP4H00 |
Gear 38T |
A3ERPP4M02 |
Tension Spring |
A3ERPP4401 |
Arm |
A3EPPP1201 |
Bushing |
4004454001 |
BALL BEARING |
A3ERPP5701 |
Gear 46T |
A3ERPP5801 |
Gear 15/93T |
A3ERPP5101 |
Mounting Plate |
A3ERPP5R00 |
Motor |
A108M50100 |
Photointerrupter |
A3EPPP1101 |
Bushing |
A3ERPP3N00 |
Motor |
A3ERPP5202 |
Mounting Plate |
A3ERPP5P00 |
Seal |
A3ERPP5N00 |
Seal |
A3ERPP5Q00 |
Seal |
A3ERPP4Y01 |
Guide |
A3ERPP5M01 |
Bushing |
A3ERPP7K00 |
Pressing Spring |
A3ERPP5J01 |
Roller |
A3ERPP5S00 |
Gear 38T |
A3ERPP4C00 |
Gear 17T |
A3ERPP4D00 |
Gear 14T |
A3ERPP4601 |
Mounting Plate |
A3ERPP4501 |
Arm |
A3EPPP2501 |
Screw |
A3EPPPB001 |
Screw |
V217060001 |
E Ring |
A3EPPPB601 |
Screw |
A3ERPP6K01 |
Screw |
A3EPPPAY01 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3ERPP5A00 |
Bushing |
A3ERPP5500 |
Gear |
A3ERPP6401 |
Seal |
A3ERPP4X01 |
Guide Plate |
A3ERPP6501 |
Seal |
A3ERPP5403 |
Guide |
A02E193400 |
Shoulder screw |
A3ERPP7K00 |
Pressing Spring |
A3ERPP5M01 |
Bushing |
4030104002 |
CATCH |
A3ERPP5900 |
Roll |
A3ERPP5H00 |
Shaft |
A3EPPP1400 |
Bushing |
A3EPPPAR01 |
Pin |
A3ERPP5C00 |
Gear |
A3ERPP5D01 |
Knob |
A3ERPP6101 |
Shoulder Screw |
A3EPPP1201 |
Bushing |
A3ERPP6301 |
Seal |
A3ERPP5B02 |
Guide Plate |
A0EDM50100 |
Photoreflector |
A3ERPP6201 |
Auxiliary Plate |
A3ERPP5F01 |
Gear 15T |
A3ERPP5G02 |
Gear 13T |
A3ERPP1101 |
Pin |
A3ERPP7M01 |
Tension Spring |
A3ERPP5302 |
Mounting Plate |
A3ERPP5L01 |
Roller |
A3ERPP5Y01 |
Neutralizing Brush |
A3ERPP5002 |
Guide Plate |
A3ERPP5K01 |
Roller |
A3ERPP5602 |
Mounting Plate |
A3ERPP5X00 |
Bushing |
A3ERPP6S00 |
Label |
A3ERPP6U00 |
Label |
A3ERPP7H00 |
Wire Harness Assy |
A3ERPP7401 |
Bracket |
A3ERPP7201 |
Bracket |
A3ERPP7302 |
Tension Spring |
A3ERPP7102 |
Bracket |
A3ERPP6001 |
Seal |
V217040001 |
E Ring |
V218040086 |
E ring |
A3EPPPCJ01 |
Screw |
V217060001 |
E Ring |
A3ERPP6L01 |
Screw |
A3EPPPB601 |
Screw |
A3ERPP8200 |
Screw |
A3EPPP1101 |
Bushing |
A3ERPP2J02 |
Guide |
A3EPPP3702 |
Roll |
A3ERPP2A00 |
Shaft |
A3ERPP2N01 |
Tension Spring |
A108M50100 |
Photointerrupter |
A3ERPP2B00 |
Torsion Spring |
A3ERPP2101 |
Actuator |
A3ERPP2301 |
Guide |
A3EPPP1300 |
Bushing |
A3ERPP2P01 |
Cushion |
A3EPPPAQ01 |
Pin |
A3ERPP2401 |
Lever |
A3ERPP6X01 |
Pressure Spring |
A3ERPP2901 |
Lever |
A3ERPP2E01 |
Gear 30T |
A3ERPP2G00 |
Timing Belt |
A3ERPP1X01 |
Mounting Plate |
A3ERPP2F00 |
Motor |
A3ERPP3N00 |
Motor |
A3ERPP2700 |
Gear 16/88T |
A3ERPP6V01 |
Tension Spring |
A3ERPP2800 |
Gear 50T |
A3ERPP2C00 |
Torsion Spring |
A3ERPP2L00 |
Torsion Spring |
A3ERPP1V02 |
Guide |
A3ERPP2001 |
Mounting Plate |
A3ERPP2201 |
Guide |
A3ERPP2D01 |
Roller |
A3ERPP1U02 |
Guide |
A3ERPP6R00 |
Label |
A3ERPP7800 |
Wire Harness Assy |
A3ERPP7D01 |
Wire Harness Assy |
A3ERPP7701 |
Wire Harness Assy |
A3ERPP7C01 |
Wire Harness Assy |
V217040001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
V217030001 |
E Ring |
V218040086 |
E ring |
A3EPPPAY01 |
Screw |
A3ERPP3Q01 |
Mounting Plate |
A3ERPP3R02 |
Cover |
A3ERPP3V01 |
Neutralizing Brush |
A3ERPP3U02 |
Seal |
A3ERPP3T01 |
Seal |
A10D929300 |
Stapler Unit |
A3ERPP3S01 |
Seal |
A3ERPP7900 |
Wire Harness Assy |
A10DP00100 |
STAPLE CARTRIDGE |
A3ERPP7W01 |
Seal |
A3ERPP7V00 |
Seal |
A3ERPP7X01 |
Seal |
A3EPPPB601 |
Screw |
A3EPPPBQ01 |
Screw |
A3ERPP5T00 |
Gear 26T |
A3ERPP1001 |
Pin |
A3EPPP1101 |
Bushing |
A3ERPP5U00 |
Shaft |
A3ERPP3N00 |
Motor |
A3ERPP5V00 |
Gear 34T |
A3ERPP3E00 |
Pressing Spring |
A3ERPP3B02 |
Regulating Plate |
A3ERPP3C02 |
Rack |
A3ERPP3D01 |
Gear 14/44T |
A0EDM50100 |
Photoreflector |
A108M50100 |
Photointerrupter |
A3ERPP3A02 |
Regulating Plate |
A3ERPP3901 |
Mounting Plate |
A3ERPP2E01 |
Gear 30T |
A3ERPP3J00 |
Timing Belt |
A3ERPP3K01 |
Gear 30T |
A3ERPP2R00 |
Roller |
A092145400 |
Shoulder screw |
A3ERPP2T01 |
Mounting Plate |
A3ERPP3M00 |
Motor |
A3ERPP7Y00 |
Paddle Assy |
A3ERPP3801 |
Paddle Assy |
A3ERPP6Y02 |
Cover |
A3ERPP7Z00 |
Shaft |
V217040001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
A3EPPPAY01 |
Screw |
A3EPPPB101 |
Screw |
V217030001 |
E Ring |
V218040086 |
E ring |
A3ERPP7N01 |
Guide Plate |
A3ERPP3G01 |
Seal |
A3ERPP3301 |
Stopper |
A3ERPP3601 |
Shaft |
A3ERPP3101 |
Arm |
A3ERPP3201 |
Arm |
A3ERPP3P01 |
Cushion |
A3ERPP3L01 |
Plate Spring |
A3ERPP3401 |
Lever |
A3ERPP3000 |
Lever |
A3ERPP3701 |
Torsion Spring |
A3ERPP3F01 |
Pressing Spring |
A10DM20000 |
Plunger solenoid |
A3ERPP2V00 |
Holder |
A3ERPP2U00 |
Holder |
A3ERPP3500 |
Shaft |
A3ERPP2R00 |
Roller |
A3ERPP3H00 |
Timing Belt |
A3ERPP2Y00 |
Gear 20T |
A3ERPP7001 |
Tension Spring |
A3ERPP2Q01 |
Tension Plate |
A3ERPP2X00 |
Gear |
A108M50100 |
Photointerrupter |
A3ERPP2S03 |
Mounting Plate |
A3ERPP3N00 |
Motor |
A3ERPP2M01 |
Seal |
A3ERPP1Y01 |
Guide |
A3ERPP2K01 |
Guide |
A3ERPP2602 |
Guide |
A3ERPP2H02 |
Guide |
A3ERPP2C00 |
Torsion Spring |
A3ERPP2503 |
Guide |
A3ERPP2L00 |
Torsion Spring |
A3ERPP6T00 |
Label |
A3ERPP7U00 |
Seal |
A3ERPP7F01 |
Wire Harness Assy |
A3EPPPB601 |
Screw |
A3EPPPBN01 |
Screw |
V217040001 |
E Ring |
A3EPPPAY01 |
Screw |
A3EPPPBA01 |
Screw |
A3EPPPB101 |
Screw |
A3ERPP6801 |
Cover |
A3ERPP6703 |
Tray |
A3ERPP6G01 |
Shoulder Screw |
A3EPPP2600 |
Photoreflector |
A3EPPP2700 |
Photoreflector |
A3EPPPBS00 |
Torsion Coil spring |
A3EPPPA801 |
Actuator |
A3ERPP6D02 |
Cover |
A3ERPP6H01 |
Seal |
A3ERPP6E01 |
Mounting Plate |
A10D427300 |
Cushion |
A3ERPP6A01 |
Cover |
A3ERPP6F01 |
Mounting Plate |
A3ERPP6901 |
Arm |
A3ERPP6B00 |
Shaft |
A3ERPP6C01 |
Tension Spring |
A3ERPP6601 |
Guide |
A108M50100 |
Photointerrupter |
A3ERPP7J00 |
Wire Harness Assy |
A3ERPP7501 |
Seal |
A3EPPPCH00 |
Wire Harness Assy |
A3ERPP8000 |
Mounting Plate |
A3ERPP4P00 |
Shaft |
A3EPPPB401 |
Screw |
A3EPPPB201 |
Screw |
A3EPPPB301 |
Screw |
A3ERPP7E00 |
Wire Harness Assy |
A3ERPP7600 |
Wire Harness Assy |
A3ERPP7B00 |
Wire Harness Assy |
A3ERPP7A01 |
Wire Harness Assy |
V500010005 |
saddle |
V500010020 |
Saddle |
V500010046 |
saddle |
V501010001 |
band |
V570010021 |
Saddle |
V570010026 |
saddle |
A3ERPP1501 |
Mounting Plate |
A3ERPP8100 |
Cushion |
A3ERPP1Q00 |
Rail |
A3EPPPCL00 |
Guide |
1033440203 |
STOPPER RING |
4030104002 |
CATCH |
A3EPPPCK00 |
Label |
A3ERPP6K01 |
Screw |
A3EPPP1P02 |
Rear Cover |
A3EPPP1R02 |
Upper Cover |
A3EPPP1S02 |
Bracket |
A0HR172601 |
Torsion Coil spring |
A0HR115400 |
Ground Plate /Lower |
A3EPPP2501 |
Screw |
A3EPPP1K02 |
Cover |
A3EPPPBG00 |
Label |
A3EPPPCP00 |
MAGNET CATCH |
A3EPPP2301 |
Actuator |
A3EPPP1N00 |
Shaft |
A3EPPP1M02 |
Front Cover |
A3EPPP1L02 |
Cover |
A3EPPP1G01 |
Lower Cover |
A3EPPP2001 |
Tray |
A3EPPP1Y01 |
Tray |
A3EPPPB801 |
Screw |
A3EPPPBA01 |
Screw |
A3EPPPB401 |
Screw |
A3EPPPB601 |
Screw |
A3EPPP2700 |
Photoreflector |
A3EPPPBD01 |
Sheet |
A3EPPP2N01 |
Bracket |
A3EPPP4C01 |
Torsion Coil spring |
A3EPPP5201 |
Screw |
A3EPPP1F01 |
Cover |
4030104002 |
CATCH |
A3EPPP2600 |
Photoreflector |
A3EPPPC200 |
Wire Harness Assy |
A092145400 |
Shoulder screw |
A3EPPP1B01 |
Reinforce Plate |
A3EPPPBV00 |
Wire Harness Assy |
A3EPPPBT00 |
Wire Harness Assy |
A108M50100 |
Photointerrupter |
A3EPPP2201 |
Bracket |
A3EPPP1X01 |
Guide |
9J06M60100 |
MICRO SWITCH |
A3EPPP1V01 |
Cover |
A0HR115400 |
Ground Plate /Lower |
A0HR116000 |
Mounting Plate |
A3EPPP1U01 |
Cover |
A0HR111400 |
Castor |
A3EPPP1J02 |
Bracket |
A3EPPP2400 |
Bushing |
A3EPPPBE01 |
Main PCB Assy |
A3EPPP1T01 |
Guide |
A3EPPPBA01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB101 |
Screw |
A3EPPPB401 |
Screw |
V195080003 |
Nut |
A3EPPP3J00 |
Bush |
A3EPPP3F00 |
Bush |
A3EPPP1400 |
Bushing |
A3EPPP3M00 |
Cam |
A3EPPP2J01 |
Bracket |
A3EPPP3901 |
Cam |
A3EPPP4902 |
Tension Spring |
A3EPPP3K02 |
Guide |
A3EPPP4701 |
Pressure Spring |
A3EPPP1A01 |
Bush |
A3EPPP2Q02 |
Roller |
A3EPPP3X00 |
Shaft |
A3EPPP3L01 |
Guide |
A3EPPP2P01 |
Guide Assy |
A3EPPP5401 |
Neuralizing Brush |
A3EPPP3R01 |
Screw |
A3EPPP4102 |
Shaft |
A3EPPP3Q00 |
Nut |
A3EPPP6L01 |
Film |
A3EPPP6G00 |
Drum |
A3EPPP6H01 |
Stopper |
A3EPPP3P01 |
Nut |
A3EPPP6F01 |
Stopper |
A3EPPP3N00 |
Screw |
A3EPPP4U00 |
Timing Belt |
A3EPPP3201 |
Cam |
A3EPPPCQ00 |
Bracket |
A3EPPP5600 |
Motor Assy |
A3EPPP5500 |
Motor Assy |
A108M50100 |
Photointerrupter |
A3EPPP2M01 |
Bracket |
A0EDM50100 |
Photoreflector |
A3EPPPC500 |
Wire Harness Assy |
A3EPPPB101 |
Screw |
V218040086 |
E ring |
A3EPPPAV01 |
Screw |
V217030001 |
E Ring |
A3EPPPBA01 |
Screw |
A3EPPPAY01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPP5301 |
Motor |
A3EPPP2D01 |
Bracket |
A3EPPP2C01 |
Plate Spring |
A3EPPP3800 |
Flange |
A3EPPP4P00 |
Timing Belt |
A3EPPPBB00 |
Pulley Assy |
A3EPPP2R01 |
Pulley |
A3EPPP4M00 |
Timing Belt |
A3EPPP2S00 |
Pulley |
A3EPPP4Q00 |
Timing Belt |
A3EPPP4L00 |
Timing Belt |
A3EPPP4N00 |
Timing Belt |
A3EPPP4K00 |
Timing Belt |
A3EPPP3C00 |
Pulley |
A3EPPP2V01 |
Roller |
A3EPPP1101 |
Bushing |
A3EPPP3D01 |
Cam |
A3EPPPAQ01 |
Pin |
A0HR213100 |
Pulley 28T |
A3EPPP4U00 |
Timing Belt |
A3EPPP1001 |
Bushing |
A108M50100 |
Photointerrupter |
A3EPPP2H01 |
Bracket |
A3EPPP3B00 |
Cover |
A3EPPP3401 |
Actuator |
A3EPPP4600 |
Torsion Coil spring |
A3EPPP3A01 |
Guide |
A3EPPPBK00 |
Label |
A3EPPPBL00 |
Label |
A3EPPPC601 |
Wire Harness Assy |
A3EPPPB601 |
Screw |
A3EPPPB101 |
Screw |
V217060001 |
E Ring |
V217040001 |
E Ring |
A3EPPPB401 |
Screw |
A3EPPPAX01 |
Screw |
4004454001 |
BALL BEARING |
A3EPPP1501 |
Ball Bearing |
A3EPPP2X01 |
Guide |
A3EPPP4V00 |
Sponge |
A3EPPP4S01 |
Film |
A3EPPP2B01 |
Guide |
A3EPPP4F02 |
Roller |
A3EPPP4302 |
Tension Spring |
A3EPPP3702 |
Roll |
A3EPPP3T00 |
Shaft |
A3EPPP2T01 |
Guide |
A0EDM50100 |
Photoreflector |
A3EPPP4400 |
Torsion Coil spring |
A3EPPP2U01 |
Guide Plate |
A3EPPP4800 |
Torsion Coil spring |
A3EPPP2F01 |
Guide |
A3EPPP4E02 |
Roller |
4030104002 |
CATCH |
A3EPPP4J03 |
Roller |
A3EPPP4G02 |
Roller |
A3EPPP2K01 |
Hinge |
A3EPPP5001 |
Screw |
A3EPPP3500 |
Guide |
A3EPPP3001 |
Cam |
A3EPPP3V01 |
Shaft |
A3EPPP4B00 |
Pressure Spring |
A3EPPPBH00 |
Label |
A3EPPPC401 |
Wire Harness Assy |
V217060001 |
E Ring |
V217040001 |
E Ring |
V217030001 |
E Ring |
V218040086 |
E ring |
A3EPPPAU01 |
Screw |
A3EPPPB401 |
Screw |
A3EPPPB601 |
Screw |
A3EPPP3702 |
Roll |
A3EPPP4302 |
Tension Spring |
A3EPPP4000 |
Shaft |
A3EPPP4R01 |
Film |
A3EPPP3E01 |
Guide |
A3EPPP3G02 |
Guide |
A0EDM50100 |
Photoreflector |
A3EPPP3H01 |
Roller |
A3EPPP4202 |
Tension Spring |
A3EPPP3S00 |
Shaft |
A3EPPP2901 |
Guide Assy |
A3EPPP4X01 |
Film |
A3EPPP2801 |
Guide |
A3EPPP4D02 |
Roller |
A3EPPP1501 |
Ball Bearing |
A3EPPP1E01 |
Reinforce Stay |
A3EPPP2A02 |
Guide Assy |
A3EPPP4T02 |
Film |
A3EPPP4501 |
Torsion Coil spring |
A3EPPP5701 |
Neuralizing Brush |
A3EPPP2Y02 |
Guide Plate |
A3EPPP3101 |
Lever |
A3EPPP3302 |
Guide |
A3EPPP3603 |
Roller |
A3EPPP3U00 |
Shaft |
A3EPPP3Y00 |
Shaft |
A3EPPP4A02 |
Tension Spring |
A3EPPP2E01 |
Bracket |
A3EPPP4Y01 |
Screw |
A3EPPP5101 |
Screw |
A3EPPP2L01 |
Bracket |
A3EPPP2R01 |
Pulley |
A3EPPPBJ00 |
Label |
A3EPPPC300 |
Wire Harness Assy |
A3EPPPD500 |
Seal |
A3EPPPD900 |
Film |
V217030001 |
E Ring |
A3EPPPB601 |
Screw |
V217060001 |
E Ring |
A3EPPPB401 |
Screw |
V217040001 |
E Ring |
A3EPPPCN00 |
Screw |
A3EPPPAA00 |
Motor |
A3EPPPCY00 |
Mounting Plate |
A3EPPPAD00 |
Gear |
A3EPPPA401 |
Gear |
A3EPPP9S02 |
Shaft |
A3EPPPAC01 |
Actuator |
A3EPPPA901 |
Plate Spring |
A3EPPP9Y01 |
Torsion Spring |
A3EPPPA302 |
Actuator |
A3EPPP9X01 |
Torsion Spring |
A3EPPPA101 |
Holder |
A3EPPP9Q01 |
Holder |
A3EPPP9T01 |
Cushion |
A3EPPP1300 |
Bushing |
A3EPPPA202 |
Actuator |
A3EPPPA602 |
Torsion Spring |
A108M50100 |
Photointerrupter |
A3EPPPA801 |
Actuator |
A3EPPP2600 |
Photoreflector |
A3EPPPAH00 |
Seal |
A3EPPP2700 |
Photoreflector |
A3EPPP9503 |
Cover |
A3EPPPAG01 |
Slide Part |
A3EPPPAF01 |
Slide Part |
A3EPPPAE01 |
Slide Part |
A3EPPP9U02 |
Cover |
A3EPPP9R01 |
Arm |
A3EPPPBS00 |
Torsion Coil spring |
A3EPPPCH00 |
Wire Harness Assy |
A3EPPPC100 |
Wire Harness Assy |
A3EPPPAB01 |
Vibrating Plate |
A3EPPPD700 |
Slide Part |
A3EPPPAY01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB201 |
Screw |
V217040001 |
E Ring |
A3EPPPB801 |
Screw |
A3EPPPCF01 |
Ball Bearing |
A3EPPPAS01 |
Pin |
A3EPPP9B00 |
Shaft |
A3EPPP9C00 |
Gear |
A3EPPPA001 |
Plate Spring |
A3EPPPD100 |
Support Plate Assy |
A3EPPP9N01 |
Holder |
A3EPPP9601 |
Mounting Plate |
A3EPPP9900 |
Timing Belt |
A3EPPPD000 |
Support Plate |
A3EPPP9A01 |
Frame |
A3EPPP1Y01 |
Tray |
A3EPPP9P01 |
Tray |
A3EPPP9L02 |
Pulley |
A3EPPPBP00 |
Timing Belt |
A3EPPP1501 |
Ball Bearing |
A3EPPP9E00 |
Ratchet |
A3EPPP1201 |
Bushing |
A3EPPP9G00 |
Shaft |
A3EPPP9H03 |
Gear |
A3EPPP9J01 |
Worm Gear |
A3EPPP9F03 |
Mounting Plate |
A3EPPP9M01 |
Mounting Plate |
A3EPPPA901 |
Plate Spring |
A108M50100 |
Photointerrupter |
A3EPPPA702 |
Motor |
A3EPPPAR01 |
Pin |
A3EPPP9K00 |
Shaft |
A3EPPPD200 |
Support Plate Assy |
A3EPPP9D01 |
Gear |
A3EPPPBR01 |
Pressure Spring |
V217080001 |
E ring |
A3EPPPBN01 |
Screw |
A3EPPPBQ01 |
Screw |
A3EPPPCJ01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
V217040001 |
E Ring |
A3EPPPAY01 |
Screw |
V217060001 |
E Ring |
A3EPPP8Y01 |
Holder |
9J08560101 |
STAPLER UNIT |
A3EPPP8K02 |
Mounting Plate |
A3EPPP9001 |
Roll |
A3EPPP8L00 |
Collar |
A3EPPP8N01 |
Roll |
A3EPPP8P01 |
Holder |
A3EPPP8J01 |
Mounting Plate |
A3EPPP9301 |
Guide |
A3EPPP8R01 |
Plate Spring |
A3EPPP8Q01 |
Holder |
A3EPPP8S00 |
Timing Belt |
A3EPPP8V01 |
Gear |
A3EPPP8T00 |
Timing Belt |
A3EPPP9200 |
Shaft |
A3EPPP8X02 |
Knob |
A108M50100 |
Photointerrupter |
A3EPPP8H03 |
Holder |
A3EPPP8U00 |
Shaft |
A3EPPP8M02 |
Shaft |
A3EPPP9402 |
Plate |
A3EPPPCX00 |
Mounting Plate |
A3EPPP9102 |
Motor |
A3EPPP2C01 |
Plate Spring |
A3EPPPBY00 |
Wire Harness Assy |
A3EPPPCB00 |
Wire Harness Assy |
A3EPPPCA01 |
Wire Harness Assy |
A3EPPPCC01 |
Wire Harness Assy |
A3EPPPDA00 |
Spacer |
A3EPPPB701 |
Screw |
V217025001 |
E ring |
A3EPPPB001 |
Screw |
A3EPPPAV01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB101 |
Screw |
V217040001 |
E Ring |
A3EPPPBN01 |
Screw |
A3EPPP6T01 |
Cover |
A3EPPP6S01 |
Bracket |
A3EPPP8501 |
Film |
A3EPPP8400 |
Torsion Coil spring |
A3EPPP8201 |
Bracket |
A3EPPP7P01 |
Actuator |
A3EPPP7X01 |
Torsion Coil spring |
A108M50100 |
Photointerrupter |
A3EPPP7Y01 |
Pulley |
A3EPPP7S00 |
Timing Belt |
A3EPPP8F00 |
Motor |
A3EPPPCV00 |
Bracket |
A3EPPP7503 |
Pulley |
A3EPPP7600 |
Timing Belt |
A3EPPP7402 |
Detecting Plate |
A3EPPP8E00 |
Motor Assy |
A3EPPP7R01 |
Bracket |
A3EPPP8000 |
Timing Belt |
A3EPPP8102 |
Pulley |
A3EPPP7T02 |
Frame |
A3EPPPD600 |
Flange |
A3EPPPB901 |
Screw |
V217040001 |
E Ring |
A3EPPPAY01 |
Screw |
V217030001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
A3EPPP7N03 |
Frame |
A3EPPP7K00 |
Frame |
A3EPPPAJ00 |
Holder Assy |
A3EPPPAN00 |
Arm |
A3EPPP7V01 |
Torsion Coil spring |
A3EPPP7H00 |
Timing Belt |
A3EPPP7A01 |
Pulley |
A3EPPP7G00 |
Pulley |
A3EPPP7F01 |
Bracket |
A3EPPP7E00 |
Timing Belt |
A3EPPP7B03 |
Pulley |
A3EPPP7C02 |
Pulley |
A3EPPP7D00 |
Pulley |
A3EPPPAT00 |
Ball Bearing |
A3EPPP7900 |
Shaft |
A3EPPP7802 |
Frame |
A3EPPP1300 |
Bushing |
A3EPPP7M02 |
Frame |
A3EPPP7J01 |
Frame |
A3EPPPAK00 |
Belt Assy |
A3EPPPAP00 |
Arm |
A3EPPP7U01 |
Torsion Coil spring |
A3EPPP7701 |
Frame |
A3EPPPAQ01 |
Pin |
A3EPPP7L02 |
Shaft |
A3EPPPB501 |
Screw |
V217040001 |
E Ring |
A3EPPP7302 |
Frame |
A3EPPP8301 |
Plate Spring |
A3EPPP1300 |
Bushing |
A3EPPP8A00 |
Timing Belt |
A3EPPP6U01 |
Pulley |
A3EPPP6X00 |
Pin |
A3EPPP6V01 |
Hinge |
A3EPPP6R01 |
Arm |
A3EPPP6Q00 |
Pin |
A3EPPPAM00 |
Drum |
A3EPPP8D01 |
Adjusting Plate Assy |
A3EPPPAL00 |
Pulley |
A3EPPP8701 |
Belt |
A3EPPP8601 |
Roll |
A3EPPP8900 |
Pulley |
A3EPPP8802 |
Bracket |
A108M50100 |
Photointerrupter |
A3EPPP8C01 |
Cover |
A0EDM50100 |
Photoreflector |
A3EPPP7202 |
Frame |
A3EPPP8B00 |
Timing Belt |
A3EPPP7100 |
Timing Belt |
A3EPPP7002 |
Pulley |
A3EPPPAQ01 |
Pin |
A3EPPP6Y01 |
Shaft |
A3EPPPC801 |
Wire Harness Assy |
A3EPPPD800 |
Guide |
A3EPPPB501 |
Screw |
A3EPPPAY01 |
Screw |
A3EPPPBA01 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3EPPP5E01 |
Cam |
A3EPPP1300 |
Bushing |
A3EPPP5G01 |
Actuator |
4004454001 |
BALL BEARING |
A3EPPPBC00 |
Label |
A3EPPP6B01 |
Guide Plate |
A3EPPP6M01 |
Film |
A3EPPP6K01 |
Film |
A3EPPP4H03 |
Roller |
A3EPPP6A01 |
Guide Plate |
A3EPPP5500 |
Motor Assy |
A3EPPPCS00 |
Bracket |
A108M50100 |
Photointerrupter |
A3EPPP5H00 |
Timing Belt |
A3EPPP6C02 |
Gear |
A3EPPP5B00 |
Gear |
A3EPPP1101 |
Bushing |
A3EPPP5F02 |
Guide Plate |
A3EPPP5801 |
Shaft |
A3EPPP5J02 |
Guide Plate |
A3EPPPCR00 |
Micro Switch |
A3EPPP6902 |
Plate Spring |
A3EPPP6801 |
Guide |
A3EPPP6N01 |
Neuralizing Brush |
A3EPPP6P01 |
Neuralizing Brush |
A3EPPPD300 |
Paddle Assy |
A3EPPPD400 |
Paddle Assy |
A3EPPP6000 |
Torsion Coil spring |
V217040001 |
E Ring |
V217060001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPAY01 |
Screw |
V218040086 |
E ring |
A3EPPPB401 |
Screw |
A3EPPPB901 |
Screw |
A3EPPP6300 |
Regulating Plate |
A3EPPP6501 |
Reinforce Plate |
A3EPPP6401 |
Reinforce Plate |
A3EPPP6201 |
Cover |
A3EPPP5U01 |
Cover |
A3EPPP5V01 |
Reinforce Plate |
A3EPPP5X01 |
Reinforce Plate |
A3EPPP5P00 |
Regulating Plate |
A3EPPP5N01 |
Cover |
A108M50100 |
Photointerrupter |
A3EPPP5Y01 |
Bracket |
A3EPPP5500 |
Motor Assy |
A3EPPP5R01 |
Pulley |
A3EPPP5C00 |
Timing Belt |
A3EPPP6J00 |
Shaft |
A3EPPP5Q00 |
Timing Belt |
A3EPPP6701 |
Torsion Coil spring |
A3EPPP5T02 |
Pulley |
A3EPPP5K00 |
Shaft |
A3EPPP5M01 |
Drum |
A3EPPPCT00 |
Frame |
A3EPPP5L00 |
Shaft |
A3EPPPCU00 |
Frame |
A3EPPP6601 |
Bracket |
A3EPPPBM01 |
Pressure Spring |
A3EPPPC700 |
Wire Harness Assy |
A3EPPPC000 |
Wire Harness Assy |
A3EPPPBA01 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPAY01 |
Screw |
V217030001 |
E Ring |
A3EPPPB301 |
Screw |
V217040001 |
E Ring |
A108R90000 |
PHOTO INTERRUPTER |
A3EP820100 |
Guide /1 |
A3EP819001 |
Guide /Upper |
A3EP811100 |
Support Plate /1 |
A3EP811800 |
Support Plate /4 |
A3EP812500 |
Idler Plate spring /2 |
A0HR212700 |
Idler Roll /1 |
A3EP812100 |
Idler Shaft /1 |
A3EP814300 |
Ground Spring /2 |
A3EP812200 |
Idler Plate spring /1 |
A3EP811201 |
Support Plate /2 |
A3EP822800 |
Holding Part /1 |
A3EP822600 |
Sheet |
A3EP814600 |
Cover /Front |
A3EP822900 |
Holding Part /2 |
A3EP814200 |
Ground Spring /1 |
A3EP822100 |
Guide /7 |
A3EP822201 |
Holder |
A3EP822300 |
Holding Part /1 |
A3EP822500 |
Holding Sheet /2 |
A3EP822400 |
Holding Sheet /1 |
A3EP822700 |
Lever |
A3EPN10200 |
Sensor Relay harness |
V153030804 |
screw |
V153030803 |
Screw |
V217030001 |
E Ring |
V153031003 |
screw |
A3EP814700 |
Cover/Rear |
A3EP812000 |
Regulating Part /1 |
A3EP815500 |
Ground Spring /3 |
A3EP811700 |
Support Plate /3 |
A3EP815000 |
Fixing Plate /3 |
A3EP815200 |
Positioning Shaft /2 |
A3EP821800 |
Cover Part |
A3EP813900 |
Lock Part /2 |
A108R90000 |
PHOTO INTERRUPTER |
A0HR701200 |
Mounting Plate |
A3EP821600 |
Regulating Part /3 |
V153030804 |
screw |
V121030604 |
Screw |
V153030803 |
Screw |
A0HRM10000 |
Stepping motor |
A3EP810700 |
Mounting Plate /1 |
A3EP815400 |
Ground Plate /3 |
A0HR213600 |
Flange |
A3EP810900 |
Belt/1 114L |
A0HR210200 |
Pulley 14/26T |
A3EP820300 |
Belt/3 276L |
A0HR210300 |
Flange |
A0HR210900 |
Drive Belt /2 |
A0HR211000 |
Pulley 28T |
A3EP816200 |
Drive Pulley/1 28T |
07BA15930 |
SPACER B |
A3EP816500 |
Fixing Plate /5 |
A00J617800 |
BALL BEARING |
A3EP810800 |
Fixing Plate /1 |
A3EP814800 |
Fixing Part /2 |
A3EP814900 |
Guide /6 |
A3EP819801 |
Actuator |
A3EP821700 |
Sensor Spring /1 |
A108R90000 |
PHOTO INTERRUPTER |
A3EP810001 |
Guide /Lower |
A3EP810600 |
Roller /1 |
A3EP822000 |
Bushing |
A3EP811500 |
Roller /2 |
A3EPN10100 |
Sensor Relay harness |
A3EPN10000 |
I/F Wiring |
V153030803 |
Screw |
V116030603 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3EPPPBF01 |
Harness Assy |
A3EPPPBU01 |
Wire Harness Assy |
A3EPPPBX01 |
Wire Harness Assy |
A3EPPPC900 |
Wire Harness Assy |
A3EPPPCM00 |
Wire Harness Assy |
V500010005 |
saddle |
V500010007 |
saddle |
V500010020 |
Saddle |
V500010046 |
saddle |
V570010021 |
Saddle |
V570010026 |
saddle |
A3EP115100 |
Mounting Plate /Rear |
A3EP115001 |
Mounting Plate /Front |
A3EP810500 |
Guide /3 |
A3EP116500 |
Mounting Plate /Rear |
A3EP116400 |
Mounting Plate /Front |
A3EP810400 |
Guide /2 |
A3EP957100 |
Mounting Plate |
A3EPPP1C01 |
Mounting Plate |
A3EPPP1D01 |
Mounting Plate |
V116040803 |
Screw |
V116031603 |
Screw |
A3EPPPB101 |
Screw |
V153030803 |
Screw |
A02E193400 |
Shoulder screw |
A3ERPP1E01 |
Cover/Front |
A3ERPP1G01 |
Lever |
A3ERPP1P00 |
Torsion Spring |
A3ERPP1M00 |
Shaft |
A3ERPP6Q00 |
Label |
A3ERPP6P01 |
Label |
A3EPPPB801 |
Screw |
V217040001 |
E Ring |
A3ERPP1F01 |
Mounting Plate |
A3ERPP4P00 |
Shaft |
A3ERPP1401 |
Stay |
A3ERPP1301 |
Stay |
A3ERPP1J01 |
Stay |
A3ERPP1C01 |
Cover |
A3ERPP1201 |
Stay |
A3ERPP1801 |
Mounting Plate |
A3ERPP1T00 |
Sheet |
A3EPPPB601 |
Screw |
A3EPPPBQ01 |
Screw |
A3ERPP1R01 |
Sheet |
A3ERPP6J01 |
PWB |
A3ERPP1B02 |
Mounting Plate |
A3ERPP1K00 |
Shaft |
A3ERPP1S01 |
Cover |
A3ERPP1D01 |
Guide |
A3ERPP1701 |
Guide |
A3ERPP1A01 |
Lock Lever |
A3ERPP1600 |
Roll |
A3ERPP1L00 |
Shaft |
A3ERPP1N01 |
Tension Spring |
A3ERPP1903 |
Mounting Plate |
A3EPPPB101 |
Screw |
A3EPPPB601 |
Screw |
A3EPPPB701 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3ERPP4S00 |
Motor |
A3ERPP7Q00 |
Neutralizing Brush |
A3ERPP4701 |
Mounting Plate |
A3ERPP4B01 |
Gear 24/46T |
A3ERPP4E00 |
Gear 15/40T |
A3ERPP4F01 |
Gear 34/80T |
A3ERPP4U02 |
Gear 28/96T |
A3ERPP4T01 |
Gear 24/60T |
A3ERPP4301 |
Mounting Plate |
A3ERPP3X01 |
Mounting Plate |
A108M50100 |
Photointerrupter |
A3ERPP4900 |
Holder |
A3EPPP1101 |
Bushing |
A3ERPP4V01 |
Plate |
A3ERPP4201 |
Slide Plate |
A3ERPP4K00 |
Shaft |
A3ERPP4A01 |
Gear 46T |
A3EPPPAS01 |
Pin |
A3EPPP1201 |
Bushing |
A3ERPP3Y01 |
Mounting Plate |
A3ERPP4J00 |
Shaft |
A3ERPP4101 |
Stay |
A3ERPP4001 |
Mounting Plate |
A3EPPPB601 |
Screw |
V217060001 |
E Ring |
A3EPPPBQ01 |
Screw |
V217040001 |
E Ring |
A3EPPPB001 |
Screw |
A3ERPP4Q01 |
Gear |
A3ERPP4N01 |
Roller |
A3ERPP4802 |
Guide Plate |
A3ERPP4R01 |
Plate |
A3ERPP4G01 |
Gear |
A3EPPPAS01 |
Pin |
A3ERPP5E00 |
Gear 20T |
A3ERPP4L00 |
Shaft |
A3ERPP4H00 |
Gear 38T |
A3ERPP4M02 |
Tension Spring |
A3ERPP4401 |
Arm |
A3EPPP1201 |
Bushing |
4004454001 |
BALL BEARING |
A3ERPP5701 |
Gear 46T |
A3ERPP5801 |
Gear 15/93T |
A3ERPP5101 |
Mounting Plate |
A3ERPP5R00 |
Motor |
A108M50100 |
Photointerrupter |
A3EPPP1101 |
Bushing |
A3ERPP3N00 |
Motor |
A3ERPP5202 |
Mounting Plate |
A3ERPP5P00 |
Seal |
A3ERPP5N00 |
Seal |
A3ERPP5Q00 |
Seal |
A3ERPP4Y01 |
Guide |
A3ERPP5M01 |
Bushing |
A3ERPP7K00 |
Pressing Spring |
A3ERPP5J01 |
Roller |
A3ERPP5S00 |
Gear 38T |
A3ERPP4C00 |
Gear 17T |
A3ERPP4D00 |
Gear 14T |
A3ERPP4601 |
Mounting Plate |
A3ERPP4501 |
Arm |
A3EPPP2501 |
Screw |
A3EPPPB001 |
Screw |
V217060001 |
E Ring |
A3EPPPB601 |
Screw |
A3ERPP6K01 |
Screw |
A3EPPPAY01 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A3ERPP5A00 |
Bushing |
A3ERPP5500 |
Gear |
A3ERPP6401 |
Seal |
A3ERPP4X01 |
Guide Plate |
A3ERPP6501 |
Seal |
A3ERPP5403 |
Guide |
A02E193400 |
Shoulder screw |
A3ERPP7K00 |
Pressing Spring |
A3ERPP5M01 |
Bushing |
4030104002 |
CATCH |
A3ERPP5900 |
Roll |
A3ERPP5H00 |
Shaft |
A3EPPP1400 |
Bushing |
A3EPPPAR01 |
Pin |
A3ERPP5C00 |
Gear |
A3ERPP5D01 |
Knob |
A3ERPP6101 |
Shoulder Screw |
A3EPPP1201 |
Bushing |
A3ERPP6301 |
Seal |
A3ERPP5B02 |
Guide Plate |
A0EDM50100 |
Photoreflector |
A3ERPP6201 |
Auxiliary Plate |
A3ERPP5F01 |
Gear 15T |
A3ERPP5G02 |
Gear 13T |
A3ERPP1101 |
Pin |
A3ERPP7M01 |
Tension Spring |
A3ERPP5302 |
Mounting Plate |
A3ERPP5L01 |
Roller |
A3ERPP5Y01 |
Neutralizing Brush |
A3ERPP5002 |
Guide Plate |
A3ERPP5K01 |
Roller |
A3ERPP5602 |
Mounting Plate |
A3ERPP5X00 |
Bushing |
A3ERPP6S00 |
Label |
A3ERPP6U00 |
Label |
A3ERPP7H00 |
Wire Harness Assy |
A3ERPP7401 |
Bracket |
A3ERPP7201 |
Bracket |
A3ERPP7302 |
Tension Spring |
A3ERPP7102 |
Bracket |
V217040001 |
E Ring |
V218040086 |
E ring |
A3EPPPCJ01 |
Screw |
V217060001 |
E Ring |
A3ERPP6L01 |
Screw |
A3EPPPB601 |
Screw |
A3ERPP8200 |
Screw |
A3EPPP1101 |
Bushing |
A3ERPP2J02 |
Guide |
A3EPPP3702 |
Roll |
A3ERPP2A00 |
Shaft |
A3ERPP2N01 |
Tension Spring |
A108M50100 |
Photointerrupter |
A3ERPP2B00 |
Torsion Spring |
A3ERPP2101 |
Actuator |
A3ERPP2301 |
Guide |
A3EPPP1300 |
Bushing |
A3ERPP2P01 |
Cushion |
A3EPPPAQ01 |
Pin |
A3ERPP2401 |
Lever |
A3ERPP6X01 |
Pressure Spring |
A3ERPP2901 |
Lever |
A3ERPP2E01 |
Gear 30T |
A3ERPP2G00 |
Timing Belt |
A3ERPP1X01 |
Mounting Plate |
A3ERPP2F00 |
Motor |
A3ERPP3N00 |
Motor |
A3ERPP2700 |
Gear 16/88T |
A3ERPP6V01 |
Tension Spring |
A3ERPP2800 |
Gear 50T |
A3ERPP2C00 |
Torsion Spring |
A3ERPP2L00 |
Torsion Spring |
A3ERPP1V02 |
Guide |
A3ERPP2001 |
Mounting Plate |
A3ERPP2201 |
Guide |
A3ERPP2D01 |
Roller |
A3ERPP1U02 |
Guide |
A3ERPP6R00 |
Label |
A3ERPP7800 |
Wire Harness Assy |
A3ERPP7D01 |
Wire Harness Assy |
A3ERPP7701 |
Wire Harness Assy |
A3ERPP7C01 |
Wire Harness Assy |
V217040001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
V217030001 |
E Ring |
V218040086 |
E ring |
A3EPPPAY01 |
Screw |
A3ERPP3Q01 |
Mounting Plate |
A3ERPP3R02 |
Cover |
A3ERPP3V01 |
Neutralizing Brush |
A3ERPP3U02 |
Seal |
A3ERPP3T01 |
Seal |
A10D929300 |
Stapler Unit |
A3ERPP3S01 |
Seal |
A3ERPP7900 |
Wire Harness Assy |
A10DP00100 |
STAPLE CARTRIDGE |
A3ERPP7W01 |
Seal |
A3ERPP7V00 |
Seal |
A3ERPP7X01 |
Seal |
A3EPPPB601 |
Screw |
A3EPPPBQ01 |
Screw |
A3ERPP5T00 |
Gear 26T |
A3ERPP1001 |
Pin |
A3EPPP1101 |
Bushing |
A3ERPP5U00 |
Shaft |
A3ERPP3N00 |
Motor |
A3ERPP5V00 |
Gear 34T |
A3ERPP3E00 |
Pressing Spring |
A3ERPP3B02 |
Regulating Plate |
A3ERPP3C02 |
Rack |
A3ERPP3D01 |
Gear 14/44T |
A0EDM50100 |
Photoreflector |
A108M50100 |
Photointerrupter |
A3ERPP3A02 |
Regulating Plate |
A3ERPP3901 |
Mounting Plate |
A3ERPP2E01 |
Gear 30T |
A3ERPP3J00 |
Timing Belt |
A3ERPP3K01 |
Gear 30T |
A3ERPP2R00 |
Roller |
A092145400 |
Shoulder screw |
A3ERPP2T01 |
Mounting Plate |
A3ERPP3M00 |
Motor |
A3ERPP7Y00 |
Paddle Assy |
A3ERPP3801 |
Paddle Assy |
A3ERPP6Y02 |
Cover |
A3ERPP7Z00 |
Shaft |
V217040001 |
E Ring |
A3EPPPB601 |
Screw |
A3EPPPB401 |
Screw |
A3EPPPAY01 |
Screw |
A3EPPPB101 |
Screw |
V217030001 |
E Ring |
V218040086 |
E ring |
A3ERPP7N01 |
Guide Plate |
A3ERPP3G01 |
Seal |
A3ERPP3301 |
Stopper |
A3ERPP3601 |
Shaft |
A3ERPP3101 |
Arm |
A3ERPP3201 |
Arm |
A3ERPP3P01 |
Cushion |
A3ERPP3L01 |
Plate Spring |
A3ERPP3401 |
Lever |
A3ERPP3000 |
Lever |
A3ERPP3701 |
Torsion Spring |
A3ERPP3F01 |
Pressing Spring |
A10DM20000 |
Plunger solenoid |
A3ERPP2V00 |
Holder |
A3ERPP2U00 |
Holder |
A3ERPP3500 |
Shaft |
A3ERPP2R00 |
Roller |
A3ERPP3H00 |
Timing Belt |
A3ERPP2Y00 |
Gear 20T |
A3ERPP7001 |
Tension Spring |
A3ERPP2Q01 |
Tension Plate |
A3ERPP2X00 |
Gear |
A108M50100 |
Photointerrupter |
A3ERPP2S03 |
Mounting Plate |
A3ERPP3N00 |
Motor |
A3ERPP2M01 |
Seal |
A3ERPP1Y01 |
Guide |
A3ERPP2K01 |
Guide |
A3ERPP2602 |
Guide |
A3ERPP2H02 |
Guide |
A3ERPP2C00 |
Torsion Spring |
A3ERPP2503 |
Guide |
A3ERPP2L00 |
Torsion Spring |
A3ERPP6T00 |
Label |
A3ERPP7U00 |
Seal |
A3ERPP7F01 |
Wire Harness Assy |
A3EPPPB601 |
Screw |
A3EPPPBN01 |
Screw |
V217040001 |
E Ring |
A3EPPPAY01 |
Screw |
A3EPPPBA01 |
Screw |
A3EPPPB101 |
Screw |
A2Y2899500 |
Paper exit Guide |
A2Y2894101 |
Lifting Part |
A2Y2895300 |
Conveyance Pulley |
A2Y2898500 |
Idling Shaft |
13GQ76020 |
SHAFT HOLDER A |
A2Y2899301 |
Mounting Pedestal |
A108M50100 |
Photointerrupter |
A2Y2897500 |
Drive Cover |
A2Y2897702 |
Handle /1 |
A2Y2897800 |
Handle /2 |
V137030603 |
screw |
V217040050 |
E ring |
V153031003 |
screw |
V137030803 |
screw |
V149030804 |
screw |
V153030803 |
Screw |
V149031003 |
screw |
A2Y2897400 |
Frame /2 |
A2Y2895900 |
Rotation Guide /Rear |
A2Y2900300 |
Holding Part /2 |
A2Y2895600 |
Rotation Guide /Front |
A2Y2892000 |
Paper exit Belt |
A2Y2895300 |
Conveyance Pulley |
A2Y2894200 |
Handle /3 |
A2Y2896801 |
Drive Shaft |
A2Y2896500 |
Drive Gear 22T |
322076010 |
PAPER LIFT UP LEVER SHAFT HOLDER |
13GQ76020 |
SHAFT HOLDER A |
A0HR894200 |
Connecting Pin |
V153030803 |
Screw |
V217040050 |
E ring |
V192030409 |
screw |
A2Y2G89000 |
Positioning Plate Caulking |
56QA75060 |
Drive Bearing /6 |
A2Y2897100 |
Up/down Worm |
A2Y2899900 |
Drive Shaft /2 |
A2Y2898600 |
Drive Gear 42T |
A2Y2898300 |
Torsion Spring |
A2Y2898000 |
Up/down Actuator |
A2Y2898200 |
Up/down Part |
A2Y2897900 |
Up/down Spring |
A108M50100 |
Photointerrupter |
A2Y2899700 |
Cover |
A2Y2898801 |
Mounting Plate |
A2Y2N10001 |
Drive Wiring |
A0PNM10200 |
DC Brushless motor /20 |
A2Y2899800 |
Drive Base frame |
V137030603 |
screw |
V217040050 |
E ring |
V237301050 |
pin |
V192030409 |
screw |
A2Y2896900 |
Paper exit Guide /Lower |
A2Y2893900 |
Neutralizing Sheet /2 |
A2Y2894501 |
Neutralizing Sheet /1 |
A2Y2896300 |
Hold Part |
A2Y2893100 |
Torsion Coil spring |
A2Y2896200 |
Pressing Part |
A11R921400 |
Paper exit Roller |
A2Y2893000 |
Torsion Coil spring |
A2Y2890701 |
Holding Part |
A2Y2894000 |
Holding Sheet |
A11R893200 |
Holding Roller /1 |
A2Y2893700 |
Holding Arm /F |
A2Y2893200 |
Holding Arm /R |
A2Y2893802 |
Paper exit Guide |
A2Y2896400 |
Guide Part |
A2Y2897000 |
Paper exit Sheet |
V153031003 |
screw |
V137030603 |
screw |
A3ERPP7E00 |
Wire Harness Assy |
A3ERPP7600 |
Wire Harness Assy |
A3ERPP7B00 |
Wire Harness Assy |
A3ERPP7A01 |
Wire Harness Assy |
V500010005 |
saddle |
V500010020 |
Saddle |
V500010046 |
saddle |
V501010001 |
band |
V570010021 |
Saddle |
V570010026 |
saddle |
V500010003 |
Saddle |
A3ERPP1501 |
Mounting Plate |
A3ERPP8100 |
Cushion |
A3ERPP1Q00 |
Rail |
A2Y2900000 |
Mounting Plate /S |
A2Y2893300 |
Paper exit Cover |
A2Y2900101 |
Mounting Plate /T |
A2Y2900200 |
Guide /4 |
A3ERPP6K01 |
Screw |
V116040603 |
Screw |
V116040803 |
Screw |
V137030603 |
screw |
V153031003 |
screw |
A11P160402 |
Cover Plate /A |
A07R160700 |
Screw Cover |
A11P162302 |
Cover Plate /3 |
A11P162205 |
Cover Plate /2 |
A07R161500 |
Preventing Part /1 |
A11P162102 |
Cover Plate /1 |
A11P162001 |
Cover Plate /Right |
A2Y1162900 |
Guide /1 |
300011191 |
MAGNET HOLDER PLATE |
A2Y1163000 |
Guide /2 |
A2Y1163100 |
Guide /3 |
A11P160601 |
Cover Plate |
12AR12161E |
ACTUATOR |
A11P160105 |
Open/close Door /Front |
A2Y1940100 |
Processing Label |
A2Y1160200 |
Cover Plate /C |
A2Y1161000 |
Cover Plate /B |
A11P160701 |
Cover Plate /5 |
A11P162703 |
Ground Plate /1 |
A11P162801 |
Neutralizing Brush /1 |
V114040804 |
screw |
V153040803 |
screw |
V153031003 |
screw |
V147041003 |
screw |
V137030603 |
screw |
V153030803 |
Screw |
A11P105101 |
Support Plate /C |
A11P104400 |
Wiring Plate /1 |
A11T955400 |
Mounting Plate /B |
13QE49150 |
PROTECTION PART |
08AA85512 |
Photo Sensor |
13GL46720 |
Fixing Plate |
A2Y1107600 |
Stopper Guide |
A11P104000 |
Support Plate /7 |
A11P102703 |
Support Plate /B |
A11P102201 |
Support Plate /A |
A2Y1N10600 |
Interlock Wiring /1 |
A11PR74911 |
Idler Roll Assy |
A11P709802 |
Pressing Spring /2 |
A11P707300 |
Registration Shaft /1 |
A11P707200 |
Support Plate /15 |
A11P713200 |
Sheet /M |
A11P703801 |
Plate/5 |
A11P704801 |
Registration Plate /1 |
9335191052 |
SOLID STATE SWITCH |
A11P712500 |
Support Plate /11 |
A2Y1100500 |
Auxiliary Stay |
A2Y1100600 |
Reinforce Stay /2 |
A11P105501 |
Support Plate /1 |
4030104002 |
CATCH |
A11P103901 |
Support Plate /6 |
07BA12352 |
MAGNET CATCH |
A11P105401 |
Positioning Plate |
A11P105701 |
Ground Plate /2 |
9J08112601 |
CUSHION |
9J08112701 |
SPACER |
A11P106000 |
Actuator |
12QR12260 |
SWITCH INSULATING SHEET |
12QR86011 |
Interlock Switch |
55FA12101 |
MAGNET CATCH X |
12QR12190 |
COVER |
4348201001 |
CASTOR |
129U10350 |
CARRIAGE ROLLER 1 |
A2Y1105300 |
Reinforce Plate /1 |
A11P161501 |
Support Plate /5 |
A2Y1103401 |
Reinforce Stay /3 |
A11P105802 |
Mounting Plate /1 |
20AF97030 |
SEPARATION PROCESSING LABEL |
A2Y1N11400 |
Sensor Relay harness |
V137030603 |
screw |
V144030603 |
Screw |
V116030603 |
Screw |
V137040803 |
SCREW |
V116040603 |
Screw |
V217040050 |
E ring |
V118030603 |
screw |
V126030603 |
screw |
V118031603 |
screw |
V118021003 |
screw |
V116040803 |
Screw |
V121041203 |
screw |
V195A20003 |
nut |
V144040603 |
SCREW |
V144030803 |
SCREW |
A11P130300 |
Wiring Plate /2 |
A11P161400 |
Support Plate /4 |
A11P130200 |
Wiring Plate /1 |
A2Y1H10002 |
PWB Assembly(PWB-MC ASSY) |
A11P161101 |
Support Plate /1 |
A11P161300 |
Support Plate /3 |
A2Y1130100 |
Mounting Plate |
A2Y1130400 |
Wiring Plate /3 |
A2Y1895101 |
Paper exit Sheet |
A2Y1894000 |
Paper exit Plate /A |
A11P902001 |
Reinforce Stay /1 |
A2Y1895900 |
Paper exit Cover |
A11P162501 |
Support Plate /Lower |
A11P161600 |
Support Plate /6 |
A11P160501 |
Support Plate /Upper |
A11P103500 |
Cover Part /1 |
A2Y1104900 |
Support Plate /12 |
V651010017 |
connector |
V137030603 |
screw |
V137040603 |
screw |
V118040403 |
screw |
V137040803 |
SCREW |
V116040803 |
Screw |
V118040803 |
screw |
A2Y1724400 |
Drive Shaft /1 |
A11P724301 |
Swing Cam /1 |
A11P726900 |
Swing Spring /1 |
A11P724201 |
Regulating Plate /2 |
A11P724102 |
Regulating Plate /1 |
A11P724000 |
Mounting Plate /1 |
A11PM10200 |
DC Brushless motor /12 |
A2Y1735400 |
Mounting Plate |
A2Y1735600 |
Adjusting Spring |
13GQ45490 |
COLLAR B |
A2Y1729400 |
Holding Plate |
A2Y1725800 |
Drive Belt/5 144L |
13GQ45480 |
COLLAR A |
A2Y1724600 |
Pulley/11 24T |
A083M10000 |
Stepping motor |
A108M50100 |
Photointerrupter |
A11P726000 |
Light blocking Plate /4 |
A2Y1735300 |
Drive Belt/3 208L |
A2Y1894100 |
Drive Pulley 27T |
4131253701 |
BUSHING |
A2Y1724900 |
Pulley/9 27/51T |
A2Y1725700 |
Drive Belt/4 144L |
A2Y1725000 |
Pulley/6 17T |
A11PR72111 |
Swing Plate/1 Cauking Assy |
13QA17730 |
COLLAR 6 |
A2Y1724500 |
Idling Pulley/1 17T |
A2Y1R70100 |
Paddle Assy |
12QV40660 |
SHAFT POSITIONING PART |
A2Y1725400 |
Drive Belt/1 146L |
A2Y1723200 |
Idling Pulley/2 17/17T |
A2Y1725600 |
Drive Belt/2 176L |
A2Y1725500 |
Drive Pulley/1 17T |
A2Y1R70000 |
Paddle Assy |
A11PR72011 |
Swing Plate/2 Cauking Assy |
A2Y1724800 |
Mounting Plate /2 |
A0P0663600 |
Bushing |
A11PR72211 |
Swing Plate/1/2 Cauking Assy |
A2Y1723800 |
Drive Shaft /2 |
V237301250 |
pin |
V217040050 |
E ring |
V116030603 |
Screw |
V137030603 |
screw |
V118030603 |
screw |
V118030403 |
screw |
V237201050 |
Pin |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P709200 |
Pressing Spring /1 |
A11P708600 |
Idler Shaft /A |
A11P701001 |
Guide Plate /F |
12ER40350 |
STICKING PART |
A11PR70500 |
Part/4 Assy |
A11P711301 |
Guide Plate /M |
A11P710000 |
Sheet /S |
A11P705000 |
Sheet /Q |
A11P716400 |
Sheet /D |
A11P709900 |
Sheet /R |
A11P709300 |
Attaching Part |
A11P703300 |
Positioning Spring /1 |
A11P711400 |
Holding Plate /6 |
A11P702200 |
Holding Plate /6 |
A11P701500 |
Support Plate /16 |
A11PR70300 |
FNS Solenoid/1/1 Assy |
A11PR70400 |
Part/1 Assy |
A11P711200 |
Guide Plate /L |
A11P711501 |
Holding Plate /7 |
A2Y1N11000 |
Drive Wiring |
V217030001 |
E Ring |
V217020001 |
E ring |
V137030603 |
screw |
V116030504 |
Screw |
A11P700302 |
Guide Plate /N |
20AK48090 |
ACTUATOR /2 |
20AK48080 |
SPRING /2 |
A1V4R90000 |
Photointerrupter |
A11P716701 |
Support Plate /C |
A11P703100 |
Block |
A11P703001 |
Plate /2 |
A11P714300 |
Stopper Part |
A11P715101 |
Support Plate /A |
A11P708500 |
Plate/4 |
A11P899901 |
Support Plate /10 |
A11P104800 |
Support Plate /11 |
13QA85511 |
Sensor 1 |
A11P709700 |
Support Plate /5 |
A11P104700 |
Support Plate /10 |
A11P710300 |
Holding Plate /5 |
A11PR70200 |
FNS Solenoid/1/2 Assy |
A11P701101 |
Guide Plate /5 |
A11P710200 |
Pressing Spring /4 |
A11P714701 |
Idler Shaft /2 |
A2Y1708000 |
Paper exit Roll |
A11P708800 |
Guide Plate /K |
13QA41420 |
SUPPORT SHEET |
A11P717802 |
Light blocking Case |
A11P715500 |
Guide Plate /R |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P708600 |
Idler Shaft /A |
A11P709200 |
Pressing Spring /1 |
A11P701900 |
Guide Plate /I |
A11P718900 |
Sheet /L |
A2Y1714200 |
Neutralizing Brush /2 |
A2Y1N11800 |
Sensor Relay harness |
V137030603 |
screw |
V153030803 |
Screw |
V116030603 |
Screw |
V118030603 |
screw |
V116030504 |
Screw |
V217030050 |
E ring |
V217030001 |
E Ring |
V144030603 |
Screw |
V217020001 |
E ring |
13QE49140 |
TENSION PULLEY |
A11PR72700 |
Tension Plate/Rear Cauking Assy |
A11P103600 |
Plate/2 |
A1V4R90000 |
Photointerrupter |
A2Y1100700 |
Mounting Plate /1 |
A2Y1M50000 |
Detection Sensor |
A11P904200 |
Slide Shaft |
13QE49160 |
GUIDE ROLLER |
13QE49131 |
ACTUATOR 1 |
A11P905200 |
Neutralizing Brush |
15JK491700 |
UP/DOWN PLATE /1 |
A11P892500 |
Bushing /1 |
A2Y1890500 |
Paper exit Actuator |
A11P901300 |
Support Part |
14JS77030 |
UP DOWN GEAR C 23T |
A11P890702 |
Support Plate /2 |
A2Y1894600 |
Up/down Stay |
A2Y1M50100 |
Detection Sensor |
A2Y1100800 |
Mounting Plate /2 |
15JK-1130 |
TENSION PLATE FRONT CAULKING |
A2Y1896400 |
Up/down Wire /F |
500075010 |
BALL BEARING |
12QR48070 |
UP DOWN PULLEY |
A11P899200 |
Up/down Shaft |
A11P101000 |
Plate |
A11P105900 |
Mounting Plate |
13QE49150 |
PROTECTION PART |
A2Y1896500 |
Up/down Wire /R |
A11P899300 |
Reinforce Plate /1 |
A2Y1N12001 |
Sensor Relay harness |
A11PR72500 |
Tension Plate/Front Assy |
A11PR72600 |
Tension Plate/Rear Assy |
A108R90000 |
PHOTO INTERRUPTER |
A108M50100 |
Photointerrupter |
V217060001 |
E Ring |
V116040603 |
Screw |
V137030603 |
screw |
V116030603 |
Screw |
V118031003 |
screw |
V217030050 |
E ring |
V118040603 |
screw |
V217080050 |
E ring |
V237302050 |
Pin |
V116030504 |
Screw |
V118030403 |
screw |
V137040803 |
SCREW |
A11T955001 |
Swing Rail /1 |
A2Y1700500 |
Sensor Plate /1 |
A0EDM50100 |
Photoreflector |
A11P702701 |
Support Plate /3 |
A11P706000 |
Idler Roll /1 |
A2Y1702500 |
Idler Shaft /3 |
A2Y1708400 |
Pressing Spring /3 |
A11P104101 |
Support Plate /8 |
A11P702900 |
Mounting Plate /1 |
A11PR70200 |
FNS Solenoid/1/2 Assy |
A11P104201 |
Support Plate /9 |
A2Y1713801 |
Support Plate /9 |
A2Y1711800 |
Guide Plate /P |
A2Y1713700 |
Support Plate /8 |
A11P713300 |
Sheet /N |
A2Y1700800 |
Guide Plate /4 |
A2Y1N10900 |
Drive Relay harness |
A2Y1N10800 |
Drive Wiring |
V116040803 |
Screw |
V137030603 |
screw |
V217030050 |
E ring |
V217020050 |
E ring |
V116030603 |
Screw |
V116030504 |
Screw |
V144030603 |
Screw |
V125030818 |
Screw |
A11P717200 |
Guide Lever /4 |
A11P717001 |
Guide Lever /2 |
A11P710500 |
Guide Sheet /2 |
A11P715600 |
Idling Shaft |
A11P713400 |
Guide Pulley /2 |
15JL775400 |
GUIDE BELT 92L |
A11P713500 |
Holding Part /2 |
A11P717500 |
Guide Pulley/2 27T |
A11P717600 |
Holding Part /3 |
A11P718001 |
Guide Lever /7 |
12QR50700 |
BELT HOLDER B |
A11P715700 |
Guide Belt 112L |
12QR76680 |
ENTRANCE GUIDE PULLEY A34T |
A11P707900 |
Guide Lever /1 |
A11P708901 |
Paper exit Roller /Lower |
A00J617900 |
Ball Bearing |
15AJ50460 |
PUNCH SPACER |
A2Y1719900 |
Pulley/4 20T |
13GQ45480 |
COLLAR A |
A2Y1706500 |
Drive Belt/4 189L |
A11P717101 |
Guide Lever /3 |
A11P710400 |
Guide Sheet /1 |
A11P717300 |
Guide Lever /5 |
A11P718101 |
Guide Lever /8 |
A11P717400 |
Guide Lever /6 |
14GE45470 |
Rotation Knob |
A2Y1940900 |
Release Label /8 |
V217060001 |
E Ring |
V237201250 |
Pin |
V116030603 |
Screw |
V217040001 |
E Ring |
V237301650 |
pin |
V217060050 |
E ring |
V217040050 |
E ring |
A11P890000 |
Drive Roller /A |
122H48251 |
PAPER EXIT ROLLER A |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P709200 |
Pressing Spring /1 |
A11P708600 |
Idler Shaft /A |
A11P101301 |
Support Plate /2 |
A03U812800 |
Slide Shaft Holder |
15AJ50460 |
PUNCH SPACER |
A2Y1894400 |
Pulley/2 40T |
A2Y1940500 |
Release Label /4 |
A11P709100 |
Support Shaft /2 |
A11P704401 |
Torsion Spring /2 |
A11P701203 |
Guide Plate /6 |
A11P733600 |
Attaching Part /1 |
56AA40490 |
SHAFT STOPPER 4 |
A11P701303 |
Guide Plate /7 |
A11P704100 |
Torsion Spring /1 |
A11P106200 |
Support Shaft /8 |
A11P717901 |
Reinforce Stay |
A2Y1714200 |
Neutralizing Brush /2 |
V217060050 |
E ring |
V116030603 |
Screw |
V137030603 |
screw |
A11P717901 |
Reinforce Stay |
A11P704600 |
Torsion Spring /4 |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P709200 |
Pressing Spring /1 |
A11P708600 |
Idler Shaft /A |
56AA40490 |
SHAFT STOPPER 4 |
A11P701702 |
Guide Plate /9 |
A11P704500 |
Torsion Spring /3 |
A11P700201 |
Part /3 |
A11P701602 |
Guide Plate /H |
A11P709400 |
Guide Spring /1 |
12ER40350 |
STICKING PART |
A11P106100 |
Support Shaft /1 |
4131253701 |
BUSHING |
A11P700101 |
Part /2 |
A11P714100 |
Neutralizing Brush /1 |
A2Y1940800 |
Release Label /7 |
13GQ76020 |
SHAFT HOLDER A |
V153030803 |
Screw |
V217030001 |
E Ring |
V217020001 |
E ring |
V116030603 |
Screw |
V217040050 |
E ring |
V137030603 |
screw |
A11P700600 |
Guide Plate /L |
A11P700701 |
Guide Plate /V |
A11P709200 |
Pressing Spring /1 |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P708600 |
Idler Shaft /A |
A0HR715500 |
Open/close Knob |
A2Y1940400 |
Release Label /3 |
A11P705600 |
Open/close Handle /1 |
48645260 |
STOPPER RUBBER |
A2Y1707400 |
Torsion Spring /5 |
56AA40490 |
SHAFT STOPPER 4 |
A11P714001 |
Sheet /O |
A11P716801 |
Sheet /F |
A2Y1707500 |
Torsion Spring /6 |
A11P704301 |
Guide Plate /D |
A11P702304 |
Guide Plate /1 |
A2Y1705800 |
Open/close Knob |
A2Y1940200 |
Release Label /1 |
A11P718703 |
Sheet /K |
A11P712100 |
Guide Plate /S |
A11P716304 |
Sheet /C |
A11P704200 |
Guide Plate /C |
A11P702000 |
Guide Plate /A |
A2Y1940700 |
Release Label /6 |
15AG57180 |
OPEN CLOSE LEVER |
V144030603 |
Screw |
V116040603 |
Screw |
V217030001 |
E Ring |
A03U812800 |
Slide Shaft Holder |
A2Y1107700 |
Support Plate /12 |
15AJ50460 |
PUNCH SPACER |
A2Y1897500 |
Compressing Spring |
A11P896600 |
Idler Holder |
A2Y1907100 |
Reinforce Plate |
A11P898200 |
Support Plate /8 |
A2Y1907200 |
Hook |
A2Y1907300 |
Torsion Spring /7 |
A11P898300 |
Support Plate /9 |
A11PR73211 |
Support Shaft Assy |
12QV40660 |
SHAFT POSITIONING PART |
A11P734900 |
Paddle /4 |
A11P897801 |
Support Part /1 |
A2Y1892200 |
Paper exit Pulley/A 30T |
A2Y1895300 |
Drive Belt 212L |
A2Y1729000 |
Collar /C |
A2Y1728900 |
Drive Belt/6 74L |
A2Y1891600 |
Idling Pulley/3 21/30T |
A11PR73100 |
Support Plate/13 Cauking Assy |
A11PR73000 |
Support Plate/3Cauking3 Assy |
A11P902301 |
Support Part /2 |
A11P890114 |
Support Plate /1 |
A11P891312 |
Idler Shaft |
A11P893400 |
Idler Roll |
A11P901700 |
Neutralizing Brush /1 |
A11P904500 |
Attaching Part /2 |
A11P902501 |
Paper exit Plate /2 |
A11P891001 |
Paper exit Cover /C |
A11P890801 |
Paper exit Cover /A |
A11P902401 |
Paper exit Plate /1 |
A11P904011 |
Idler Shaft /2 |
A11P890902 |
Paper exit Cover /B |
V217060050 |
E ring |
V111030403 |
screw |
V137030603 |
screw |
V116031003 |
Screw |
V153030803 |
Screw |
V237302050 |
Pin |
V116030603 |
Screw |
V116030804 |
Screw |
V217040001 |
E Ring |
V116040603 |
Screw |
A11P903900 |
Neutralizing Brush /6 |
A11P902901 |
Ground Plate /5 |
A11P904800 |
Duplex Tape /1 |
A11P903100 |
Neutralizing Brush /3 |
A11P903801 |
Neutralizing Brush /5 |
A11P903201 |
Ground Plate /6 |
A11P900400 |
Neutralizing Brush /B |
A11P900101 |
Ground Plate /4 |
A11P898502 |
Regulating Part /1 |
A11P903401 |
Ground Plate /8 |
A11P903701 |
Neutralizing Brush /4 |
A11P101301 |
Support Plate /2 |
A11P903301 |
Ground Plate /7 |
13GQ76020 |
SHAFT HOLDER A |
A11P900001 |
Ground Plate /3 |
A11P900200 |
Actuator |
A11P899701 |
Ground Plate /1 |
A2Y1903500 |
Paper exit Sheet /2 |
A11P899801 |
Ground Plate /2 |
A11P101100 |
Support Plate /2 |
A1V4R90000 |
Photointerrupter |
A11P900300 |
Neutralizing Brush /A |
A11P903000 |
Neutralizing Brush /2 |
A11P907000 |
Stopper Plate |
A11P892012 |
Up/down Lever |
A11P892400 |
Up/down Spring |
4131253701 |
BUSHING |
40AA30270 |
DEVELOPING SPACER |
A11P892600 |
Drive Gear/1 48T |
13GQ45480 |
COLLAR A |
A2Y1894100 |
Drive Pulley 27T |
A11P891811 |
Drive Shaft /2 |
A2Y1N11700 |
Sensor Relay harness |
A2Y1891700 |
Pulley/7 21T |
A2Y1891500 |
Drive Shaft /1 |
A11PR73511 |
Fixing Plate Cauking Assy |
V153030803 |
Screw |
V217040050 |
E ring |
V237301050 |
pin |
V237200850 |
Pin |
V116030603 |
Screw |
V217040001 |
E Ring |
A11P718800 |
Neutralizing Brush /1 |
A2Y1707800 |
Paper exit Roll |
A11P705400 |
Idler Shaft /1 |
A11P709200 |
Pressing Spring /1 |
A11P715400 |
Pressing Spring /8 |
A1V4R90000 |
Photointerrupter |
13QE48070 |
ACTUATOR 1 |
13QE48080 |
Spring 1 |
A11P703100 |
Block |
12ER40350 |
STICKING PART |
A11P701401 |
Guide Plate /G |
56AA40490 |
SHAFT STOPPER 4 |
A11P704600 |
Torsion Spring /4 |
A11P705600 |
Open/close Handle /1 |
15AG57180 |
OPEN CLOSE LEVER |
A2Y1941000 |
Release Label /9 |
A11P715001 |
Part /5 |
13GQ76020 |
SHAFT HOLDER A |
12VR75510 |
DOUBLE FEED PV SHAFT HOLDER |
A11P708702 |
Idler Roll /2 |
A11P708600 |
Idler Shaft /A |
48645260 |
STOPPER RUBBER |
A11P702101 |
Guide Plate /B |
A11P704500 |
Torsion Spring /3 |
4131253701 |
BUSHING |
A11P702401 |
Set Part |
A11P714802 |
Guide Plate /T |
A11P714900 |
Guide Plate /U |
A2Y1N11600 |
Sensor Relay harness |
V217030050 |
E ring |
V137030603 |
screw |
V217040050 |
E ring |
V217020001 |
E ring |
V233301050 |
pin |
V217030001 |
E Ring |
A11P735000 |
Attaching Part /3 |
A2Y1721700 |
Regulating Plate /3 |
A11P735200 |
Neutralizing Brush /C |
A11P726800 |
Regulating Spring /1 |
A11P720300 |
Regulating Part /1 |
A11P735800 |
Neutralizing Brush /A |
A11P721601 |
Regulating Plate /2 |
A2Y1735500 |
Attaching Part /1 |
A11P732202 |
Lifting Sheet /1 |
A11P721811 |
Support Shaft /1 |
A11P735700 |
Slide Plate /Rear |
A11P720200 |
Regulating Plate /1 |
A11P726611 |
Support Plate /2 |
55VA47850 |
Belt Holding Part /2 |
A2Y1722300 |
Idling Pulley /3 |
A2Y1735900 |
Drive Belt/6 448L |
A11PR71300 |
Tension Plate/2Cauking Assy |
A2Y1729200 |
Drive Belt/6 80L |
A2Y1722200 |
Pulley/10 29/33T |
A11P726211 |
Support Plate /1 |
A11P735600 |
Slide Plate /Front |
A11PR71400 |
Tension Plate/1Cauking Assy |
A11PR71511 |
Support Plate/3 Cauking1 Assy |
A11P723401 |
Plate /2 |
A108R90000 |
PHOTO INTERRUPTER |
A11PR71911 |
Tension Plate3/Cauking1 Assy |
A2Y1731900 |
Idling Pulley/4 24T |
15AN51860 |
COLLAR A |
A2Y1731800 |
Drive Belt/8 638L |
A11P735100 |
Neutralizing Brush |
A2Y1729300 |
Drive Belt/7 86L |
A2Y1732000 |
Idling Pulley/4 24/36T |
A11PR71811 |
Support Plate/7 Cauking Assy |
A2Y1R70200 |
Drive Motor Assy |
A11P730900 |
Support Plate /4 |
V116030603 |
Screw |
V153030803 |
Screw |
V217040050 |
E ring |
V137030603 |
screw |
V217060001 |
E Ring |
V118030403 |
screw |
V116040603 |
Screw |
V217060050 |
E ring |
A11P722700 |
Slide Sheet /1 |
A11P733400 |
Support Shaft /1 |
A11P733300 |
Paper exit Guide |
A11P733500 |
Hold Spring /1 |
A11P722800 |
Slide Sheet /2 |
A11P720101 |
Regulating Bottom Plate /1 |
A11P731312 |
Support Shaft /2 |
A11P731203 |
Slide Holder |
A11P730411 |
Support Plate /8 |
A11P734000 |
Guide Sheet /2 |
A11P734400 |
Stopper Sheet /1 |
A2Y1905300 |
Coupling |
4131253701 |
BUSHING |
A2Y1893800 |
Worm wheel |
A2Y1899500 |
Drive Shaft /4 |
A2Y1898000 |
Fixing Plate /2 |
A2Y1R70300 |
Rack Drive Motor Assy |
A11P730301 |
Regulating Part /3 |
A11P733900 |
Guide Sheet /1 |
A11P733800 |
Spacer /1 |
A11P734700 |
Stopper Plate |
A11P734800 |
Duplex Tape |
A11P730511 |
Support Plate /4 |
A11P893000 |
Support Plate /4 |
A11P892702 |
Drive Rack |
A11P733600 |
Attaching Part /1 |
A11P892801 |
Drive Gear/2 19T |
A11PR71600 |
Drive Shaft/3 Assy |
A0P0663600 |
Bushing |
A108M50100 |
Photointerrupter |
A11P720401 |
Regulating Part /1 |
A11P899401 |
Mounting Plate /4 |
A11P897400 |
Plate /3 |
A11P900901 |
Light blocking Plate /4 |
A11P730800 |
Light blocking Plate /4 |
A0EDM50100 |
Photoreflector |
A2Y1723601 |
Sensor Plate /3 |
A11P730201 |
Regulating Part /2 |
A11P736000 |
Support Plate /10 |
A11P736100 |
Support Plate /11 |
A11P728701 |
Guide Sheet /3 |
A108R90000 |
PHOTO INTERRUPTER |
A2Y1736000 |
Attaching Part /2 |
V217030001 |
E Ring |
V116030603 |
Screw |
V217040050 |
E ring |
V137030603 |
screw |
V153030803 |
Screw |
V123030603 |
Screw |
V237301050 |
pin |
V115260503 |
Screw |
V237200850 |
Pin |
504045110 |
PRESSURE ROLLER |
A11PR71000 |
Stepler Plate/2 Cauking Assy |
56AA80112 |
Paper Exit Drive Motor |
A11P727400 |
Hold Shaft /1 |
A11P727300 |
Hold Part /3 |
A11PR70900 |
Guide Plate Cauking Assy |
13QE76531 |
MOTOR PULLEY 14T |
A11P725900 |
Drive Belt/5 126L |
A0P0663600 |
Bushing |
A11P721400 |
Idling Gear/1 20T |
A11P727000 |
Hold Part /1 |
A11P727100 |
Hold Spring /1 |
A11P728600 |
Guide Rail /3 |
A108M50100 |
Photointerrupter |
A11P721102 |
Stapler Bottom Plate /1 |
A11P728500 |
Guide Rail /1 |
A11P726700 |
Plate/1 |
A11P728201 |
Stapler Guide |
A11P728300 |
Spacer |
A11P728101 |
Stapler Rack |
A11P734501 |
Guide Sheet /C |
A11P732800 |
Stapler Cover /1 |
A11P734202 |
Guide Part /1 |
A11P734302 |
Guide Part /2 |
A07P790100 |
Stapler Main body |
A11P726500 |
Light blocking Plate /1 |
A11P726400 |
Light blocking Plate /2 |
A11P727200 |
Hold Part /2 |
A11PR71111 |
Stapler Plate /1 Cauking Assy |
A11P726300 |
Light blocking Plate /3 |
A11P730000 |
Stapler Cover /1 |
A11P726100 |
Plate /5 |
A108R90000 |
PHOTO INTERRUPTER |
A11P732901 |
Reinforce Plate /1 |
A11PR90100 |
CARTRIDGE ASSY |
V217040001 |
E Ring |
V116030603 |
Screw |
V237201250 |
Pin |
V137030603 |
screw |
V144030603 |
Screw |
V217030001 |
E Ring |
V137040803 |
SCREW |
V116040603 |
Screw |
V153030803 |
Screw |
V153031003 |
screw |
V149030803 |
screw |
14JS77141F |
UP/DOWN WORM |
A11P902600 |
Idling Shaft /1 |
326040330 |
SHAFT HOLDER A |
14JS77520 |
Drive Pulley /2 16T |
A11P899100 |
Belt/1 147L |
40BA52390 |
BELT HOLDER |
A11P899000 |
Idling Pulley/2 36T/31T |
A11PR72400 |
Motor Fixing Plate/1Assy |
A0PNM10200 |
DC Brushless motor /20 |
48645260 |
STOPPER RUBBER |
56AA40490 |
SHAFT STOPPER 4 |
A0HR715500 |
Open/close Knob |
A11R701202 |
Open/close Handle /1 |
A2Y1711900 |
Guide Plate /Q |
A2Y1710600 |
Guide Plate /8 |
56AA12270 |
EXTERNAL LOCKING PART |
A2Y1712000 |
Guide Plate /20 |
A0EDM50100 |
Photoreflector |
A2Y1705900 |
Sensor Plate /Z |
90075530 |
BUSHING |
14JS77010 |
UP/DOWN GEAR /A 27/40T |
A11P905400 |
Up/down Gear /B |
A11P898900 |
Idling Shaft /A |
A0G6243900 |
Ball Bearing |
A11P904700 |
Support Shaft /1 |
14JS49210 |
FIXING PLATE |
A11P895401 |
Mounting Plate /1 |
A2Y1941100 |
Release Label /10 |
A2Y1N11500 |
Sensor Relay harness |
V116040603 |
Screw |
V116030603 |
Screw |
V137040803 |
SCREW |
V193040609 |
screw |
V237201050 |
Pin |
V217040001 |
E Ring |
V217060001 |
E Ring |
V137030603 |
screw |
V125030818 |
Screw |
V144030603 |
Screw |
12AR45611 |
ACTUATOR |
A11P898800 |
Mounting Plate /1 |
12QR86011 |
Interlock Switch |
A2Y1906800 |
Timing belt 106L |
A2Y1894900 |
Pulley/1 18/45T |
A2Y1906700 |
Timing belt 134L |
A2Y1894300 |
Pulley/3 17T |
A11PR72800 |
Up/Down Rever M Assy |
A11PM10200 |
DC Brushless motor /12 |
A11P897900 |
Idling Gear/4 17T/61T |
A11P896000 |
Drive Gear/6 25T |
A11P900500 |
Wiring Plate /2 |
A2Y1M10200 |
Stepping motor |
A03U812800 |
Slide Shaft Holder |
A11P895700 |
Drive Gear/5 45T |
A11P895800 |
Idling Gear/3 21T/49T |
A11P896300 |
Plate /2 |
A108R90000 |
PHOTO INTERRUPTER |
A2Y1R7A000 |
Mounting Plate |
15AJ50460 |
PUNCH SPACER |
A11P894700 |
Idling Gear/1 62T/22T |
A11P893700 |
Support Plate /5 |
A2Y1N11300 |
Drive Relay harness |
A2Y1N10700 |
Interlock Wiring /2 |
V118021003 |
screw |
V118031603 |
screw |
V137030603 |
screw |
V217040050 |
E ring |
V237201050 |
Pin |
V111030403 |
screw |
V116030603 |
Screw |
V217060050 |
E ring |
V232200809 |
pin |
A2Y1719800 |
Pulley 20T |
A11P716000 |
Tension Spring /1 |
A11PR70100 |
Tensioner Caulking/2 Assy |
A2Y1706800 |
Timing belt/2 528L |
A2Y1719900 |
Pulley/4 20T |
A2Y1718500 |
Timing belt/1 168L |
13GQ45480 |
COLLAR A |
A2Y1M10000 |
Stepping motor |
A2Y1713100 |
Mounting Plate /3 |
122H15220 |
TENSION ROLLER |
A2Y1719500 |
Pulley/3 26T |
56QA75060 |
Drive Bearing /6 |
40AA30270 |
DEVELOPING SPACER |
A11P714600 |
Base frame |
A2Y1706300 |
Timing belt/1 143L |
A11P719700 |
Gear/2 30T |
A2Y1719600 |
Pulley/9 20T |
A2Y1716900 |
Gear/9 30T |
A2Y1707600 |
Mounting Plate /4 |
A2Y1706700 |
Timing belt/3 570L |
A2Y1714500 |
Connecting Shaft |
A11P717700 |
Gear/3 22T |
A11P705302 |
Paper Exit Roller /Upper |
A2Y1706100 |
Drive Roller /5 |
A2Y1705100 |
Drive Roller /3 |
A2Y1705200 |
Drive Roller /4 |
A2Y1703400 |
Drive Roller /5 |
14GE45470 |
Rotation Knob |
A2Y1719200 |
Pulley/3 26T |
A2Y1940600 |
Release Label /5 |
A11PR70000 |
Tensioner Cauking/1Assy |
V217040050 |
E ring |
V116030603 |
Screw |
V237201250 |
Pin |
V137030603 |
screw |
V217060001 |
E Ring |
V144030603 |
Screw |
A00J617900 |
Ball Bearing |
A2Y1719900 |
Pulley/4 20T |
A2Y1712900 |
Stopper Plate |
13GQ45480 |
COLLAR A |
A2Y1M10000 |
Stepping motor |
A2Y1704001 |
Support Plate /2 |
A2Y1719200 |
Pulley/3 26T |
56QA75060 |
Drive Bearing /6 |
40AA30270 |
DEVELOPING SPACER |
15AJ50460 |
PUNCH SPACER |
A2Y1706600 |
Drive Belt/8 288L |
A2Y1M10200 |
Stepping motor |
A11P707000 |
Mounting Plate /2 |
A2Y1706400 |
Drive Belt/3 306L |
A2Y1719400 |
Pulley/3 26T |
A2Y1940300 |
Release Label /2 |
A2Y1703600 |
Registration Roller |
A2Y1704700 |
Registration Roller |
A2Y1705100 |
Drive Roller /3 |
A108M50100 |
Photointerrupter |
14GE45470 |
Rotation Knob |
V217060050 |
E ring |
V217040050 |
E ring |
V116030603 |
Screw |
V237201250 |
Pin |
V144030603 |
Screw |
A2Y1823100 |
Idler Plate spring /3 |
A3EP820100 |
Guide /1 |
A3EP819001 |
Guide /Upper |
A2Y1823000 |
Guide Sheet |
A3EP811800 |
Support Plate /4 |
A3EP812500 |
Idler Plate spring /2 |
A0HR212700 |
Idler Roll /1 |
A3EP812100 |
Idler Shaft /1 |
A3EP814300 |
Ground Spring /2 |
A2Y1812300 |
Bushing /1 |
A2Y1812400 |
Idler Roll /1 |
A3EP822800 |
Holding Part /1 |
A2Y1821500 |
Pressing Spring |
A3EP814600 |
Cover /Front |
A3EP812200 |
Idler Plate spring /1 |
A3EP822900 |
Holding Part /2 |
A3EP814200 |
Ground Spring /1 |
A3EP811201 |
Support Plate /2 |
A3EP811100 |
Support Plate /1 |
A2Y1813501 |
Guide /5 |
A2Y1821400 |
Idler Shaft /2 |
V153030804 |
screw |
V153030803 |
Screw |
V217030001 |
E Ring |
V153031003 |
screw |
A3EP814700 |
Cover/Rear |
A2Y1818100 |
Fixing Plate /6 |
A2Y1817800 |
Regulating Part /2 |
A2Y1H10101 |
PWB Assembly(PWB-RU ASSY) |
A3EP815500 |
Ground Spring /3 |
A2Y1820800 |
Mounting Plate |
A2Y1820700 |
Mounting Plate |
A3EP811700 |
Support Plate /3 |
A3EP815000 |
Fixing Plate /3 |
A3EP815200 |
Positioning Shaft /2 |
A3EP821800 |
Cover Part |
A3EP813900 |
Lock Part /2 |
A0HR701200 |
Mounting Plate |
A3EP821600 |
Regulating Part /3 |
A108R90000 |
PHOTO INTERRUPTER |
A2Y1821201 |
Lock Part /2 |
A2Y1N14200 |
I/F Wiring |
V121030604 |
Screw |
V153030804 |
screw |
A2Y1M10100 |
Stepping motor |
A3EP810700 |
Mounting Plate /1 |
A3EP815400 |
Ground Plate /3 |
A0HR213600 |
Flange |
A3EP810900 |
Belt/1 114L |
A0HR210200 |
Pulley 14/26T |
A3EP820300 |
Belt/3 276L |
A0HR210300 |
Flange |
A0HR210900 |
Drive Belt /2 |
A0HR211000 |
Pulley 28T |
A3EP816200 |
Drive Pulley/1 28T |
07BA15930 |
SPACER B |
A3EP816500 |
Fixing Plate /5 |
A00J617800 |
BALL BEARING |
A3EP810800 |
Fixing Plate /1 |
A3EP814800 |
Fixing Part /2 |
A2Y1812700 |
Guide /4 |
A3EP819801 |
Actuator |
A3EP821700 |
Sensor Spring /1 |
A108R90000 |
PHOTO INTERRUPTER |
A3EP810001 |
Guide /Lower |
A3EP810600 |
Roller /1 |
A3EP822000 |
Bushing |
A3EP811500 |
Roller /2 |
A2Y1816400 |
Roller /3 |
A2Y1815800 |
Fixing Plate /4 |
A2Y1817000 |
Ground Spring /4 |
A2Y1816300 |
Drive Pulley/2 28T |
A2Y1815600 |
Belt/2 288L |
A2Y1816000 |
Idling Roll |
A2Y1815700 |
Pulley 28T |
A0ED814100 |
Pulley 22T |
A2Y1N14300 |
Sensor Relay harness |
V153030803 |
Screw |
V116030603 |
Screw |
V217030001 |
E Ring |
V217040001 |
E Ring |
A2Y1N10000 |
Drive Wiring |
A2Y1N10100 |
Drive Wiring |
A2Y1N10201 |
Drive Wiring |
A2Y1N10300 |
Drive Wiring |
A2Y1N10400 |
I/F Wiring |
A2Y1N10501 |
I/F Wiring |
A2Y1N11200 |
Drive Relay harness |
A2Y1N11901 |
Sensor Relay harness |
V500010003 |
Saddle |
V500010007 |
saddle |
V500010008 |
saddle |
V500010020 |
Saddle |
V500010046 |
saddle |
V500010057 |
Locking Wire Saddle |
V570010021 |
Saddle |
V570010023 |
saddle |
V570010025 |
saddle |
V570010026 |
saddle |
V500020077 |
wabe Clamp |
V500020044 |
bushing |
V570010037 |
bushing |
V570010046 |
SADDLE |
V500020076 |
wabe Clamp |
A11P955702 |
Paper exit Tray /2 |
A11P955305 |
Paper Exit Tray /1 |
A2Y1957300 |
Cushion |
A07R890001 |
PAPER EXIT TRAY /2 |
A11P890301 |
Paper Exit Tray /1 |
A2Y1956900 |
Connecting Sheet |
9J08112701 |
SPACER |
9J08112601 |
CUSHION |
A2Y1956801 |
Mounting Plate |
A2Y1957100 |
Mounting Plate |
A11PR74000 |
Main Body Connection Plate/2 Assy |
A2Y1956501 |
Mounting Plate /Rear |
A2Y1956400 |
Mounting Plate /Front |
A2Y1956600 |
Mounting Plate /Front |
A2Y1956700 |
Mounting Plate /Rear |
A2Y1R70400 |
Main Body Connection Plate Assy |
A2Y1955100 |
Mounting Plate /1 |
A11P956301 |
Mounting Screw |
A0HR115400 |
Ground Plate /Lower |
A2Y1103200 |
Stapler Cover |
A3EP810400 |
Guide /2 |
A3EP810500 |
Guide /3 |
V121041203 |
screw |
V144030603 |
Screw |
V116040803 |
Screw |
V116041603 |
Screw |
V116031603 |
Screw |
V137030603 |
screw |
V114040803 |
Screw |
A3ET910500 |
Fixing Plate |
A0P0109200 |
Screw |
A3ET910600 |
Guide Plate |
A4JUR70000 |
Punch Unit 2 Holes |
A4JUR70100 |
Punch Unit 2/3 Holes |
A4JUR70200 |
Punch Unit 2/4 Holes |
A4JUR70300 |
Punch Unit 4 Holes/SW |
A3ET910900 |
Guide Plate /Upper |
A3ET911200 |
Punch Guide |
A3ET910400 |
Positioning Pin |
4040737401 |
LABEL |
A3ET911500 |
Holding Part |
A3ETM50000 |
Separating Sensor |
A3ET911400 |
Cover Sheet |
A3ET910702 |
Duct |
A3ET911100 |
Detecting Plate |
A3ET911000 |
Sensor Holder |
A3ETM50100 |
Separating Sensor |
A3ETN10001 |
Drive Wiring |
13NK50380 |
NEUTRALIZING BRUSH C |
13NK50380 |
NEUTRALIZING BRUSH C |
13NK50380 |
NEUTRALIZING BRUSH C |
13NK50380 |
NEUTRALIZING BRUSH C |
V137030803 |
screw |
V207030003 |
washer |
V116030803 |
Screw |
V153030803 |
Screw |
V501010018 |
BAND |
V500010020 |
Saddle |
A3ET910800 |
Collection Box |
A3ET940000 |
Label |
A3ET940100 |
Label |
A11T912100 |
Drive Belt/1 150L |
A0P0663600 |
Bushing |
13XA76520 |
PUNCH DRIVING PULLEY 2 30T/21T |
A11P735200 |
Neutralizing Brush /C |
08AA85512 |
Photo Sensor |
13GL46720 |
Fixing Plate |
A11TR70000 |
Mounting Plate/2 Caulking Assy |
13XA76510 |
PUNCH DRIVING PULLEY 1 15T |
56GA73431 |
MOTOR FIXING PART /1 |
A11TM10100 |
HB Motor |
A11T911302 |
Mounting Plate /1 |
A11T911200 |
Swing Rack /1 |
A11T911600 |
Slide Bushing /1 |
A2YR913200 |
Slide Plate /1 |
20AF97030 |
SEPARATION PROCESSING LABEL |
A11T911000 |
Guide Shaft /1 |
504045110 |
PRESSURE ROLLER |
A11TR70100 |
Drive Connecting/1 Assy |
A2YR913401 |
Guide Plate /1 |
A2YR913701 |
Guide Plate /2 |
A2YRN10001 |
Drive Wiring |
A2YR913600 |
Plate /1 |
A11TH02000 |
Detection Board Assy |
A11T911811 |
Plate /2 |
13QA85521 |
Sensor /2 |
A2YR914100 |
Protection Cover /2 |
A11T912200 |
Protection Cover /1 |
A11T940101 |
Processing Label |
A2YRN10100 |
Drive Relay harness |
A2YR914000 |
Guide Plate /3 |
V116030603 |
Screw |
V237201250 |
Pin |
V217040001 |
E Ring |
V137030603 |
screw |
V153030803 |
Screw |
V144030803 |
SCREW |
V118030603 |
screw |
V121030403 |
screw |
V217050001 |
E ring |
V116030803 |
Screw |
V500010020 |
Saddle |
V570010021 |
Saddle |
V500010003 |
Saddle |
V501010018 |
BAND |
V116030403 |
Screw |
V207030003 |
washer |
A4JUR70400 |
Punch Unit /1 2Holes |
13NK50380 |
NEUTRALIZING BRUSH C |
A4JUR70500 |
Punch Unit /2 2/3Holes |
13NK50380 |
NEUTRALIZING BRUSH C |
A4JUR70600 |
Punch Unit /3 2/4Holes |
13NK50380 |
NEUTRALIZING BRUSH C |
A4JUR70700 |
Punch Unit /4 4Holes SW |
13NK50380 |
NEUTRALIZING BRUSH C |
A11T940200 |
Processing Label /2 |
A11T913400 |
Scatter Guide /1 |
A11T913500 |
Scatter Guide /2 |
V116040803 |
Screw |
V116030603 |
Screw |
A11TR70600 |
Processing Box/Assy |
A2YR955301 |
Neutralizing Sheet /1 |
A2YRH10103 |
PWB Assembly(PWB-PK ASSY) |
A2YR955200 |
Stay /1 |
V116030603 |
Screw |
V502010041 |
BUSHING |
A10A940100 |
Sheet /1 |
A10A160302 |
Cover /Front |
A10AH02000 |
Operation Unit Board Assy |
554012080 |
SWITCH BUTTON |
A10AN10500 |
FNS Wiring /5 |
A07V160600 |
Screw Cover |
A07V160200 |
Cover /Upper |
13QN40570 |
TRAY RELEASE SHAFT |
A07V160800 |
tray Release Handle |
13QN-4280 |
TRAY MOUNTING PIATE CAULKING |
55VA42360 |
RELEASE ROLLER |
13QN40590 |
TRAY LOCKING SPRING |
13QN40581E |
LOCK CLAW |
13QN40680 |
TRAY LIFTING SPRING REAR |
048645260 |
STOPPER RUBBER |
13QN-4320 |
PANEL 4 CAULKING |
A07V160401 |
Regulating Cover /Rear |
A07V160100 |
Cover /Lower |
56UF97280 |
SEPARATION PROCESSING LABEL |
A10AH01001 |
Drive Board Assy |
V502010014 |
support |
12ER75531 |
Bushing/A |
13QN40652 |
BOARD MOUNTING PLATE |
A10AN10100 |
FNS Wiring /1 |
A07V160500 |
Cover /Right |
13QN-4301 |
PANEL 2 CAULKING |
13QN40421 |
CONNECTING ARM A |
13QN40670 |
TRAY LIFTING SPRING FRONT |
13QN40760 |
POSITIONING PART |
A10A100100 |
Receiving Plate /1 |
13QN40012E |
PANEL /1 |
A10A100200 |
Receiving Plate /2 |
13QN40740 |
INSULATING SHEET |
12QR86011 |
INTERLOCK SWITCH |
13QN40700 |
SWITCH SPRING |
13QN40500 |
TRAY POSITIONING PIN |
13QN-4310 |
PANEL 3 CAULKING |
V114040604 |
Screw |
V217040050 |
E ring |
V158030803 |
Screw |
V121030603 |
screw |
V121040603 |
screw |
V123030803 |
Screw |
V570010021 |
Saddle |
V118021003 |
screw |
V360100000 |
EDGING |
V500010006 |
saddle |
V500010011 |
saddle |
V500010016 |
saddle |
13QNR70100 |
FEEDING UNIT ASSY |
50BA40030 |
FEEDING ROLLER A |
50BAR70100 |
FEEDING ROLLER ASSY A |
13QN40190 |
PAPER FEED SHAFT 1 |
13QN40541 |
ADJUSTMENT PLATE |
56AA40490 |
SHAFT STOPPER 4 |
12ER75531 |
Bushing/A |
13QN40051 |
PAPER DETECTING ACTUATOR |
392015650 |
SLIDE BUSHING/C |
13QN40381E |
PAPER FEED SWING PLATE |
059076510 |
PULLEY 1 15T |
396078020 |
PIN B |
12QV40740 |
Belt Regulating Part |
25SA77561 |
PAPER FEED DRIVE BELT 126L |
13QN-4370 |
PAPER ROCKING SHAFT RIGHT ASSY |
13QN40060 |
FEEDING ROLLER B |
13QNR70500 |
FEEDING ROLLER ASSY C |
08AA85512 |
Photo Sensor |
13QN40251 |
PAPER FEED GUIDE PLATE C |
13QNR70200 |
DRIVING CNT SHAFT A ASSY |
13QN42181 |
CLUTCH FIXING PLATE |
192141710 |
PAPER LIFT UP LEVER BUSHING |
466078010 |
PIN A D2X10 |
129X76620 |
CONVEYANCE PULLEY B 16T |
13QN82011 |
PAPER FEED CLUTCH |
13QN40790 |
SPACER |
12AR15190 |
COLLAR B |
13QN40442E |
CONNECTING ARM /C |
26NA40820 |
PAPER FEED SLIDE BUSHING |
13QN76520 |
DRIVE PULLEY 2 40T |
13QN91070 |
FNS WIRING 7 |
13QNR70300 |
DRIVING CNT SHAFT B ASSY |
13QN40233E |
PAPER FEED GUIDE PLATE /A |
13QN40750 |
Cover |
V121030603 |
screw |
V121030803 |
SCREW |
V217040050 |
E ring |
V217060050 |
E ring |
V233301250 |
pin |
V121030404 |
screw |
V500010026 |
saddle |
V500010027 |
saddle |
V570010021 |
Saddle |
V570010033 |
saddle |
540077362 |
Paper Lifting Gear /B 14/63T |
540077311 |
PAPER LIFTING GEAR /C 15/70T |
540077321 |
PAPER LIFTING /D 15/40T |
08AA85512 |
Photo Sensor |
13QN40661 |
MOUNTING PLATE |
A10YA6560 |
PAPER FEED MOTOR ASSY |
13QN42131 |
MOTOR MOUNTING PLATE |
A0R5M10300 |
DC Brushless motor /30 |
13QN-4340 |
MOTOR MOUNTING PLATE CAULKING |
13QN77060 |
IDLING GEAR/B 24/31T |
13QN77510 |
DRIVE BELT A 189L |
25SA77060 |
Screw Drive Gear 4 30T |
90075530 |
BUSHING |
13QN40271 |
PAPER FEED DRIVING ROLLER/UPPER |
13QN40281 |
PAPER FEED DRIVING ROLLER/LOWER |
13QN98030 |
Drive Holding Spacer |
A00V240600 |
BALL BEARING |
13QN76530 |
DRIVE PULLEY 3 24T |
13QN77550 |
DRIVE BELT E 258L |
13QN40781 |
WIRING MOUNTING PLATE |
V217040050 |
E ring |
V217060050 |
E ring |
V121030603 |
screw |
V502010014 |
support |
V118260403 |
screw |
V500010016 |
saddle |
V500010026 |
saddle |
V501010004 |
band |
V570010007 |
saddle |
V570010021 |
Saddle |
V500010006 |
saddle |
13QN40090 |
PAPER FEED SWING SHAFT |
12ER75531 |
Bushing/A |
13QN40070 |
PAPER FEED ROCKING BLOCKA |
13QN40850 |
PAPER FEED GUIDE SHEET |
13QN40260 |
PAPER FEED GUIDE PLATE D |
13QN40842 |
REGISTRATION GUIDE SHEET |
13QN40371 |
CONVEYANCE GUIDE PLATE LOWER |
13QN-4270 |
LOCK PLATE ASSY |
13QE48300 |
Block |
08AA85512 |
Photo Sensor |
13QE48080 |
Spring 1 |
13QE48070 |
ACTUATOR 1 |
129U75510 |
TENSION SHAFT HOLDER |
13QN40530 |
CONVEYANCE DRIVEN ROLLER |
13QN40411 |
CONVEYANCE PRESSING SPRING |
13QN40401 |
CONVEYANCE IDLER SHAFT |
14JS47210 |
NEUTRALIZING BRUSH |
13QN40241 |
PAPER FEED GUIDE PLATE B |
13QN40861 |
REGISTRATION GUIDE SHEET 2 |
26NA40820 |
PAPER FEED SLIDE BUSHING |
12AR15190 |
COLLAR B |
13QN40432E |
CONNECTING ARM /B |
13QN40790 |
SPACER |
12ER40350 |
STICKING PART |
13QN40110 |
SOLENOID SPRING |
13QN40080 |
PAPER FEED ROCKING BLOCKB |
15JKR70300 |
FNS SOLENOID ASSY |
13QN40101 |
SOLENOID MOUNTING PLATE |
13QN49100 |
WIRING PROTECTION SHEET |
V123030603 |
Screw |
V123030803 |
Screw |
V121030603 |
screw |
V217040050 |
E ring |
V217030050 |
E ring |
V217060050 |
E ring |
V237301450 |
pin |
V121030403 |
screw |
V500010021 |
saddle |
V500010026 |
saddle |
13QN77010 |
PAPER FEED REVERSING GEAR A 14T |
13QN40150 |
MULTI FEED PREVENTING SHAFT |
13QN40731 |
TORQUE LIMITTER |
13QNR70400 |
REVERSING RUBBER ASSY |
56AA40490 |
SHAFT STOPPER 4 |
13QN77020 |
IDLING GEAR A 15T |
13QN40130 |
MULTI FEED PREVENTING PLATE |
13QN40141 |
SEPARATION MOUNTING PLATE |
13QN40770 |
BUSHING/B |
13QN40180 |
SEPARATION SWING SHAFT RIGHT |
12ER75531 |
Bushing/A |
13QN76510 |
DRIVE PULLEY 1 30T |
13QN76550 |
IDLING PULLEY 3 26T |
25AA51160 |
BELT HOLDER A |
129R77920 |
DRIVING BELT B 216L |
13QN77560 |
DRIVING BELT F 246L |
13QN77530 |
DRIVE BELT C 150L |
13QN40201E |
SEPARATION BASE PLATE |
13QN40550 |
MULTI FEED PREVENTING SPRING |
13QN77030 |
PAPER FEED REVERSING GEAR B 15T |
V217040050 |
E ring |
V121030603 |
screw |
V217060050 |
E ring |
V237301250 |
pin |
V500010026 |
saddle |
V570010007 |
saddle |
V570010033 |
saddle |
V500010006 |
saddle |
13QN77010 |
PAPER FEED REVERSING GEAR A 14T |
13QN40150 |
MULTI FEED PREVENTING SHAFT |
13QN40731 |
TORQUE LIMITTER |
13QNR70400 |
REVERSING RUBBER ASSY |
56AA40490 |
SHAFT STOPPER 4 |
13QN77020 |
IDLING GEAR A 15T |
13QN40130 |
MULTI FEED PREVENTING PLATE |
13QN40180 |
SEPARATION SWING SHAFT RIGHT |
13QN40770 |
BUSHING/B |
13QN40141 |
SEPARATION MOUNTING PLATE |
13QN77030 |
PAPER FEED REVERSING GEAR B 15T |
13QN40550 |
MULTI FEED PREVENTING SPRING |
13QN40201E |
SEPARATION BASE PLATE |
12ER75531 |
Bushing/A |
13QN77530 |
DRIVE BELT C 150L |
13QN76510 |
DRIVE PULLEY 1 30T |
55VA77270 |
TONER CONVEYANCE GEAR A 30T |
13QN40830 |
IDLING SHAFT 1 |
55GA75031 |
BALL BEARING |
13QN40811 |
CLUTCH MOUNTING PLATE |
13QN82020 |
REGISTRATION CLUTCH |
13QA10330 |
SHAFT SPACER |
13QN40820 |
CONNECTING PART |
13QN76560 |
DRIVE PULLEY C 24T |
13QN77550 |
DRIVE BELT E 258L |
25AA51160 |
BELT HOLDER A |
13QN76550 |
IDLING PULLEY 3 26T |
13QN-4330 |
TENSION PLATE CAULKING |
V121030403 |
screw |
V121030603 |
screw |
V237200850 |
Pin |
V237301250 |
pin |
V217040050 |
E ring |
V217060050 |
E ring |
V123030803 |
Screw |
13QA85521 |
Sensor 2 |
13QN42171 |
MOUNTING PLATE |
15JF42030 |
UP DOWN TRAY |
13QN42120 |
MULTI FEED PREVENTING SHEET |
13QA85511 |
Sensor 1 |
13QN42220 |
CONNECTING PLATE |
13QN42080 |
LEVER |
A07V600800 |
Adjusting Cover |
A07V600700 |
Paper Regulating Plate /2 |
13QN77040 |
Up Down Gear 12T |
15JF97040 |
ORIGINAL REGULATING LABEL A |
13QN42090 |
PAPER LIFTING SHAFT |
A07V600300 |
Paper Regulating Plate / Rear |
13QN42110 |
RACK B |
13QN91041 |
FNS WIRING /4 |
A07V600400 |
Paper feed Cover /1 |
13QN42250 |
SEPARATION AUXILIARY SHEET 2 |
13QN42241 |
SEPARATION AUXILIARY SHEET |
15JF42260 |
MULTI-FEED PREVENTING SHEET/2 |
15JF42270 |
MULTI-FEED PREVENTING SHEET/3 |
A07V600100 |
Paper feed Tray /1 |
396077060 |
PAPER FEED IDLER GEAR A 22T |
13FG-9332E |
SIZE DETECT BOAD ASSY |
55GA77190 |
PINION 108T |
13QN42100 |
RACK A |
15JF42200 |
PAPER REGULATING PLATE FRONT |
A07V600600 |
Paper feed Cover /3 |
V122030603 |
Screw |
V237301650 |
pin |
V123030603 |
Screw |
V158030803 |
Screw |
V121030603 |
screw |
V118040603 |
screw |
V217040050 |
E ring |
V500020003 |
clamp |
13QA85521 |
Sensor 2 |
A07V600200 |
Paper feed Tray /2 |
13QN42171 |
MOUNTING PLATE |
13QA85511 |
Sensor 1 |
13QN42120 |
MULTI FEED PREVENTING SHEET |
15JF42030 |
UP DOWN TRAY |
13QN91061 |
FNS WIRING /6 |
13QN42090 |
PAPER LIFTING SHAFT |
A07V600800 |
Adjusting Cover |
A07V600700 |
Paper Regulating Plate /2 |
13QN77040 |
Up Down Gear 12T |
15JF97040 |
ORIGINAL REGULATING LABEL A |
13QN42220 |
CONNECTING PLATE |
A07V600300 |
Paper Regulating Plate / Rear |
13QN42080 |
LEVER |
13QN42110 |
RACK B |
A07V600400 |
Paper feed Cover /1 |
13QN42241 |
SEPARATION AUXILIARY SHEET |
13QN42250 |
SEPARATION AUXILIARY SHEET 2 |
15JF42260 |
MULTI-FEED PREVENTING SHEET/2 |
15JF42270 |
MULTI-FEED PREVENTING SHEET/3 |
A07V600100 |
Paper feed Tray /1 |
396077060 |
PAPER FEED IDLER GEAR A 22T |
55GA77190 |
PINION 108T |
13FG-9332E |
SIZE DETECT BOAD ASSY |
13QN42100 |
RACK A |
15JF42200 |
PAPER REGULATING PLATE FRONT |
A07V600500 |
Paper feed Cover /2 |
V158030803 |
Screw |
V237301650 |
pin |
V122030603 |
Screw |
V123030603 |
Screw |
V121030603 |
screw |
V217040050 |
E ring |
V118040603 |
screw |
V500020003 |
clamp |
V501010002 |
band |
V570010033 |
saddle |
V500010021 |
saddle |
V500010027 |
saddle |
V500020003 |
clamp |
V500010006 |
saddle |
V500010011 |
saddle |
V500010016 |
saddle |
V570010007 |
saddle |
V500010026 |
saddle |
V501010002 |
band |
V501010004 |
band |
V360100000 |
EDGING |
V502010014 |
support |
A10A160400 |
Cover Plate /5 |
A10A940200 |
Sheet /2 |
318065281 |
CAMFOLLOWERSLIDES
CREW |
V121040603 |
screw |
V114040604 |
Screw |
A10A940300 |
Processing Label |
V158040803 |
screw |
A10A160101 |
Cover Plate /4 |
A10C890101 |
Paper Exit Tray /2 |
A10C890000 |
Paper Exit Tray /1 |
A10C160301 |
Preventing Part |
A10C890300 |
Stopper Part |
A10C890200 |
Paper Exit Guide /Upper |
4109553001 |
STOPPER |
4655352801 |
MEMBER |
4655351701 |
TORSION SPRING |
4655350901 |
ACTUATOR |
4655353701 |
MEMBER |
9335140061 |
SOLID STATE SWITCH |
4655351801 |
TORSION SPRING |
4655351301 |
ACTUATOR |
4040737401 |
LABEL |
A10C100700 |
Spacer /1 |
A10C160001 |
Cover/Rear |
4655351601 |
SHAFT |
4655352901 |
COVER |
A10C701300 |
Entrance Guide |
A10C100800 |
Spacer /2 |
A10C700800 |
Hold Plate Spring /1 |
A10C701100 |
Idler Shaft |
A10C701000 |
Idler Roll |
A10C700900 |
Hold Plate Spring /2 |
A10C701400 |
Conveyance Guide |
4655352601 |
PRESSURE SPRING |
4655352301 |
NEUTRALIZING BRUSH |
A10C160100 |
Cover /Front |
A10C100100 |
Mounting Plate /2 |
A10C940100 |
Processing Label |
V217020001 |
E ring |
V153030803 |
Screw |
V116030803 |
Screw |
A10C130100 |
Cover Part |
4611620102 |
SOLENOID |
4655351902 |
EARTH GROUND |
4655352401 |
BRACKET |
4655360401 |
PRESSURE SPRING |
4655360301 |
LEVER |
A10C701200 |
Positioning Spring |
4655360201 |
LEVER |
1044530302 |
CAP |
1300314219 |
Gear /30T |
4655360101 |
ARM |
4655360501 |
GEAR 26T |
4655353601 |
PLATE SPRING |
4655352712 |
STOPPER |
A10C130000 |
Cover Plate |
4655020101 |
REINFORCE PLATE ASSY |
4655351001 |
Plate Spring |
4655350401 |
GEAR 24T |
1200322107 |
BUSHING |
4655680101 |
WIRE HARNESS ASSY |
4655350712 |
STOPPER |
4655353501 |
PLATE SPRING |
4655350501 |
ROLLER |
4655350301 |
ROLLER |
A10C700100 |
Idling Gear /1 26T |
A10C700000 |
Receiving Arm /1 |
A10C700200 |
Set Ring /1 |
A10C100001 |
Mounting Plate /1 |
V217040001 |
E Ring |
V116030603 |
Screw |
V218040086 |
E ring |
V153031003 |
screw |
V153030803 |
Screw |
V153040803 |
screw |
V500010023 |
clip |
V500020010 |
clip |
V501010001 |
band |
V232301009 |
pin |
V500010023 |
clip |
V500020010 |
clip |
V501010001 |
band |
A109710800 |
Paper Exit Sheet /C |
A109710700 |
Guide Plate /A |
13NQ10371 |
GUIDE PLATE |
13NK10250 |
FINISHER COVER PLATE |
129R10210 |
MAIN FIXED PLATE 1 |
A07T102601 |
Main body Mounting Plate /Front |
13NK10061 |
Electric Cover Plate |
A109101800 |
Protection Sheet /1 |
A07T101601 |
Mounting Plate /3 |
123Y45261 |
STOPPRE RUBBER |
13NK10032F |
Rear Panel |
A07T130601 |
Wiring Plate |
A07T101502 |
Positioning Plate /Rear |
13NK10110 |
Rear Reinforce Stay |
27LA80511 |
Main Body Fan Motor |
13NK10091 |
MOUNTING PLATE 1 |
129U-1030 |
ROCKING PLATE ASSY |
A07TA1080 |
LOCK LEVER |
66031142 |
ROLLER |
A109103000 |
Lock Spring |
A07T130701 |
Wiring Plate |
A07T130501 |
Protection Plate |
13NK10140 |
FILTER MOUNTING PLATE |
538088261 |
Noise Filter |
57AF97740 |
EARTH LABEL F |
12QR10084 |
REINFORCESTAY |
A07T701102 |
Guide Plate /Upper |
A07T701400 |
Slide Sheet |
V121040603 |
screw |
V121030603 |
screw |
V121040403 |
screw |
V118040603 |
screw |
V121033003 |
screw |
V127040603 |
screw |
V570010023 |
saddle |
V139030603 |
screw |
V500010007 |
saddle |
V138030603 |
screw |
V217060050 |
E ring |
56GA80062 |
HB MOTOR 40 |
56GA73431 |
MOTOR FIXING PART /1 |
396078020 |
PIN B |
A07T915100 |
Swing Pulley 12T |
13NK77580 |
PUNCH ROCKING BELT 246L |
08AA85512 |
Photo Sensor |
13NK50201 |
MOUNTING PLATE A |
A07T911000 |
Motor Mounting Plate /A |
A00J617900 |
Ball Bearing |
13NK-5160 |
Punch Rocking Shaft Assy |
129U10460 |
STOPPER SCREW |
A109103200 |
Slide Rail /Left |
A109103100 |
Slide Rail /Right |
A07TN10200 |
DC Power source harness /1 /1 |
A109N10300 |
AC Power Source Harness /1 |
13NQ10361 |
POWER SOURCE MOUNTING PLATE |
13LH84511 |
DC Power Source |
A109101601 |
Wiring Plate |
A075M45211 |
DC Power source /2 |
A109N11100 |
Relay Harness /2 |
A109711200 |
Auxiliary Plate /1 |
A109711300 |
Auxiliary Plate /2 |
A109101700 |
Wiring Cover |
A109101100 |
Mounting Plate /3 |
A07TN10801 |
Drive Wiring /1 |
A07TN10100 |
Main body Wiring /1 |
13NQ10340 |
WIRING CONNECTING PLATE A |
13NQ10380 |
SUPPORT SHAFT /A |
13NQ10330 |
WIRING GUIDE ARM |
13NQ10390 |
SUPPORT SHAFT/B |
V121040603 |
screw |
V121030603 |
screw |
V111030603 |
screw |
V123030803 |
Screw |
V500010026 |
saddle |
V500010003 |
Saddle |
V193030404 |
screw |
V111030503 |
screw |
V123030603 |
Screw |
V217060050 |
E ring |
V217040050 |
E ring |
V217030050 |
E ring |
V501010002 |
band |
V500010005 |
saddle |
V501010003 |
band |
V500010007 |
saddle |
V360700000 |
Free Bush |
V570010015 |
saddle |
V500010008 |
saddle |
V114040616 |
screw |
V502010017 |
support |
V360300000 |
EDGING |
A07T160500 |
Door /2 |
A109940100 |
Processing Label |
A109160700 |
Fixing Plate |
A109160400 |
Connecting Plate /A |
A07T160201 |
External Cover /Upper |
A07R161500 |
Preventing Part /1 |
A07T160301 |
Rear Cover |
56UF97280 |
SEPARATION PROCESSING LABEL |
56AA97130 |
EARTH LABEL |
15AG97040 |
POWER SOURCE CAUTION LABEL |
56UA97320 |
CAUTION LABEL/A |
A109H01002 |
Control Board Assy |
V502010017 |
support |
26NA86511F |
Power source Socket |
13NK10320 |
MOUNT PLATE 1 |
26NA88612 |
Power Source Cord |
26NE88611E |
Power source Cord |
26NF88611 |
Power Source Cord |
A109N10901 |
Interface Wiring /1 |
56AF84540 |
Coil |
A07TM60100 |
Power source Relay |
15KS90040 |
AC POWER SOURCE WIRING 2 |
13NK88461 |
CIRCUIT BREAKER |
13NK50310D |
Spring /A |
12QR12190 |
COVER |
15KS10410 |
SWITCH MOUNTING PLATE |
55FA12101 |
MAGNET CATCH X |
15KS10420 |
SWITCH MOUNTING PLATE MIDDLE |
40AA85011 |
Door Switch |
12AR45611 |
ACTUATOR |
13LH10110 |
SWITCH COVER |
A07T160801 |
Hold Plate |
300011191 |
MAGNET HOLDER PLATE |
12AR12161E |
ACTUATOR |
A07T160100 |
Door /1 |
V127030603 |
screw |
V123040603 |
Screw |
V151030803 |
screw |
V151040603 |
Screw |
V121030603 |
screw |
V118030403 |
screw |
V121031603 |
screw |
V147030803 |
screw |
V118030603 |
screw |
V121040603 |
screw |
V114040604 |
Screw |
V501010004 |
band |
A07T941500 |
Release Label /5 |
13NQ45170 |
COVER FRONT |
13NK10330 |
COVER PLATE |
13NQ45621E |
Conveyance Cover /Upper |
13NQ45131E |
Main body Positioning Stay /2 |
A109450800 |
Cover /5 |
13NQ45121E |
Main body Positioning Stay /1 |
13NQ45140 |
LOCKING CAM |
13NQ45740 |
HOLDING SPRING |
13NQ45730 |
JAM RELEASE SPRING 8 |
13NQ45710 |
FULCRUM PLATE |
300078030 |
PIN B D3X12 |
55VA47710 |
BOTTOM PLATE LOCKING CLAW |
15JK42840 |
Entrance Roll /3 |
A07T701600 |
Protection Part |
13NK45251 |
PRESSING SPRING |
13NK-4640 |
Conveyance Driven Shaft Assy |
A109450300 |
Cover /1 |
A109450900 |
Fixing Plate |
13NQ45641 |
SPRING SUPPORT PLATE |
13NQ45631 |
SPRING MOUNTING PLATE |
13NQ-4690 |
CON SIDE PLATE REAR CAULKING |
A109450500 |
Cover /3 |
A109940200 |
Caution Label |
A109450600 |
Cover /4 |
A109450401 |
Cover /2 |
13NQ45680 |
GUIDE SHEET 2 |
13NQ45850 |
GUIDE SHEET 3 |
A07T910502 |
Guide Plate /5 |
A07T911201 |
Guide Sheet |
13NQ45690 |
RELEASE SHAFT |
13NQ45521 |
HANDLE /2 |
A07T941300 |
Release Label /3 |
15AG57160 |
LEVER COVER |
13NQ45720 |
JAM RELEASE SPRING 7 |
13NQ-4671 |
CON SIDE PLATE FRONT CAULKING |
13NQ-4720 |
HINGE PLATE CAULKING |
V118040603 |
screw |
V121030603 |
screw |
V123032003 |
Screw |
V121030403 |
screw |
V121040603 |
screw |
V151030803 |
screw |
V217020050 |
E ring |
V217030050 |
E ring |
V217040050 |
E ring |
V127030603 |
screw |
V127040603 |
screw |
V114040604 |
Screw |
V121030304 |
screw |
13NQ45830 |
MOUNTING PLATE 4 |
13QA85511 |
Sensor 1 |
15KS46030 |
NEUTRALIZING BRUSH |
A07T710801 |
Exit Guide Plate /1 |
048645260 |
STOPPER RUBBER |
A109712201 |
Paper Exit Sheet /1 |
A07T711000 |
Paper exit Sheet |
A07T710901 |
Exit Guide Plate /2 |
13NK45850 |
HINGE PLATE REAR |
15JK42840 |
Entrance Roll /3 |
13NK-4640 |
Conveyance Driven Shaft Assy |
13NK45251 |
PRESSING SPRING |
A07T701600 |
Protection Part |
13NK45840 |
HINGE PLATE FRONT |
13NK45760 |
REINFORCE PLATE 1 |
15AG46480 |
LIFTING STAY |
A07T941600 |
Release Label /6 |
15AA45560 |
RELEASE LEVER |
V121030603 |
screw |
V118030403 |
screw |
V127030603 |
screw |
V207040003 |
washer |
V217020050 |
E ring |
V500010003 |
Saddle |
V500020026 |
lifter |
V360200000 |
EDGING |
13NQ45261 |
GUIDE PLATE 6 |
13NQ45271 |
GUIDE PLATE 7 |
13NQ45890 |
GUIDE SHEET 5 |
A07T910301 |
Guide Plate /3 |
A07T911101 |
Adjusting Plate |
13NQ46060 |
GUIDE SHEET /9 |
A07T910901 |
Guide Plate /9 |
15KS50370 |
NEUTRALIZING BRUSH B |
13NQ45900 |
ADJUSTING SPRING |
13NK-4660 |
HINGE PLATE CAULKING |
065075040 |
DRIVEN SHAFT METAL |
13NQ45761 |
GUIDE PLATE A |
A109A7160 |
PAPER UP/DOWN LEVER/2 ASSY |
13NQ45340E |
Jam Release Spring /4 |
15JK42840 |
Entrance Roll /3 |
13NK-4640 |
Conveyance Driven Shaft Assy |
13NK45251 |
PRESSING SPRING |
A07T701600 |
Protection Part |
A07T941800 |
Release Label /8 |
13NQ45330E |
Jam Release Spring /3 |
13NQ45042 |
GUIDE PLATE 2 |
048645260 |
STOPPER RUBBER |
13NK45031 |
GUIDE PLATE 1 |
13NQ46010 |
GUIDE SHEET/7 |
13NQ45980 |
LIGHT SHIELD SEAL |
13NQ45860 |
GUIDE SHEET 4 |
13NQ-4740 |
SOLENOID MT PLATE/A CAULKING |
12ER40350 |
STICKING PART |
13NQR70200 |
SOLENOID 1 ASSY |
13NQ45950 |
SOLENOID SPRING 2 |
13NQ45930 |
SOLENOID ARM 3 |
13NQ45940 |
SOLENOID ARM 4 |
13NQ-4770 |
FULCRUM PLATE/A CAULKING |
A07TN10601 |
Relay harness |
V123030803 |
Screw |
V123040603 |
Screw |
V121030603 |
screw |
V121031603 |
screw |
V121040603 |
screw |
V195030003 |
nut |
V217020050 |
E ring |
V217030050 |
E ring |
V217040050 |
E ring |
V121030304 |
screw |
V123030604 |
Screw |
V123030603 |
Screw |
V127030603 |
screw |
A07T941400 |
Release Label /4 |
13NQ45661 |
HANDLE /3 |
55VA75520 |
REGISTRATION SHAFT HOLDER |
A07T452001 |
Folding Roller /3 |
13NQ45061 |
GUIDE PLATE /4 |
A0G6M91400 |
Gasket /D |
48645260 |
STOPPER RUBBER |
13NQ45670 |
GUIDE SHEET /1 |
A07T451901 |
Folding Roller /2 |
A07T451801 |
Folding Roller /1 |
55GA75040 |
Fixing Roller Bearing / Lower |
304078070 |
PIN C |
13NQ76520 |
FOLDING PULLEY /1 42T |
13NQ45820 |
FOLDING COLLAR |
13NQ77530 |
DRIVE BELT 3 345L |
13NQ77520 |
DRIVE BELT 2 264L |
08AA75010 |
Developing Bearing /S |
13NK76550 |
IDLING PULLEY 24/30T |
12QR50610 |
BELT HOLDER |
26NA53590 |
BALL BEARING |
12QR76550 |
DRIVING PULLEY A 24T |
13NQ45780 |
MOTOR DETECTING PLATE |
13NQ77010 |
FOLDING GEAR 1 43T |
13NQ77540 |
DRIVE BELT 4 276L |
13NK76530 |
MOTOR PULLEY 2 24T |
A07T705001 |
Motor Mounting Plate /2 |
56AA85511 |
Photo Sensor |
A07TM10100 |
HB Stepping motor /60 |
13NQ45380 |
PULLING PLATE |
13NQ45370 |
PULLING SPRING |
13NQ45840 |
CONVEYANCE ROLLER 2 |
20AL48470G |
Jam Release Knob |
A07T941200 |
Release Label /2 |
V123030803 |
Screw |
V118030603 |
screw |
V121030603 |
screw |
V121040603 |
screw |
V193030404 |
screw |
V217060050 |
E ring |
V217100050 |
E ring |
V118031003 |
screw |
V500020026 |
lifter |
V500010005 |
saddle |
V500010003 |
Saddle |
13NK45790 |
GUIDE PART / 1 |
13NK45100 |
PAPER UP DOWN LEVER 1 |
26NA53590 |
BALL BEARING |
13NK77020 |
Conveyance Gear 30T |
A07T452200 |
Protection Sheet |
13NQR70200 |
SOLENOID 1 ASSY |
12ER40350 |
STICKING PART |
13NQ-4740 |
SOLENOID MT PLATE/A CAULKING |
65075040 |
DRIVEN SHAFT METAL |
13NQ45430 |
SOLENOID SPRING 1 |
13NK45460 |
SOLENOID ARM 2 |
13NK75020 |
REGISTRATION DRIVING BEARING |
12QR76550 |
DRIVING PULLEY A 24T |
13NQ75010 |
Regist Drive Bearing |
13NQ46040 |
REGISTRATION DRIVING SPACER |
13NQ45550 |
REGISTRATION SPRING |
13NQ77540 |
DRIVE BELT 4 276L |
13NK76530 |
MOTOR PULLEY 2 24T |
A07T704801 |
Motor Mounting Plate /1 |
56AA80112 |
Paper Exit Drive Motor |
13NK45561E |
Wiring Guide Plate /3 |
13NK45472E |
Wiring Guide Plate /2 |
A109451100 |
Release Spring /2 |
13NQ45230 |
CONVEYANCE ROLLER |
13NQ45220 |
REGISTRATION DRIVEN ROLLER |
A07T712101 |
Regist Drive Roller |
13NK45810 |
GUIDE SHEET |
13NK45801 |
REGISTRATION GUIDE PLATE |
A109451000 |
Release Spring /1 |
14GE45470 |
Rotation Knob |
A07T941100 |
Release Label /1 |
V123030803 |
Screw |
V121030603 |
screw |
V118030603 |
screw |
V121042003 |
screw |
V217040050 |
E ring |
V217060050 |
E ring |
V118031603 |
screw |
V193030404 |
screw |
V500010026 |
saddle |
V123040603 |
Screw |
V127040603 |
screw |
V123030603 |
Screw |
V360100000 |
EDGING |
V360300000 |
EDGING |
V500010005 |
saddle |
V501010003 |
band |
A109A9130 |
Punch Rocking Assy (2/3 HOLE) |
13NK50081 |
SHAFT MOUNTING PLATE /FRONT |
13NK50140 |
PUNCH SLIDE SHAFT / UPPER |
08AA85512 |
Photo Sensor |
14JA50211 |
MOUNTING PLATE/B |
14JA50290 |
GUIDE PART |
13NK50280D |
Punch Slide Shaft /Lower |
13NK50250 |
PROTECTION RUBBER |
13NK75010 |
Slide Bearing |
14JA50021 |
PUNCH MOUNTING PLATE |
12QV75520 |
PAPER FEED SHAFT HOLDER |
13NK77030 |
PUNCH IDLING GEAR 40/14T |
13NK-5100 |
MOTOR MT PLATE/B CAULKING |
13NK50091 |
SHAFT MOUNTING PLATE/REAR |
A111A9160 |
PUNCH DRIVE GEAR ASSY |
13NK50170 |
PUNCH RACK |
A07T701300 |
Entrance Guide Plate /B |
15KS50220 |
NEUTRALIZING BRUSH |
A04FH02000 |
PAPER SIZE DETECTING BOARD ASSY |
13NKK0010 |
SPRING CLUTCH |
A07TN10501 |
Main Body Wiring /2 |
13NK50451 |
ENTRANCE SHEET B |
13NK50432 |
ENTRANCE SHEET |
13NK50340 |
SPACER |
15KS50380 |
NEUTRALIZING BRUSH/ C |
14JA50011 |
PUNCH MAIN BODY |
V121040603 |
screw |
V121030603 |
screw |
V121040403 |
screw |
V223120050 |
C ring |
V118030603 |
screw |
V217040050 |
E ring |
V121030403 |
screw |
V500010046 |
saddle |
V500020044 |
bushing |
V500010026 |
saddle |
V501010011 |
binder |
V501010002 |
band |
V501010006 |
band |
A109A9230 |
Punch Rocking Assy (2/4 HOLE) |
13NK50081 |
SHAFT MOUNTING PLATE /FRONT |
13NK50140 |
PUNCH SLIDE SHAFT / UPPER |
08AA85512 |
Photo Sensor |
14JA50211 |
MOUNTING PLATE/B |
14JA50290 |
GUIDE PART |
13NK50280D |
Punch Slide Shaft /Lower |
13NK50250 |
PROTECTION RUBBER |
13NK75010 |
Slide Bearing |
14JA50021 |
PUNCH MOUNTING PLATE |
12QV75520 |
PAPER FEED SHAFT HOLDER |
13NK77030 |
PUNCH IDLING GEAR 40/14T |
13NK-5100 |
MOTOR MT PLATE/B CAULKING |
13NK50091 |
SHAFT MOUNTING PLATE/REAR |
A111A9160 |
PUNCH DRIVE GEAR ASSY |
13NK50170 |
PUNCH RACK |
A07T701300 |
Entrance Guide Plate /B |
15KS50220 |
NEUTRALIZING BRUSH |
A04FH02000 |
PAPER SIZE DETECTING BOARD ASSY |
13NKK0010 |
SPRING CLUTCH |
A07TN10501 |
Main Body Wiring /2 |
13NM50510 |
ENTRANCE SHEET/C |
13NK50451 |
ENTRANCE SHEET B |
13NM50501 |
PUNCH HOLDING PART |
13NK50432 |
ENTRANCE SHEET |
15KS-5210 |
ENTRANCE SHEET/E ASSY |
13NK50340 |
SPACER |
15KS50380 |
NEUTRALIZING BRUSH/ C |
14JB50011 |
PUNCH MAIN BODY |
V121040603 |
screw |
V121030603 |
screw |
V121040403 |
screw |
V223120050 |
C ring |
V118030603 |
screw |
V217040050 |
E ring |
V121030403 |
screw |
V500010046 |
saddle |
V500020044 |
bushing |
V500010026 |
saddle |
V501010011 |
binder |
V501010002 |
band |
V501010006 |
band |
A109A9330 |
Punch Rocking Assy (SW4 HOLE) |
13NK50081 |
SHAFT MOUNTING PLATE /FRONT |
13NK50140 |
PUNCH SLIDE SHAFT / UPPER |
13NK50290 |
GUIDE PART |
13NK50280D |
Punch Slide Shaft /Lower |
13NK50250 |
PROTECTION RUBBER |
13NK75010 |
Slide Bearing |
13NK50020 |
PUNCH MOUNTING PLATE |
12QV85511 |
PHOTO SENSOR |
13NK50210 |
MOUNTING PLATE B |
12QV75520 |
PAPER FEED SHAFT HOLDER |
13NK77030 |
PUNCH IDLING GEAR 40/14T |
13NK-5100 |
MOTOR MT PLATE/B CAULKING |
13NK50091 |
SHAFT MOUNTING PLATE/REAR |
A111A9160 |
PUNCH DRIVE GEAR ASSY |
13NK50170 |
PUNCH RACK |
A07T701300 |
Entrance Guide Plate /B |
15KS50220 |
NEUTRALIZING BRUSH |
A04FH02000 |
PAPER SIZE DETECTING BOARD ASSY |
13NKK0010 |
SPRING CLUTCH |
A109N12500 |
Main Body Wiring /2 |
13NK50451 |
ENTRANCE SHEET B |
13NK50432 |
ENTRANCE SHEET |
13BX50520 |
ENTRANCE SHEET /D |
15KS50380 |
NEUTRALIZING BRUSH/ C |
13NK50340 |
SPACER |
13NK50320 |
PUNCH ACTUATOR |
13BX50011 |
PUNCH MAIN BODY |
V121040603 |
screw |
V121030603 |
screw |
V121040403 |
screw |
V223120050 |
C ring |
V118030603 |
screw |
V217040050 |
E ring |
V121030403 |
screw |
V123030603 |
Screw |
V500010026 |
saddle |
V501010011 |
binder |
V501010002 |
band |
V501010006 |
band |
13NK50190 |
SPACER A |
13NK50470 |
HOLD PLATE |
13NK50460 |
BRUSH |
13NK-5070 |
Punch Screw Pin Unit |
13NK50160 |
SCREW COVER |
13NK50260 |
COUPLING |
13NK50270D |
Connecting Shaft |
13GQ76020 |
SHAFT HOLDER A |
13NK50030 |
SCREW CONVEYING CASING |
15KS50370 |
NEUTRALIZING BRUSH B |
40AA77200 |
CONVEYANCE GEAR 33T |
13NK77050 |
SCREW IDLING GEAR 18/24T |
25AA29770 |
SEPARATE FULCRUM SHAFT HOLDER |
13NK-5521 |
SCREW MT PLATE / REAR CAULKING |
A07T701201 |
Entrance Guide Plate /A |
048645260 |
STOPPER RUBBER |
15KS85520 |
PHOTO SENSEOR 2 |
A07TA7030 |
Fulcrum Shaft Pin Assy |
13NK50421 |
MOTOR MOUNTING PLATE C |
A111A9280 |
MOTOR ASSY |
13NK50180 |
COVER B |
13NK50350 |
GUIDE COVER |
A0GY166200 |
Magnet Catch |
A07T910400 |
Punch Box |
A109940300 |
Processing Label /3 |
13NK50390 |
PUNCH COLLECTING PLATE |
13QE45470 |
STOPPER PART |
13NQ45880 |
STOPPER PART |
13NK50050 |
PUNCH COLLECTING DUCT |
13NK50061 |
SCREW MOUNTING PLATE /FRONT |
13NK50400 |
DUCT HOLDING PLATE UPPER |
13NK50230 |
ROTARY LEVER |
A07T941700 |
Release Label /7 |
13NK50240 |
RELEASE SPRING |
13NK50300 |
COVER LOWER |
08AA85512 |
Photo Sensor |
V138030603 |
screw |
V113030616 |
screw |
V217040050 |
E ring |
V217030050 |
E ring |
V121030603 |
screw |
V121040603 |
screw |
V151030803 |
screw |
V360200000 |
EDGING |
V570010023 |
saddle |
V121020603 |
screw |
V118260403 |
screw |
V118031003 |
screw |
V145030803 |
screw |
V500010051 |
saddle |
V500010024 |
saddle |
13NQ52141 |
COVER |
13NK52111 |
MOUNTING PLATE /3 |
13QA85511 |
Sensor 1 |
13NQ76550 |
FOLDING PULLEY 3 30T |
08AA85512 |
Photo Sensor |
A07TA4030 |
FOLDING SHAFT/3 PRESSING ASSY |
13NQ52150 |
PLATE |
13NQ52120 |
TENSION SPRING |
13NQ52160 |
TENSION PLATE 3 |
13NQ77570 |
FOLDING BELT 124L |
07BA15720 |
STOPPER ROLLER B |
13NQ76540 |
FOLDING PULLEY 2 20T |
13NQ52130D |
Folding Shaft /4 |
A00V240600 |
BALL BEARING |
A07T450600 |
Guide Plate /8 |
A07TN10701 |
Relay harness /2 |
13NQ52170 |
TENSION PLATE 4 |
12QV76530 |
PAPER EXIT PULLEY A 32T |
13NQ77560 |
DRIVE FOLDING BELT 2 98L |
13NQ52091 |
MOTOR MOUNTING PLATE /3 |
56GA73431 |
MOTOR FIXING PART /1 |
56GA80062 |
HB MOTOR 40 |
A07T915500 |
Pulley /C 16T |
13QA17300 |
PIN |
A07TN11002 |
Drive Wiring /2 |
V123030603 |
Screw |
V123040603 |
Screw |
V118030403 |
screw |
V500010026 |
saddle |
V121030603 |
screw |
V138030603 |
screw |
V193030404 |
screw |
V217040050 |
E ring |
V570010023 |
saddle |
V500010003 |
Saddle |
V217060050 |
E ring |
V501010002 |
band |
V139030603 |
screw |
13NQ52120 |
TENSION SPRING |
13NQ52050 |
TENSION PLATE 1 |
07BA15720 |
STOPPER ROLLER B |
13NQ76540 |
FOLDING PULLEY 2 20T |
13NQ52040D |
Folding Shaft /2 |
13NQ77570 |
FOLDING BELT 124L |
13NQ-5340 |
Folding Shaft /1 Pressing Assy |
13NQ52070 |
TENSION PLATE 2 |
13NQ76550 |
FOLDING PULLEY 3 30T |
13NQ52150 |
PLATE |
13GQ80032 |
FNS Motor /1 |
12QR77010 |
Staple Driving Gear 51/21T |
13GQ77010 |
REGULATING GEAR 28/55T |
13NQ77550 |
DRIVE FOLDING BELT 1 130L |
25AA52140 |
Belt Holder B |
120H42180 |
COLLAR |
12QV76530 |
PAPER EXIT PULLEY A 32T |
14QH75530 |
SHAFT HOLDER G |
13NQ-5330 |
MOTOR FIXING PLATE CAULKING |
13NQ52021 |
MOUNTING PLATE /1 |
08AA85512 |
Photo Sensor |
13NQ52011 |
FOLDING PEDESTAL /1 |
V123030603 |
Screw |
V123040603 |
Screw |
V118030403 |
screw |
V121030403 |
screw |
V121030603 |
screw |
V500010024 |
saddle |
V193030404 |
screw |
V217040050 |
E ring |
V123040803 |
Screw |
V217050050 |
E ring |
V217060050 |
E ring |
V121031203 |
screw |
V501010002 |
band |
V501010004 |
band |
V501010003 |
band |
V360200000 |
EDGING |
V360300000 |
EDGING |
V570010051 |
Edge Saddle |
V570010015 |
saddle |
V500010008 |
saddle |
V500010005 |
saddle |
V500010003 |
Saddle |
V570010014 |
saddle |
V500010026 |
saddle |
V501010011 |
binder |
V360700000 |
Free Bush |
V360100000 |
EDGING |
V502010017 |
support |
A07TA1630 |
ACTUATOR ASSY |
A07T101301 |
Mounting Plate /1 |
A07T101401 |
Mounting Plate /2 |
55FA12101 |
MAGNET CATCH X |
A07T101800 |
Fixing Plate |
129U10350 |
CARRIAGE ROLLER 1 |
A109101500 |
Fixing Plate /1 |
12QV10101 |
ADF MOUNTING SCREW |
A109A7130 |
Entrance Guide Plate Assy |
15KS97070 |
Punch Label /1 |
15KS97080 |
Punch Label /2 |
A109A7150 |
Punch Guide Plate Assy |
A109A1040 |
Setting Plate Assy |
A07T160601 |
Cover /Right |
A092145000 |
Cover /Upper |
A092145200 |
Mounting Plate |
4036596601 |
SCREW |
9J06M10000 |
FAN MOTOR |
A092145500 |
Cushion |
A092145100 |
Cover /Lower |
A092145300 |
Cover/Rear |
A092145400 |
Shoulder screw |
A092160000 |
Paper exit Cover /Left |
A092N11P00 |
CONVEYANCE RELAY HARNESS /3 |
V121030803 |
SCREW |
V153030803 |
Screw |
A02E169600 |
Holder |
A02E169612 |
Holder |
9326282011 |
MAGNET |
1139170302 |
SLIDER |
1139170601 |
SEAL |
1139170414 |
PAD |
A02E169500 |
Cover |
A02E169511 |
Cover |
A02E169700 |
Hinge |
V153041603 |
screw |
V147031403 |
screw |
